Sida 1/2
13 5 789
246 10 11 12 13
GVM-SD80D
FacebookGVM Official
Website
Download APP
Web: www.gvmled.com
B&H Email: bh@gvmled.com
GVM Email: support@gvmled.com
Amazon Email: amazonsupport@gvmled.com
Warehouse Add: 4301 N Delaware ave, unit D. PHILADELPHIA, PA19137, USA
PRODUCT
INTRODUCTION
④ Can simulate 8 kinds of scene lights: Lightning, Flash, Candlelight, TV, Bad
Bulb, Explosion, Fireworks, Paparazzi
② In App control mode, you can easily control the light by your IOS and Android
intelligent mobile device. Meanwhile the light supports Bluetooth mesh
networking, and can be controlled in groups with GVM brand devices that
support mesh networking.
③ It has LCD display and a stable system, which supports multiple angels
rotation and can effectively control light. It is also equipped with a standard
lampshade. After installation, it makes the lighting become softer.
Customized control fills the light, allowing you to easily and easily shoot the
desired results.
We believe that once using our product correctly, you can make huge progress
when shooting. Before using the product, you are strongly recommended to
read the instructions below carefully.
Welcome to use “GVM-SD80D”, this product is specially designed for senior
photography enthusiasts. The product is suitable for live streaming / outdoor /
studio photography, and also for YouTube video shooting. The main features of
the product are:
① Stepless adjustable Lighting Effects, Brightness/CCT can be controlled at
will. The color temperature range is 2700K~7500K. There is a high color
render index CRI97+ COB lamp bead in the light. It helps to restore and
enrich the color of objects, providing you with natural and vivid shooting
effects.
DISCLAIMERS
3.Design and specifications are subject to change without notice.
2.Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.
1.Before using this product, please read the instructions carefully and make sure to use
the product correctly. If you don’t obey the instructions and warnings, you maybe
cause harm to yourself and the people around or even damage the product and other
things around.
USE AND PRESERVATION
Do not put the light in a highly humid, strong electromagnetic field, direct
sunlight, high-temperature environment. If the light is not use for a long time,
please disconnect the power.
Guarantee: Do does not modify the product, or you will lose the right of
maintenance.
Clean: Before cleaning,please unplug the power plug. And use wet cloth
rather than any detergent or soluble liquid, avoiding damaging the surface
layer.
Power: Make sure the power is in the demanded range, not too high or too
low. Correctly load the battery, in order not the damage to the machine.
Accessories: Please use the accessories provided by the manufacturer and
approved ones, in order to maximize the performance.
Repairing: If there is fault or performance degradation, do not unpack the
shell by yourself, avoiding damage to the machine and lose the right of
maintenance. When there is a fault, do not hesitate to contact us, and we will
do our best to deal with the problem.
PRODUCT
PARAMETER
Brand : GVM
Product Name : Photography lights
Product model : GVM-SD80D
Product Type : Photography Fill Light
Functions/features : LCD screen, high display COB lamp beads,
APP control, MESH networking
Lamp beads quantity : COB×1
Color rendering index : ≥97
Color temperature : 2700K-7500K
Lumen : 11300lux/0.5m, 2860lux/1m
Light adjustment method : Stepless adjustment
Power : 80W
Voltage : AC 100-240V
Power supply mode : DC & Battery
Power supply : DC:15V7A
Battery type : NP series battery (need to buy separately)
Product Weight : 1.2 KG
Product Size (mm) : 153×122×223
Cooling : Fan forced cooling
Product material : Aluminum alloy + plastic
Commodity origin : Huizhou, China
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
PRODUCT
STRUCTURE ANALYSIS
Fixture handle
for light stand
COB lamp bead
Bowens Mount
Angle fixed handle
Bayonet
Light stand interface
LCD display
Compound knob
Composite button
Switch ON/OFF
Power input port
Battery compartment
INSTALLATION METHOD
1Rotate the lamp holder fixing handle clockwise to install and fix the lamp
on the bracket, and turn it counterclockwise to unload.
2Loosen the angle fixing handle, adjust the angle of the spotlight you
need, and then tighten the angle fixing handle.
3Insert the Bowens Mount of the standard cover into the Bowens Mount of
the lamp correspondingly, and then turn it slightly clockwise to install the
standard cover on the light. Push the Bowens Mount removal buckle to
the upper right and turn the standard cover counter clockwise to remove
the standard cover.
4Connect the power cord to supply power.
