Installation / Service Instructions
For the latest documentation, visit www.escea.com 630241_14
DL850 / DL1100
Gas Fireplaces
Important:
The appliance shall be installed in accordance with;
• This installation instruction booklet
• Local gas fitting regulations
• Municipal building codes
• Electrical wiring regulations
• Any other relevant statutory regulations.
• AS/NZS 5601:2010 Gas Installations
WARNING:
This appliance must be installed by a qualified person.
Do not modify this appliance.
This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the appliance.
Failure to follow these instructions could cause a malfunction of the heater, which could result
in death, serious bodily injury, and/or property damage. Failure to follow these instructions may
also void your fire insurance and/or warranty.
Who can install this product:
Installation must be carried out by a registered installer who, on completion of the installation,
must issue a:
AUS: Certificate of Compliance
NZ: Certificates that comply with the latest legislation
in accordance with national and/or local codes. If these are not issued then the Escea warranty
may be void.
Warranty Repair and Annual Servicing:
Please contact Escea if you require warranty work. Warranty repair work must be carried
out by a recognised gas fire technician. It is recommended that recognised Escea Gas Fire
Technicians are also used to carry out annual servicing requirements (particularly during the
warranty period). For contact details of recognised Escea Gas Fire Technicians in your area, or
for replacement parts, please contact the retailer from whom the appliance was purchased our
visit our website.
The heater must be installed according to these instructions and in compliance with all relevant
building, gas fitting, electrical and other statutory regulations (e.g. AS/NZS 5601). Any
shortcomings in the appliance and flue installation will be the responsibility of the installer, and
Escea will not be accountable for any such failings or their consequences.
Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220. For contact
details of your local Escea distributor or dealer in New Zealand, please visit: www.escea.com or
email: info@escea.com. From Australia, please visit www.escea.com.au, call AU: 1800 460 832
or WA: 1800 730 140, or email us at info@escea.com
DL850 PRODUCT SPECIFICATION
MODEL NAME DL850
Description of Appliance Gas Fire Heater
Star Rating 5.0 Stars
Max. Heat Output 9.2kW
A/NZ Approval No. AS/NZS 5263.1.3:2016
Gas Type Natural Propane ULPG
Gas input High 38 MJ/hr 38 MJ/hr 33 MJ/hr
Low 17 MJ/hr 15 MJ/hr 14 MJ/hr
Inlet Pressure Max 5 kPa 5 kPa 5 kPa
Min 1.13 kPa 2.75 kPa 2.75 kPa
Operating Pressure on High 1.0 kPa 2.3 kPa 2.6 kPa
Burner Jet Size Front: 2.45mm
Rear: 2.3mm
Front: 1.4mm
Rear: 1.3mm
Front: 1.2mm
Rear: 1.1mm
Burner Aeration Front and Rear:
Small Hole
Front and Rear:
Large Hole
Front and Rear:
Large Hole
Pilot injector Regular Red Red
Appliance Dimensions
(mm)
Width 959mm
Height 560mm
Depth 517 mm
Weight 65 kgKg
Ignition System Electronic Ignition to pilot system
Escea PCB
Flame Safeguard Flame Rectification
Remote controls Yes
Timers Yes
Clock Yes
Function lock / child Yes
Temperature control Yes
Connections 230V ACElectric
Gas 1/2" BSPP female lower centre of fireplace chassis
Flue Type Aluminium Flexi Flue and PolyPro
Flue Size 75mm and 100mm Flexi Flue & PolyPro
Spigot Loca-
tion
Right hand top
Data badge location On Chassis Base
