Sida 1/8

WARNING: Read all safety warnings and instructions before use. Failure to

follow the warnings and instructions may result in electric shock, ﬁre and/or

serious injury. Save these instructions for future reference.

09/16

DEMOLITION

HAMMER KIT

ORIGINAL INSTRUCTIONS

Power: 1500W

Input: 230-240V ~ 50Hz

Impact Energy: 32J

Impact Frequency: 1900/min

Breaking Capacity: 38mm

Accessory Fitment: SDS Max

Weight: 10.8kg

SPECIFICATIONS - MODEL NO. FBT-1100U

KNOW YOUR PRODUCT

1. Accessory Holder

2. Accessory Locking Sleeve

3. Accessory Rotation Lock

4. Side Handle

5. Power Cord

6. On/Off Trigger

7. Lock-On Button

8. Anti-Vibration Rear Handle

4 5

Congratulations on purchasing your Full Boar demolition

hammer kit. It has been designed for rapid breaking and

chipping of concrete, block and masonry products.

Read and understand the instruction manual before

operating the demolition hammer. Failure to do so could

result in personal injury or equipment damage.

INTRODUCTION

WARNING! When using mains-powered tools, basic safety precautions, including the

following, should always be followed to reduce risk of ﬁre, electric shock, personal injury

and material damage.

Read the whole manual carefully and make sure you know how to switch the tool off in an emergency,

before operating the tool. Save these instructions and other documents supplied with this tool for

future reference. The manufacturer cannot accept any liability for damage or accidents which arise

due to a failure to follow these instructions and the safety information.

Before you connect the equipment to the mains supply make sure that the data on the rating plate is

identical to the mains data.

This tool is double insulated therefore no earth wire is required.

The power supply for this product should be protected by a residual current device (rated at 30mA or

less). A residual current device reduces the risk of electric shock.

If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord

available through the service organisation.

Note: Double insulation does not take the place of normal safety precautions when operating this

tool. The insulation system is for added protection against injury resulting from a possible electrical

insulation failure within the tool.

Using an Extension Lead

Always use an approved extension lead suitable for the power input of this tool. Before use, inspect

the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or

defective.

When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead

not suitable for the power input of the tool or which is damaged or defective may result in a risk of ﬁre

and electric shock.

ELECTRICAL SAFETY
