Sida 1/21

User Manual and 

Install Instructions 

                                 



 



‐FOR  OUTDOOR USE ONLY.



‐READ THE INSTUCTIONSCAREFULLYAND 

BESUREYOURBARBECUEIS IN PROPERLY 

INSTALLEDANDASSEMBLED. 

FAILURETOFOLLOWTHESEINSTRUCTIONS

MAYRESULTINSERIOUSINJURY DAMAGE.OR 



‐PLEASERETAINTHEMANUALFORFUTURE 

REFERENCE.



‐  CONVERSION OF NATURALGASONLYTOBE 

DONEBYAUTHORIZEDPERSONS.



‐REMOVALOFANYTRANSITPROTECTIONBEFORE 

USING

  COKBBQEUGABR5

NOTETOINSTALLER: 

TESTOPERATIONOFTHEAPPLICANCEANDINSTRUCT

THEUSERBEFORELEAVING.



 

MillsInternationalTradingPty,Ltd.

                       2/5StantonRoad,SevenHillsNSW2147AUSTRALIA



USE



OUTDOORS



ONLY



Thisapplianceshallonlybeused in anaboveground open ‐airsituationwithnaturalventilation,withoutstagnantareas,

where aregas leakage andproductsofcombustion rapidlydispersedbywindandnaturalconvection.

Anyoutdoorenclosureinwhichtheapplianceisusedshallcomplywithoneofthefollowing:

 Anenclosurewithwalls levelon permanentallsides,but at leastone opening at ground andnooverheadcover.See

Figure1.

 Within a partialenclosurethatincludes  an overhead coverandnomorethantwowalls.SeeFigure  2 & 3.

 Within a partialenclosurethatincludes  an overhead coverandmorethan thetwowalls, followingshallapply:

‐At          least 25% of the total wall area is completely open; and

‐At    least 30% of the remaining      wall area is open and unrestricted. SeeFigure  4 & 5.

 Inthecaseofbalconies, side, at least20%of ofthetotal the back beandfrontwallareasshall andremainopenand

unrestricted.

Thefollowingdiagramsprovide a diagrammatic representation areas. ofoutdoor Rectangularareashave been usedinthese

figures‐thesameprinciplesapplyto any othershapedarea







Figure Figure Enclosure1‐Enclosure onwithwalls allsidesbut 2‐Partial withoverheadcoverand

nooverheadcover                                                       no    more than two walls









Figure Figure3‐PartialEnclosurewithoverheadcoverand 4‐Opensideatleast25%of total wallarea.

         nomorethantwowalls                                     30          % or more in total of the remaining wall area is

 openand unrestricted. 

 



Figure5‐Open atside least25%of total wallarea.30percentor

morein istotal of theremainingwallarea 

open unrestrictedand



GASCYLINDERINFORMATIO                                                       



• aThisapplianceisdesignedtobeusedwith gascylindernotexceeding(Australia9KG) 

•Thegascylindersupplyvalvemustbeturnedoffwhentheapplianceisnotinuse.

• children a buiGascylindersmustbestoredoutdoors,outofreachof andmustnotbestoredin  lding,garageor

any area.otherenclosed 

•Thegascylinderusedmustincorporate a safetycollartoprotectthevalveassembly.

* a  Neverstore spare        cylinder under the barbecue shelves or inside the trolleyhousing.Any

LPGcylindernot beattachedtotheBBQ usefor should storedoutdoorsandwellawayfromthisappliance.

Important:

•Whendisconnectingandremovingthegascylinderforthepurposeofrefilling,alwaysobservethefollowing

procedure.

•Ensurethatallgascontrolvalvesontheapplianceandthegascylinderareturned off beforedisconnectingthe

regulatorfromthecylinder.

•Donotsmoke useor  a naked nearflame the orappliance gascylinderwhiledisconnecting linethegas between

theapplianceandgascylinder.

•Removethegascylinderfromtheenclosurebeforedisconnecting appliance.the theregulatorfrom  

•Tighten  all connections before back placing thegascylinder initsenclosure.

•Thegasleaktestingprocedureshouldbeconducted      every time the gas cylinder is refilledandreconnectedtothe

appliancebeforeusingthe appliance.



RegulatorConnection

1.Checkthat theallcontrolknobsarein ‘Off’position.

2.Makesurethecylindervalveisoff.

3.   Remove the protectivecapfromthecylinderifpresent.

4. Leak           test the connection with a soapy water solution.



GasLeakTestProcedure

Neveruse a nakedflameto check forgasleaks.

Alwaysusethefollowingproceduretocheckforgasleaks.

1.In a smallcontainer,mixup a solutionofwaterand 

detergentor thesoap.Mix solutionwell.

2.  Makesurethat the the gassupplyvalveon gascylinder

   is turned on.

3.Makesurethat the the gascontrolvalveson appliance 

areallturnedoff.

4. Using a brushorspraybottleapplythe thesolutionto  

gas galineandeachjoininthesline. 

5.Bubblingofthesolution will indicatethatthereis a leak 

present.

6.Re‐tightenor jointsre‐sealany that  are leaking.

7.If a leakpersiststhencontactyourdistributororthe 

manufacturerforassistance.


