Sida 1/12
Installation
Instructions
Built-In
Dishwasher
If you have questions, www.GEAppliances.comcall 800-GECARES or visit our website at:
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT – Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these instruc-
tions for the consumer’s and local inspector’s use.
• Note to Consumer – Keep these instructions with
your Owner’s Manual for future reference.
• Skill Level – Installation of this dishwasher requires
basic mechanical and electrical skills. Proper installa-
tion is the responsibility of the installer. Product failure
due to improper installation is not covered under the
GE Appliance Warranty.
• 1 to 3 Hours. Completion Time – New installations
require more time than replacement installations.
• IMPORTANT – The dishwasher MUST be
installed to allow for future removal from the enclo-
sure if service is required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual
for available custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions. While performing
installations described in this booklet, gloves, safety
glasses or goggles should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
1
Installation Preparation
2
PARTS SUPPLIED:
¨ Two #8 Phillips flat head wood screws, 5/8" long to
secure dishwasher to underside of countertop or to
side of cabinetry. (Taped to top or side of
dishwasher.)
¨ Side and top trim pieces
¨ 2 Side mounting brackets with 4 mounting screws
(for non-wood countertops) on some models
MATERIALS YOU WILL NEED :
¨ Ferrule, compression nut and 90 Elbow (3/8"NPT external°
thread on one end, opposite end sized to fit water supply)
¨ Thread seal tape
¨ UL Listed wire nuts (3)
Materials For New Installations Only:
¨ Air gap for drain hose, if required
¨ Waste tee for house plumbing, if applicable
¨ Electrical cable or power cord, if applicable
¨ Screw type hose clamps
¨ Strain relief for electrical connection.
¨ Hand shut-off valve (recommended)
¨ Water line 3/8" min. copper or 1/2" min. plastic
(plastic must be tested for temperature and pressure)
¨ Coupler for extending drain line, if applicable
TOOLS YOU WILL NEED:
¨ Phillips head screwdriver
¨ 5/16" and 1/4" nutdriver
¨ 6" Adjustable wrench
¨ Level
¨ Carpenters square
¨ Measuring tape
¨ Safety glasses
¨ Flashlight
¨ Bucket to catch water when flushing the line
¨ 15/16" socket (optional for skid removal)
¨ Gloves
For New Installations Only:
¨ Tubing cutter
¨ Drill and appropriate bits
¨ Hole saw set
90° Elbow,
Ferrule and
Compression Nut
Wire Nuts (3)
Waste Tee
Electrical Cable
(or Power Cord, if applicable)
Hot Water line
Screw Type
Hose Clamps
Coupler
Hand
Shut-Off
Valve Thread
Seal Tape
Trim Pieces
2 Wood Screws 4, #8 Pan head Phillips Screws
3/8" long for side mounting
(some models)
Air Gap
Hole Saw Set
Measuring Tape
Tubing Cutter
Drill and Bits
Phillips
Head
Screwdriver
15/16" Socket
1/4"
and 5/16"
Nutdriver
Safety Glasses
6" Adjustable
Wrench
Bucket
Flashlight
Gloves
Carpenters
Square
Strain Relief
Side Mounting Brackets
(some models)
Level
Installation Preparation
3
PREPARE DISHWASHER ENCLOSURE
• The rough cabinet opening must be at least 24" deep,
24" wide and approximately 34-1/2" high from floor to
underside of the countertop.
• The dishwasher must be installed so that drain hose is
no more than 10 feet in length for proper drainage.
• The dishwasher must be fully enclosed on the top,
sides and back, and must not support any part of the
enclosure.
CLEARANCES: When
installed into a corner,
allow 2" min. clearance
between dishwasher and
adjacent cabinet, wall or
other appliances. Allow
28-3/8" min. clearance
from the front of the
dishwasher for door
opening. Figure B
DRAIN REQUIREMENTS
• Follow local codes and ordinances.
• Do not exceed 10 feet distance to drain.
Note: This dishwasher is equipped with a high drain
loop. There is no minimum height required for drain
hose routing. However, 18" minimum from floor to
center of waste tee or disposer inlet is required. See
Figure D.
DETERMINE DRAIN METHOD
The type of drain installation depends on the following
question.
¨ Do local codes or ordinances require an air gap?
¨ Is waste tee less than 18" above floor?
If the answer to either question is YES, Method 1 MUST
be used.
• If the answers are NO, either method may be used.
CABINET PREPARATION
• Drill a 1-1/2" dia. hole in the cabinet wall within the
shaded areas shown in Figure A for the drain hose
connection. The hole should be smooth with no sharp
edges.
IMPORTANT: When connect-
ing drain line to disposer, check to
be sure that drain plug has been
removed. DISHWASHER WILL
NOT DRAIN IF PLUG IS LEFT IN PLACE.
Method 1 – Air Gap with Waste Tee or Disposer
An air gap must be used when required by local codes and ordinances.
The air gap must be installed according to manufacturers instructions.
Method 2 – Built-in “High Drain Loop” with Waste Tee or
Disposer
Figure A
Figure B
Figure C
Figure D
24"
Min.
This Wall Area
must be Free of
Pipes or wires
Plumbing and Electric Service
Must Enter Inside This Area
34-1/2" 1/4"±
Underside of
Countertop
to Floor
4"
24"
Min.
6"
5" 5"
4"
Cabinets
Square
and
Plumb
Floor MUST be Even
With Room Floor.
28-3/8"
Countertop
Dishwasher
Clearance for Door
Opening 2" Minimum
18"
Min.
18"
Min.
Remove
Hopper
Plug
