Energy Storage System Operating Mode Setting
Global Leading Inverter Brand
1.33+million 200+ 70+ 100+
Inverter Ship Globally Professional R&D Engineers Patents and Copyrights Countries with Systems Installed
1、 Inverter Models
After TL-XH series connect with BDC, the time period of the BDC can be set.
The following models include in this series:
MIN 2500TL-XH MIN 3000TL-XH MIN 3600TL-XH MIN 、 、 、MIN 4200TL-XH、
4600TL-XH、MIN 5000TL-XH、MIN 6000TL-XH
Please make sure the inverter is the latest firmware version and is a single-phase
inverter model with RS485 port.
2、 Operating Mode Setting
The BDC time setting function enables the inverter to run different modes in different
time periods. The modes that can be set include: load first, battery first and grid first.
In the battery first mode, if you need to take power from the grid, please enable the grid
charging function in advance.
Note: When the BDC time is set, the start time of the latter period must be greater than the end time
of the previous period.
3、 Setting
Please ensure that the inverter and BDC communication are normal and in the on-grid
state. After set the BDC priority time period and enable the grid charging function, the
inverter will run continuously according to the set priority mode and time period. This
document describes four BDC time setting methods.
3.1. Setting through OLED
OLED
Touch
Button
instructions
The inverter can support multiple touch modes: single touch, two
consecutive touches, three consecutive touches, and long press 5S.
Different touch methods have different functions. Advanced setup
password: 123
Touch Methods Definition
Single Touch Move、page turning or number add 1
two consecutive touches Enter setting mode or confirm the setting
Three consecutive touches Return to the previous page
Long press 5S Data zeroing
Table.1. OLED Touch Button instructions
The OLED can only set three time periods, and the start time of the latter time period
must be greater than the end time of the previous time period.
First a single touch to enter the "Set Parameter" interface, select "Advanced " and enter
the password, press twice to enter the "Storage Setting", select "Time Period" to set the
BDC priority time period: first select the priority mode, Touch twice to enter the time
setting, select whether to enable the setting, and then touch twice to set successfully.
The schematic diagram of the OLED flow is as follows:
Time Period Loadprio 00-01
Time1: Disable
Loadprio 00-01
Time1: Disable
Batprio 00-01
Time1: Disable
Gridprio 00-01
Time1: Disable
Loadprio NN-01
Time1: Disable
Loadprio 00-01
Time1: Disable
Loadprio 00-NN
Time1: Disable
Loadprio 00-01
Time1: Disable
Loadprio 00-01
Time1: Enable
Multiple single
touch
Multiple single
touch
Multiple single
touch
Double touch Double touch Double touch
Double touch
Double touch
Double touchSingle touch
Single touch
Loadprio 00-01
Time2: Disable
Loadprio 00-01
Time2: Disable
Batprio 00-01
Time2: Disable
Gridprio 00-01
Time2: Disable
Loadprio NN-01
Time2: Disable
Loadprio 00-01
Time2: Disable
Loadprio 00-NN
Time2: Disable
Loadprio 00-01
Time2: Disable
Loadprio 00-01
Time2: Enable
Multiple single
touch
Multiple single
touch
Multiple single
touch
Double touch Double touch Double touch
Double touch
Double touchSingle touch
Single touch
Double touch
Loadprio 00-01
Time3: Disable
Loadprio 00-01
Time3: Disable
Batprio 00-01
Time3: Disable
Gridprio 00-01
Time3: Disable
Loadprio NN-01
Time3: Disable
Loadprio 00-01
Time3: Disable
Loadprio 00-NN
Time3: Disable
Loadprio 00-01
Time3: Disable
Loadprio 00-01
Time3: Enable
Multiple single
touch
Multiple single
touch Multiple single
touch
Double touch Double touch Double touch
Double touch
Double touchSingle touch
Single touch
Double touch
Strorage Setting
Password
123
General
Advanced
Country/Aera
VDE0126
Double touch
Double touch
Double touch
Set Parameter
Double touch
Figure.1. OLED Setting Flows
