Model: QB-35RFEU3
4-BAY RAID ENCLOSURE
R D LED A nAI Modus E / instellungen nzeige
I t t nni ializa io 15-24
W Vi a 7 c tosh indows st / Windows / Ma in O.S. 10.X
Re erencef s 25-28
http:// w. ntec.deww fa
I you hav uestion o need help with thi device,f e q s r s
pl s vis ou Fante Suppor F um:ea e it r c t or
http:// w. ntec-foru de/ww fa m.
Please vis ou websit fo re for tion:it r e r mo in ma
English
DE - 01/38 DE - 02/38
DIAGRAM of FANTEC QB-35RFEU3
FRONT PANEL
DESCRIPTION
LED INDICATION
1. Blue Power on
Orange Sleep mode
2. Rebuild
3. HDD error When any of HDD1~HDD4 has error, HDD error is on.
4. RAID 0 Spanning Mode / BIG
5. RAID 0 Striping Mode
6. RAID 1
7. RAID 3
8. RAID 5
9. RAID 10
10. Power button It needs to be pressed for 3 seconds to power off.
This design prevents accidental power off.
11. eS A in use / accessAT
12. USB in use / access
13. Firewire in use / access
14.-17. HDD1 / HDD2 / HDD3 / HDD4
Blue active
Purple access
Red rebuild
18. Smart Fan automatic mode
19. Smart Fan manual mode
20. Fan speed level 1
21. Fan speed level 2
22. Fan speed level 3
23. Mode RAID mode button needs to be pressed for 3 seconds to
switch the device's mode. This design will prevent
accidental execution of this function.
24. Fan button Controls auto & manual modes and fan speed from
level 1 to level 3.
25. HDD1 error
26. HDD2 error
27. HDD3 error
28. HDD4 error
OVERVIEW
EN - 01/28 EN - 02/28
Quick installation guide
SELF-ASSEMBLY
C. Press down the rib to detach the metal
frame and remove it.
A. Please use the provided handles to
secure the 4 HDDs with screws.
B. Press the circular deepening to open
the cover.
DESCRIPTION
1. Fan
2. RAID CONFIRMATION button
3. Firewire 400
4. USB 3.0 / 2.0 port
5. eSATA port
DESCRIPTION
1. 2x Firewire 800
2. DC Jack
3. DC Power
HDD HANDLE FRONT COVER METAL FRAME
REAR PANEL
SIDE PANEL right
EN - 04/28EN - 03/28
1
3
4
2
5
2
3
1
