The EVGA B360 Micro Gaming is the discerning gamer’s choice for building a powerfully affordable
system. This motherboard eliminates frills and unneeded features, while still providing a solid
platform capable of gaming, work, or study. Featuring an 8-Phase PWM design, the B360 Micro
Gaming supports the latest Intel® Socket 1151 Coffee Lake-S 6-Core processors, and 2 DDR4
DIMMs that support up to 32GB at 2667MHz. This motherboard also supports USB 2.0, 3.1 Gen1,
and 3.1 Gen2 ports and headers to keep your devices connected, and storage options including six
SATA 6Gbps ports and an M.2 Key-M slot. Stream your favorite content with an Intel® i219V Gigabit
NIC and a CNVi-ready M.2 Key-E slot. Make the EVGA B360 Micro Gaming your next motherboard
and enjoy modern performance and features for a budget-friendly price.
Part No: 112-CS-E365-KR INTRODUCTION
DIMENSIONS
• Width: 8.0 in – 200mm
• Length: 9.6 in – 244 mm
• Form Factor: mATX Form Factor
ACCESSORIES
• EVGA Quick Installation Guide
• Rear Case I/O Panel
• 2 SATA 6G Data Cables
• M.2 Key-M Thermal Pad
• USB Flash Drive + Contains
driver and manual
KEY SPECS
• Supports Intel® Core™ 8th Generation Processor Family
for 1151 socket
• 150% Increased Gold Content
• Intel® B360 Chipset
• 2 DIMM Dual-Channel up to 32GB 2667MHz+
• PCI Express® 3.0 Ready
• 5 USB 2.0 Ports (4 rear panel, 1 from 1 internal header)
• 2 USB 3.1 Gen1 Ports (2 from 1 internal header)
• 4 USB 3.1 Gen2 Ports (4x rear panel Type-A )
• 6 SATA
• 1 M.2 Key-M 80mm up to 32Gbps
• 1 M.2 Key-E 32mm
• Intel i219V Gigabit NIC (10/100/1000)
• mATX Form Factor
DESIGN DETAILS
Microprocessor support: Intel® Socket 1151 Processor
(Coffee Lake-S)
Operating Systems: Supports Windows 10 64bit
System Memory support: Supports Dual-Channel DDR4
up to 2667MHz, Supports up to 32GB of DDR4 memory.
USB 2.0 Ports: 5x from Intel® B360 PCH
– 1x internal via 1 FP header. Supports transfer speeds up
to 480 Mbps with full backwards compatibility.
USB 3.1 Gen 1 Ports: 2x from Intel® B360 PCH
– 2x internal via 1 FP header. Supports transfer speeds up
to 5Gbps with full backwards compatibility.
USB 3.1 Gen 2 Ports: 4x from Intel® B360 PCH
– 4x external Type-A. Supports transfer speeds up to
10Gbps with full backwards compatibility.
SATA Ports: Intel® B360 PCH Controller 6x SATA 6.0 Gb/s
(600 MB/s) data transfer rate - Supports hot plug
Onboard Audio: Realtek Audio (ALC888) + SV3H615 3D
Headphone Amp. Supports 5.1 Channel HD Audio + EVGA
NU Audio.
Onboard LAN: 1x Intel® i219V Gigabit (10/100/1000)
Ethernet PHY
Power Functions: Supports ACPI (Advanced Configuration
and Power Interface). Supports S0 (normal), S3 (suspend
to RAM),
S4 (Suspend to disk - depends on OS), and S5 (soft - off)
PCIe Expansion Slots:
1x PCIe x16 slot
1x PCIe p1-x4 slot
1x PCIe p1-x1 slot
PCIe 3.0 Support: Low power consumption and power
management features.
Additional Expansion Slots:
1x M.2 Key-M 80mm slot PCIe/NVMe.
1x M.2 Key-E CNVi-Ready slot for WiFi/BT*
Fan Headers: 3x 4-pin PWM controlled headers
*WiFi card/kit is not included and must be purchased separately.
PRODUCT WARRANTY
This product is covered under EVGA’s 3 year limited warranty which covers parts and labor. Further warranty extension is
available upon registration within 30 days of purchase. For more details please visit: www.evga.com/warranty.
B360 Micro Gaming
FULL UEFI GUI BIOS INTERFACE
Focused on functionality
8 PHASE PWM
Cleanest variable power switching
E-LEET TUNING UTILITY
Monitor System Vitals in OS
HIGHER GOLD CONTENT
Lower inductance, better power delivery!
M.2 SLOT
Next Generation Form Factor
PASSIVE CHIPSET HEATSINK
No fans, lower noise, longer lifespan
B360 Micro Gaming Part No: 112-CS-E365-KR FEATURES
PRODUCT WARRANTY
This product is covered under EVGA’s 3 year limited warranty which covers parts and labor. Further warranty extension is
available upon registration within 30 days of purchase. For more details please visit: www.evga.com/warranty.
