Genius DVR-HD550 Bruksanvisning
Läs nedan 📖 manual på svenska för Genius DVR-HD550 (11 sidor) i kategorin Dashcam. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/11
English
1
WEEE Warning Message
Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries:
z This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.
z For more information, contact the retailer or the local authorities in charge of waste management.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1). This device may not cause harmful interference, and
(2). This device must accept any interference received, including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you
could be required to stop operation of the equipment.
English
2
Software introduction
This DVR Player provides seamless DVR recordings for use with a PC application program (AP).
You do not need to install any program and you can quickly browse, playback or convert the
recorded video. Here are some of the features:
¾ Green Software: Do not need to install, but can be based on the language version of windows. It
will automatically display the language.
¾ Basic functions: Provides video of browsing, playback, speed switch and dump into AVI video or
JPG photo of the function.
¾ Password protected: You can set a password for the SD card to protect the SD card contents
from others.
¾ Video Repair: Can repair damaged video because of a suddenly pulled out card or power outage.
This can ensure that critical evidence is not lost.
How to use the Genius DVR Player
System Requirements
• CPU: At least Pentium 4 2.4GHz or above
• Monitor: Required to support 1280 x 720 or 1280 x 1024 resolution of the screen
• RAM: At least 1 GB of memory
• OS: Supports Windows XP, Windows Vista (32/64bit), and Windows 7 (32/64bit)
• Audio: System must have audio device installed
• USB 2.0 High Speed support of SD / SDHC card reader
Software Installation
• You do not need to install, you can execute the program directly, and the program can be
executed in the SD card (SD card cannot be write-protected).
• In Windows Vista and Windows 7, the exec. shall be the system administrator to open the normal
execution.
English
3
Software Interface Description
Image display area: Displays the current playback image.
➊Playback progress bar: Shows the progress of video playback, drag the mouse and you can
playback the video position where you want.
➋Video section list: Displays the current SD card list of all videos.
Videos in sections (Clip): Each section has a time listed when it started recording video
segments. The SD card will list all the video segments. You can choose the video you want to
view.
➌Video Groups List: The SD card shows the current group information list of all the videos.
A continuous video group can be shown in video segments. Any video longs than two seconds
is considered another group.
General continuous-time recording of the section will be treated as the same group, but there
are two circumstances would be regarded as another group:
NOTE
1. Each group will consist of video clips till the memory is full to 125MB.
2. Press the Lock button to protect the video and display in a group.
3. If you pull out the CD card or there is no power, or the battery does not work properly, the videos
damaged in the group will show and display in a red background. Damaged groups cannot be
played back for conversion without the use of "Repair "function. For "Repair Video" function, refer
to the button instructions.
Produktspecifikationer
| Varumärke: | Genius |
| Kategori: | Dashcam |
| Modell: | DVR-HD550 |
