Sida 1/48
manual
Power Supply
Installation
1
At first, remove the old PSU from the system case. Firstly, draw off all
plugs from the PSU, that are connected with the mainboard or other
components in the PC. Now remove the screws at the back side of the
case which connects the PSU with the case. After the screws are
removed, remove the old PSU from the case carefully and replace it with
your new FSP PSU.
Set the PSU into the intended position in the housing and tighten it with
the supplied screws. If you purchased a PSU with modular cables, put all
necessary cables on the PSU. No need to connect cables that are not
intended to be used on the PSU.
Put the 20+4 / 24-pin ATX plug through
the housing to the correct connection
of the mainboard.
1
Connect the 8-pin plug to the
mainboard. If your mainboard only has
a 4-pin connector, then use the 4-pin
plug or split the 8-pin connector in half.
2
For graphic cards with 6-pin connector
or connectors, use the suitable cables.
Modern graphic cards with 8-pin
connectors are also supported. In this
case, use the other two pins beside
the regular 6-pin plug in order to create
an 8-pin connector.
3-1

Produktspecifikationer

Varumärke: FSP
Kategori: Dator strömförsörjning
Modell: Hydro K Pro 850W ATX 2.52
