Sida 1/13
SUMO 4192 - GZ-FS1CCA-ANS/ANB/ATS/ATB
SUMO 4198 - GZ-FS2CCA-AJS/AJB
SUMO 5115 - GZ-FA1CAR-AJS/AJB
English User's Manual
For SUMO Series
Thank you for purchasing a GIGABYTE
Chassis. GIGABYTE is dedicated to the
integration of casing water/air-cooling
solution technology to provide users with the
most optimal solution for thermal dissipation.
For further information and specifications of
the “SUMO” series, please visit GIGABYTE
website. (http://www.gigabyte.com.tw)
The following are not covered by the warranty:
1. Using the product incorrectly or in a manner other than the designed purpose.
2. Nonobservance of the proper operation provided.
3. Malfunction due to interference from other devices.
4. Unapproved modification of the product.
5. Consequential damage to other objects due to the product’s fault.
6. Malfunction arising from natural hazards, e.g. earthquake, lightning, fire, and floods.
7. The product’s warranty label has been removed or damaged.
8. The devices inside, including power supply, hard disk, CD-ROM drive, motherboard, ventila-
tor, etc, are not detached from the casing prior to transportation of the computer system,
resulting in damage to the casing or other computer-related devices.
9. Any loss/damage caused by failure to follow the installation process with in the user manual.
02 English
SUMO 4192 SUMO 4198 / SUMO 5115
Content
1. Components Introduction 4
1-1 Casing’s Internal Structure 4
1-2 Front, Rear, and Left Side Panel Structure 5
2. Features 6
3. Specifications 7
4. Installation Instruction 8
4-1 Installation of Power Supply 8
4-2 Installation of Motherboard 8
4-3 Installation of Add-On card 9
4-4 Installation of Front Multi-Media I/O Ports 9
4-5 Connection of Cooling Fan power lines 11
4-6 Installation of 5.25” Front Drive Bay 11
4-7 Installation of 3.5” Front Device Bay 11
4-8 Installation of 3.5” Internal Device Bay 11
4-9 Application of DIY Projector Bracket 12
4-10 Application of Security locks 12
4-11 Application of Foot Supports 12
4-12 Application of Liquid Cooling System 12
4-13 Recommended GIGABYTE Thermal Solution products 13
03
English
