Sida 1/28

Maxim-

GT3RS

Maxim-

GT4RB

Maxim4B-Island

Maxim-

GT4RSB

GT3RS

Lid Assembly P0014637FB 1

Temperature Gauge P00601484C 1

Lid Handle Seat (Left) P03303124A 1

Lid Handle Seat (Right) P03303125A 1

Lid Handle P00218012R 1

Lid Rubber Pad P05518002I 4

Bowl Panel, Left P00761164A 1

Bowl Panel, Right P00762154A 1

Bowl Grease Shield P06901030B 2

Knob Seat Spring P05504021A 3

Bowl Wind Shield P0071642UA 1

Gas Collector Box with Electrode P02609055A 2

Electric Wire Set P02615193A 1Set

Main Burner P02008085B 2

Bowl Panel, Front 1

Bowl Panel, Rear 1

Upper control Panel-30mbar 1

Upper control Panel-50mbar 1

Control Panel 1

Gas Valve Heat Shield P03007266G 1

Main Valve-without jet P03239012A 2

Manifold P05003302A 1

Gas Valve Heat Shield Bracket P03327107A 2

Control knob - main burner P03401477K 2

Knob Seat P03415014S 3

Side burner hose bracket P03341002Q 2

Electric Ignitor P02502244C 1

Grease Tray Handle P00213041M 1

Grease Tray Holder Bracket P03327114D 1

Grease Tray P0271784PD 1

Hotplate P05701049H 1

Crossfire box P022123984 1

Universal Hose Bar -1/4 LH inlet P03901024A 1

Warming Rack P01505032J 1

Quick connect with hose, male P03711041I 1

Side Shelf, Left P011020684 1

Cart Bracket, Front 1

Gas cylinder housing P04021013H 1

Side Shelf Lid P0011555E4 1

Side Shelf Pot Support P00815008A 1

Side Burner Mounting Brakcet P03327024D 1

Electrode- Side Burner P02607060C 1

Side Shelf Body P011030612 1

Side Burner P02004043F 1

Control Knob - side burner P03408101L 1

P03250007G 1

Side Shelf Trim Plate P011260244 1

Burner Bracket-Side Burner P03303150U 1

Adaptor-1/4 LH inlet 1

Valve- Side Burner

51 Trolley Panel, Left P07617052V 1

52 Trolley Panel, Right P07618055V 1

53 Trolley Panel, Rear 1

54 Door guid - uppere1

55 Door guid - lowereP05510143E 1

P05510144E

56 Trolley Bottom Panel 1

57 Door 1

58 Magnet seat P05523001K 2

59 2.5" caster P05118004A 4

Hardware Pack P06003196A 1

60 Tank holder P04009036C 2

61 Tank Fastening Strap P05314005V 1

62 Name plate 1

63 Searing Burner P02005032A 1

64 Searing Burner Heat Shield 1

65 Searing Valve-without jet 1

66 Quick connect , female P03912001A 1

67 Searing Burner Electrode P02614061A 1

68 Searing Burner Electrode Bracket P033271154 1

69 Control knob - Searing burner 1

Grill Plate P01615052H

P00407036A

P0076306GA

P0076022GA

P0291373FI

P0291373FJ

P02913956E

P03904002A

P06906096A

P032480095

P03436147A

P01001112Z

P043040192

P07702140R

P033010716

GT3RS
