Sida 1/32
Installation
Instructions
31-30246
10-08 JR
Built-In Dishwashers
*Custom front panel models include a kit that
contains a template, hardware and panel
installation instructions. Refer to the kit
instructions when installing the custom panel.
Safety Information
2
CONTENTS
Installation Preparation
Parts Supplied......................................................................................3
Materials You Will Need ..................................................................3
Tools You Will Need ..........................................................................3
Advance Planning ..............................................................................4
Prepare Dishwasher Enclosure....................................................4
Prepare Drain Plumbing..................................................................5
Prepare Electrical Wiring ................................................................6
Prepare Hot Water Line ..................................................................7
Installation Instructions
Step 1, Locate Installation Items ................................................7
Step 2, Install Trim Pieces ..............................................................7
Step 3, Check Door Balance..........................................................8
Step 4, Remove Wood Base, Install Leveling Legs ............8
Step 5, Remove ToeKick..................................................................8
Step 6, Remove ToeKick Brace ....................................................8
Step 7, Install Power Cord ..............................................................9
Step 8, Install 90° Elbow..................................................................9
Step 9, Position Water Line and Housing Wiring................9
Step 10, Install Drain Hose to Dishwasher Drain Port......9
Step 11, Insert Drain Hose Through Cabinet......................10
Step 12, Slide Dishwasher
Three-Fourths of the Way Into Cabinet................................10
Step 13, Slide Dishwasher Into Final Position ............10, 11
Step 14, Level Dishwasher ..........................................................11
Step 15, Secure Dishwasher
to Countertop or Cabinet ............................................................12
Step 16, Connect Water Supply ..............................................12
Step 17, Connect Drain Line ......................................................13
Step 18, Connect Power Supply ..............................................14
Step 19, Pretest Checklist ............................................................14
Step 20, Dishwasher Wet Test ..................................................15
Step 21, Set Water Hardness ....................................................15
Step 22, Install Sound Upgrade Kit if Equipped ................15
Step 23, Install ToeKick ..............................................Back Cover
Step 24, Literature........................................................Back Cover
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT —Save these instructions for
local inspector’s use. Observe all governing codes and
ordinances.
• —Note to Installer Be sure to leave these
instructions with the Consumer.
• —Note to Consumer Keep these instructions
with your Owner’s Manual for future reference.
• —Skill Level Installation of this dishwasher requires
basic mechanical and electrical skills. Proper
installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the GE Appliance Warranty.
•Completion Time — 1 to 3 Hours.
New installations require more time than replacement
installations.
• IMPORTANT —The dishwasher MUST
be installed to allow for future removal from
the enclosure if service is required.
•If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
FOR YOUR SAFETY
Read and observe all CAUTION and WARNINGS shown
throughout these instructions.
While performing installations described in this booklet,
gloves, safety glasses or goggles should be worn.
For Monogram local service in your area, 1.800.444.1845.
For Monogram parts and accessories, call 1.800.626.2002.
For Monogram parts and accessories in Canada,
call 1.800.561.3344.
TOOLS YOU WILL NEED:
• Phillips-head screwdriver
• 5/16" and 1/4" nutdriver
• 6" Adjustable wrench
• Level
• Carpenter's square
• Measuring tape
• Safety glasses
• Flashlight
• Bucket to catch water when flushing the line
• 15/16" socket (optional for skid removal)
• Gloves
For New Installations Only:
• Tubing cutter
• Drill and appropriate bits
• Hole saw set
MATERIALS YOU WILL NEED:
• Ferrule, compression nut and 90° Elbow (3/8" NPT
external thread on one end, opposite end sized to fit
water supply)
• Thread seal tape
• UL-Listed wire nuts (3)
Materials For New Installations Only:
• Air gap for drain hose, if required
• Waste tee for house plumbing, if applicable
• Electrical cable or power cord, if applicable
• Screw-type hose clamps
• Strain relief for electrical connection
• Hand shut-off valve
• Water line 3/8" min. copper
• Coupler for extending drain line, if applicable
• GPF10L 10' drain hose, if needed
PARTS SUPPLIED:
• Two #8-18 x 5/8" Phillips special-head
screws, to secure dishwasher to underside
of countertop or sides of cabinets.
• Junction box cover and #10-1/2" hex
head screw
• Side and top trim
• Sound upgrade kit (some models)
• Drain hose (78"), drain hose hanger
and hose clamp
• Literature, Product Samples
and/or coupons
• Hard water test strip
(Models with Bulk Dispenser)
Installation Preparation
3
Wire Nuts (3)
Hot Water Line
Screw-Type
Hose Clamps
Coupler
Hand
Shut-Off
Valve
#8 Phillips Special-Head
Screws 5/8" Long
Hole Saw Set
Measuring Tape
Tubing Cutter
Drill and Bits
Phillips-Head
Screwdriver
15/16" Socket
1/4" and 5/16"
Nutdriver
Safety Glasses
6" Adjustable
Wrench
Bucket
Flashlight
Gloves
Carpenter's
Square
Level
Thread
Seal Tape
GPF10L
10' Drain Hose
Air Gap
Strain Relief
Drain Hose (78")
Hose Clamp
90° Elbow, Ferrule and
Compression Nut
Electrical Cable
(or Power Cord, if applicable)
Waste Tee
Trim Pieces
#10 Hex Head
J-Box Screw
1/2" Long
Drain Hose Hanger
Hard Water Test Strip
(Models with Bulk Dispenser)
Sound Upgrade
Kit (Some Models)
Side Trim
Top Trim
Side Trim
Junction Box Cover
