Ferguson FMB920 Bruksanvisning

Ferguson Bil högtalare FMB920

Läs nedan 📖 manual på svenska för Ferguson FMB920 (3 sidor) i kategorin Bil högtalare. Denna guide var användbar för 9 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/3

car-assistant.pl FMB920

watches, warns, reminds

WITHOUT FEES

FOR DATA

TRANSFER IN

THE WHOLE

EUROPEAN

UNION!

GPS vehicle monitoring

GSM communication

warning against possible theft

the possibility of cutting

o the ignition

warning about possible road collision

reminders about important dates

Your car in the

palm of your hand

the ability to remotely shut o

the ignition in case of theft!

assembly in:

• car

• motorcycle

• truck

• delivery truck

• bus

• four-wheeler

• any other vehicle!

car-assistant.pl

Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland

tel. +48 61 822 05 11, fax +48 61 822 05 59

e-mail: oce@ferguson-digital.eu

www.ferguson-digital.eu

FMB920

is an

alarm system consisting of

a small electronic device and

a free application on the phone.

The sensor is mounted in your

vehicle and connected to the

power supply. It has a permanent

remote connection to the server

and the application over the

cellular network. Thanks to it,

the user receives a number

of functions, eg a theft alarm

with a map or an accident

detection system informing

about a possible collision. The

map and navigation will also

help nd your vehicle left in the

parking lot or in a foreign city.

is an

easy-to-use, real-time tracking

GPS position monitor with

GNSS and GSM connectivity,

which is able to collect device

coordinates and other useful

data for transmission through

the GSM network to the server.

• Plug and follow

• Small device mounted inside the car/

motorcycle/other vehicle (recommended

help from a professional installer)

• Internal GSM and GNSS antenna allowing for

easier (without external antennas) mounting

• Real-time tracking

• Intelligent data collection based on time,

distance, angle, ignition, speed

• Sending the data obtained via GPRS

(TCP/IP and UDP/IP protocols)

• Works in roaming networks

• Current speed

• Over speeding alarm

• Theft alarm

• Information on battery voltage

• Information on switching the ignition on/o

• Ability to cut o the ignition

• Battery voltage drop alarm

• Power failure alarm - sabotage

• Alarm for detection of a possible collision

• A reminder about the review

• Reminder about an insurance policy

• Navigation to the vehicle

• Counter of kilometers traveled

• Route history (last 4 months)

• Private/business travel

• Route mapping

• Online application

• Integrated scenarios:

• Excessive speed to protect the driver

and prevent punishment

* Functions dependent on the purchased package - more

information on the website http://car-assistant.pl

car-assistant.pl

Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland

tel. +48 61 822 05 11, fax +48 61 822 05 59

e-mail: oce@ferguson-digital.eu

www.ferguson-digital.eu

FMB920

GSM

• Quad-band 850/900/1800/1900 MHz

• GPRS class 12 (up to 240

kbps) SMS (text/data)

• SMS (text/data)

GNSS

• Tracking: 33/99 channels

• Sensitivity -165 dBM

• Hot start <1s

• Warm start <25s

• Cold start <35s

• NMEA-183 protocol

• GPS, GLONASS, GALILEO,

BEIDOU, SBAS, QZSS, DGPS

• Accuracy <3m

Interface

• 1 digital input

• 1 analog input

• 1 digital NO output (connection of

external relays, LED diodes, buzzer etc.)

• Accelerometer

• 10~30 VDC power supply

• Integrated 170 mAh battery

Li-Ion 3.7 V (0.63 Wh)

• GSM internal high gain antenna

• GNSS internal high gain antenna

• Dimensions: L (79mm) x W

(43mm) x H (12mm)

• 2 device status LEDs

• Working temperature: -40°C to +85°C

• Humidity: 5% to 95%

• IP54

EAN: 4779027311753

Packaging: xx pcs

Warning about a possible

trac collision

Too much overload or

impact can be a signal

that an accident has

occurred. The system will ale

and selected people. You wil

immediately see the location

the potential event on the map.

Warning against

possible theft

Each time your car

changes position

without authorization,

you will receive an alarm

about possible theft. You will be able

to follow your vehicle on the map.

Warnings

and echoes

The system noties too

much of the battery

voltage drop. The parental

control function gives

the possibility of warning about

exceeding the set speed limit.

Reminders about

important dates

We took care of other

useful messages,

including ones about

upcoming inspection

dates or scheduled visits to the car

service. The system also makes sure

that the insurance policy is renewed.
