INSTRUCTION MANUAL
Read understand and all of the instructions and safety
information in this manual before operating or servicing this tool.
Register this product at www.greenlee.com
52024555 REV 1 © 2009 Greenlee Textron Inc. 12/09
English .........1–16
Français .....17–32
Español.......33–48
Deutsch ......49–64
NC-500 NETcat® Pro Wiring Tester
2
Description
The NETcat® Pro wiring tester is a device that verifies twisted pair and coaxial cables. It uses
TDR technology to measure distance to fault and lengths of cable. It also has a feature that
enables detection of an active network device partner (PC/HUB).
Additional features include the following:
Employs touch panel LCD with contrast adjustment and backlight.•
Tests shielded twisted pair (STP), unshielded twisted pair (UTP), and coaxial cables.•
Measures cable length using TDR technology.•
Generates four different tones for cable tracing purpose.•
Identifies active network device (PC/HUB) on 10/100/1000 BaseT networks displaying •
device capabilities.
Indicates presence of a PoE (Power over Ethernet) source device.•
Verifies wiremaps.•
Detects shorts, opens, reversed polarity, crossed pairs, and split pairs.•
Uses remote ID units for Office Identification.•
Library with typical NVP values for common cables.•
Memo Pad feature for short notes or reminders.•
Safety
Safety is essential in the use and maintenance of Greenlee tools and equipment. This instruc-
tion manual and any markings on the tool provide information for avoiding hazards and
unsafe practices related to the use of this tool. Observe all of the safety information provided.
Purpose of This Manual
This instruction manual is intended to familiarize all personnel with the safe operation and
maintenance procedures for the Greenlee NC-500 NETcat
® Pro. Keep this manual available
to all personnel. Replacement manuals are available upon request at no charge
at www.greenlee.com.
NC-500 NETcat® Pro
3
Important Safety Information
SAFETY ALERT SYMBOL
This symbol is used to call your attention to hazards or unsafe practices which could
result in an injury or property damage. The signal word, defined below, indicates the
severity of the hazard. The message after the signal word provides information for
preventing or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result in severe injury or death.
Hazards which, if not avoided, COULD result in severe injury or death.
Hazards or unsafe practices which, if not avoided, MAY result in injury or property
damage.
KEEP THIS MANUAL
