Sida 1/9

GE Consumer & Industrial

Appliances

Junction Box Cov

Suppl

ied Parts:

#10

Hex-Head Screw 1/2"

Long

Junct

ion Box Cover

Within this user bag, you will find a junction

box cover and a #10 hex head screw used

to attach the junction box cover to the

bottom bracket or front brace (depending

on the model). The #10 hex-head screw

is packaged in a small bag within the

user bag. Use these parts when making

electrical

connections.

General Electric Company

Pub. No.

49-55020

Part

65D4700P340

-1

(4/06)

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

THE JUNCTION BOX COVER AND SCREW

MUST BE USED DURING THE ELECTRICAL

CONNECTION STEPS TO AVOID THE RISK OF

FIRE OR ELECTRIC SHOCK. SEE INSTALLATION

INSTRUCTIONS.

WARNING

Installation instructions

for your new

• Before you begin—Read these instructions completely and carefully.

• IMPORTANT–Save these instructions for local inspector’s use.

• IMPORTANT–OBSERVE ALL GOVERNING CODES AND ORDINANCES.

• Note to Installer–Be sure to leave these instructions with the Consumer.

• Note to Consumer–Keep these instructions with your Owners Manual for future reference.

Built-In

Dishwasher

If you have a question concerning the installation of this

product, call the GE Answer Center Consumer Information

Service at 800.626.2000, 24 hours a day, 7 days a week.

If you received a damaged dishwasher,

you should immediately contact your

dealer or builder.

Installation of this dishwasher requires basic mechanical and

electrical skills. Proper installation is the responsibility of the

installer. Product failure due to improper installation is not

covered under the GE Appliance Warranty. See the back

cover of the Owners Manual for warranty information.

The dishwasher MUST be installed to allow for future removal

from the enclosure if service is required.

MATERIALS YOU WILL NEED:

Materials required:

l 90° elbow

(3/8" NPT external thread on one end and

opposite end sized to fit water supply)

l Thread seal tape

l UL Listed Wire nuts (3)

For new installations only:

l Air gap for drain hose, if required

l Waste tee for house plumbing, if applicable

l Electrical cable or power cord, if applicable

l Screw type hose clamps

l Strain relief for electrical connection

l Hand shut-off valve (recommended)

l Water line 3/8" min. copper or 1/2" min. plastic

l Coupler for extending drain line, if applicable

Electrical Cable

or Power Cord 90° Elbow

Strain Relief

Hot Water Line

Thread Seal

Tape

Screw Type Clamps

Wire Nuts

Air

Gap Waste

Tee

Shut-Off

Valve

Flashlight

Flat Blade Screwdriver

Drill

and Bits

Measuring Tape Level

Phillips Head

Screwdriver

Tubing

Cutter

Square

Hole

Saw Set

TOOLS YOU WILL NEED:

Tools required:

l Phillips head and flat blade screwdrivers

l Adjustable wrench (6")

l Level

l Carpenters square

l Measuring tape

l Safety glasses

l Flashlight

For new installations only:

l Tubing cutter

l Drill and appropriate bits

l Hole saw set

Adjustable

Wrench

Safety Glasses

CAUTION:

PARTS SUPPLIED FOR INSTALLATION:

l Two Phillips head countertop mounting screws taped to dishwasher

Coupler

PREPARE DISHWASHER ENCLOSURE

• The rough cabinet opening must have a minimum width and

depth of 24", and approximately 34-1/2" high from floor to

underside of the countertop. Figure A

• The back wall should be free of pipes or wires. Figure A

• Adjacent cabinets should be square and plumb to ensure a

good fit. Figure A

• For corner installation, allow 2" min. clearance between

dishwasher and adjacent cabinet or wall or other

appliances. Figure B

• Make sure the floor is level inside the opening and even

with the finished floor of the kitchen.

• The dishwasher must be installed no more than 10 feet from

sink for proper drainage.

• This dishwasher must be fully enclosed on the top, sides

and back.

• The dishwasher must not support any part of the enclosure.

Figure B

CAUTION

An air gap MUST BE USED if the drain hose is connected to

waste tee or disposer lower than 18" above the floor level.

Failure to provide the proper drain connection height with air

gap or 32" minimum, high drain loop will result in improper

draining of the dishwasher which may cause damage.

PREPARE DRAIN PLUMBING

DRAIN REQUIREMENTS

• Follow local codes and ordinances.

• Dishwasher drain hose must not exceed 10 feet in length for

proper drainage.

• Dishwasher must be connected to waste line with an air

gap (not supplied) or 32" minimum, high drain loop depend-

ing on local codes and ordinances to prevent back flow into

the dishwasher.

• Air gap must be used if waste tee or disposer connection is

less than 18 inches above floor to prevent siphoning.

DRAIN PREPARATION

The type of drain installation depends on answers to the

following questions:

l Do local codes or ordinances require an air gap?

l Will waste tee or disposer connection be less than 18"

above floor?

l Will installation have a drain loop less than 32" above floor?

If the answer to of the 3 questions above is ANY YES, Method

1 MUST be used. Otherwise either Method 1 or Method 2 may

be used. Figure C or Figure D.

METHOD 1–Air Gap with Waste Tee or Disposer

Figure A

Install waste tee or disposer and air gap according to

manufacturer’s instructions.

CABINET PREPARATION

Drill 1-1/2" inch diameter hole in the cabinet wall within the

shaded area shown in Figure A for the drain hose. Make sure

there are no sharp edges. Drain hose will be passed through

this hole and connected to the drain in a later step.

Disposer Installation

METHOD 2–High Drain with Waste Tee or Disposer

Provide a method to attach drain hose to underside of

countertop. Attachment will be made in a later step.

Waste Tee Installation Figure C

Waste Tee Installation Disposer Installation

Figure D

25"

Countertop

Dishwasher

Clearance for Door

Opening 2" Minimum

24"

Min.

This Wall Area

must be Free of

Pipes or wires

Plumbing and Electric Service

Must Enter Inside This Area

34-1/2" 1/4"±

Underside of

Countertop

to Floor

24"

Min.

5" 5"

Cabinets Square

and Plumb

32"

Min.

18"

Min.

32"

Min.

18"

Min.
