Six outlet power conditioners with standard surge protection, EMI/RFI filtration,
heavy duty steel construction, and 15 ft. power cords.
The SS-6B-Pro includes the Furman EVS (Extreme Voltage Shutdown) technology that
will disconnect the power conditioner from the AC mains to protect your connected
equipment as well as itself. The high shutdown is set at 140 Vac +/- 5% while the
low shutdown is set at 95 Vac +/- 5%.
POWER CONDITIONERS
PRO PLUGS
SS-6 / SS-6B / SS-6B-Pro / PlugLOCK / ACX-25
POWER DISTRIBUTION UNITS
SS-6
SS-6B SS-6B-Pro
PlugLOCK
Lock your plugs and
transformers in place,
ensuring you never
get disconnected from
your power source
ACX-25
Discreet, 25 ft. power
cord provides ultimate
durability and longevity
Whether it’s on-stage or in the studio, Furman
Pro Plugs give you the protection you need.
With surge protection, noise filtration, and
diagnostic lighting, you can trust Furman Pro
Plugs for reliable, clean, and protected power.
Our products have saved billions of dollar’s
worth of equipment from power problems, and
our innovative technologies maximize system
performance.
WHAT
ARE YOU
PLUGGING
INTO?
Rev A, 04/2018
15A Rating
15A Rating 15A Rating
15A Rating 15A Rating
Diagnostic Lights
Diagnostic Lights Diagnostic Lights
6 Outlets
6 Outlets 6 Outlets
5 Outlets 3 Outlets
Standard Level
Surge Protection
Standard Level
Surge Protection
Standard Level
Surge Protection
Standard Level
RFI/EMI Filtration
Standard Level
RFI/EMI Filtration
Standard Level
RFI/EMI Filtration
EVS Voltage
Protection
POWER CONDITIONERS SS-6 SS-6B SS-6B-Pro
AC Protection Technology Standard spike and surge protection
UL VPR:400V, UL Nominal
Standard spike and surge protection
UL VPR:400V, UL Nominal
Standard spike and surge protection
UL VPR:400V, UL Nominal
Signal Pulse Energy Dissipation 540 Joules 540 Joules 540 Joules
Filtration Technology Standard level RFI/EMI filtration
Filter: -20dB Min, 100kHz – 1MHz
Standard level RFI/EMI filtration
Filter: -20dB Min, 100kHz – 1MHz
Standard level RFI/EMI filtration
Filter: -20dB Min, 100kHz – 1MHz
Under-Voltage Shutoff — — 95VAC +/- 5%
Over-Voltage Shutoff — — 140VAC +/- 5%
Dimensions 2.5”W x 1.5”D x 14.5”H 3.5”W x 1.5”D x 9.5”H 3.5”W x 1.5”D x 9.5”H
Weight 2.52lbs 2.64lbs 2.64lbs
AC Power Cord 15ft. captive cord (14AWG) 15ft. captive cord (14AWG) 15ft. captive cord (14AWG)
Outlets 666
Line Voltage 120V 120V 120V
Current Rating 15 amps 15 amps 15 amps
Safety Listing cULus cULus cULus
Warranty 1 year 1 year 1 year
POWER DISTRIBUTION UNITS PlugLOCK ACX-25
Dimensions 2.3”W x 2.5”D x 12.6”H —
Weight 2.125lbs 3lbs
AC Power Cord 5ft. captive cord (14AWG) 25ft. (14AWG)
Outlets 5 3
Line Voltage 120V 120V
Current Rating 15 amps 15 amps
Safety Listing cCSAus cULus
Warranty 1 year 1 year
©2018 Nortek Security & Control, LLC. All rights reserved. Furman
® is a registered trademark of Nortek Security & Control. 1800 South McDowell Blvd, Petaluma, CA 94954, USA | | Rev A, 04/2018
PRO PLUGS SS-6 / SS-6B / SS-6B-Pro / PlugLOCK / ACX-25
To find your local Furman
Dealer or Regional Sales
Representative, please visit:
www.FurmanPower.com
Product Video
#1 in Power Protection for Over 40 Years
