User Manual
VS80 Camera
Probes
For use with the VS80 High Performance
Videoscope
Introduction
The probes covered in this manual are designed for use with the
VS80 High Performance Videoscope. The probes are controlled by
the touch-screen icons and control buttons on the VS80.
The VS80 user manual and additional translations of this probe
manual are available from the support site (see the Support
section).
Please update the VS80 firmware before use, as explained in the
VS80 manual. This will ensure optimal functionality and full compat-
ibility with your camera probe.
Probe Descriptions
The probes are described in the following sections, see the Specifi-
cations and Safety sections for additional information.
The VS80 offers many useful and convenient features including
capturing still images and video, changing camera views, connect-
ing with smart devices, and controlling worklights. Please refer to
the VS80 user manual for complete information.
VS80C55-1RM General Purpose Camera Probe
The general purpose camera probe head is 5.5 mm in diameter
and its probe length is 3.3 ft (1 m). The camera resolution is 640 *
480.
1. VS80 connector
2. Probe
3. Probe head
4. Front view of camera lens and worklights
#NAS100105; r. AB/83753/84877; en-US 1
VS80CHD–55-1RM HD Camera Probe
The HD camera probe head is 5.5 mm in diameter and its probe
length is 3.3 ft (1 m). The camera resolution is 1280 * 720.
1. VS80 connector
2. Probe
3. Probe head
4. HD camera lens and worklights
VS80C2-49-1RM Dual HD Camera Probe
The dual HD camera probe head is 4.9 mm in diameter and its
probe length is 3.3 ft (1 m). The camera resolution is 1280 * 720.
1. VS80 connector
2. Probe
3. Side view camera and worklights
4. Forward view camera
VS80CIR—21 Thermal IR Camera Probe
The VS80CIR-21 offers a Lepton 3.5 IR camera with a 3.3 ft (1 m)
probe. The VS80 displays the camera image and the temperature
of targeted surfaces and offers s selectable display palette, a tem-
perature alarm, and other features.
1. VS80 connector
2. Probe
3. Orientation mark. This represents the top of the image
4. IR camera lens
#NAS100105; r. AB/83753/84877; en-US 2