5
(Battery needed to buy separately)
Outdoor using can be powered by a suitable battery. DESCRIPTION OF PRODUCT
CONTROL KEYS
54
FX/ BT-R E SE T
IN T/S ELE CTO R
DC I N
1 23
1Power input interface
2Switch:
Turn the switch to the position, the
video light uses the DC input power
supply;
Turn the switch to the position, and
the video light uses battery power.
3Composite Knob: INT/SELECTOR:
1. Rotate the encoder to adjust the parameters of the corresponding item;
2. In white light adjustment brightness, short press the knob to quickly
change the brightness; in FX light effect mode, short press the knob to
switch the light effect type;
3. Press and hold for 2 seconds to release, switch the knob adjustment
items:
In CCT mode, switch to adjust the brightness and color temperature of
white light;
In light effect mode, switch to adjust the brightness, rate, color
temperature of the light effect.
4
1.Short press and release to enter
light effect mode or return to white
light mode;
Composite button: FX/BT-RESET:
2.Press and hold for 2 seconds to
release, reset Bluetooth;
3.Press and hold the button for 10
seconds and release it to restore the
system default settings.
5LCD display: can display the current mode and parameters of the lamp
FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
① LCD Display:
Displays the current brightness, light mode, light parameters, and scene
number of the light.
SC:
APP
K
ms
CCT:
TIM:
Light effect scene display
Brightness
percentage display
CCT regulation status /
light efficiency rate
regulation status
Mobile APP operation status
(disappe ars aft er 5 seconds of
no ope ration when connected
to the APP)
Color temperature parameter
adjustment / light effect rate
parameter adjustment
② Adjust brightness (INTENSITY): Range 0%~100%
·In white light mode, short press the composite knob to quickly change the
brightness.
·Press and hold the compound knob for 2 seconds and then release it to
switch to brightness adjustment, rotate the compound knob to adjust the
brightness.
·In APP mode, connect to the APP and adjust the brightness through the
APP.
③ Adjustable color temperature (CCT): Range 2700K~7500K
·Press and hold the compound knob for 2 seconds and release it to switch to
color temperature adjustment. Rotate the compound knob to adjust the
color temperature.
·In the APP mode, connect to the APP and adjust the brightness through the
APP.
④ Adjust Scene Light Effect (SC): Range 1~8
·The scene mode has 8 scenes:
·Short press the compound button to switch the light mode to light effect
mode → long press the compound knob for 2 seconds and release it to
switch the light effect brightness and light effect rate adjustment items →
rotate the compound knob to select the scene mode and adjust parameters
such as brightness, color temperature, time, etc.
·In light effect mode, short press the composite knob to quickly change the
scene.
·In APP mode, connect to the APP and adjust the scene through the APP.
1 - Lightning, 2 - CCT Loop, 3 - Candle, 4 - Bad Bulb, 5 - TV, 6 - Paparazzi,
7 - Explosion, 8 - Breathing Light
APP CONTROL
Figure 1
Figure 2
Figure 3
Figure 4
APP download method
(Scan the QR code on the back of the manual to download the APP)
iOS version: App Store
Android version: Official website QR code, Google
Play, Huawei Store, etc.
Register an account
There may be a delay in sending the verification code,
and the speed of delivery depends on the email server
you use;
Log in after registering with your email (Figure 1);
Some email servers may recognize our verification
emails as advertising, please check your blocked
email inbox.
Add device
* Android system requires location permission to be enabled
to connect devices using Mesh technology, we will not
collect any location information from you during this
process.
② On the "My Devices" page, click the "Add Device"
button to search for nearby Bluetooth lighting
devices that have been turned on, and select the
device to be connected for network connection.
(Figure 2)
① Before adding a device, please make sure that you
have turned on the Bluetooth and network data
functions of your mobile phone, and reset the
Bluetooth of the lighting device;
Device management
① After successfully adding your
l i g h t i n g e q u i p m en t , y o u r
equipment will be displayed in
the "My Equipment" list;
(Figure 3)
② Click the device bar to enter the
device control. (Figure 4)
PRECAUTIONS
② The video light is not waterproof, please use it in a rain-proof environment.
③ The video light is not anti-corrosion, please don’t let the light come into contact with
any corrosive liquid.
① Please use the matching power adapter to power the product, do not use the power
adapter with different output voltage parameters to light the product;
⑤ When the light is not used for a long time, please turn off the power of it to save energy
consumption.
④ When you use the light, make sure that the light is placed firmly to prevent the it from
falling and being damaged.
When the temperature exceeds the set protection temperature, the over temperature
protection program is executed, the brightness is reduced to 10%, and flashes at a
frequency of 1 second, that is, on for 1 second and off for 1 second.
⑥ Over temperature protection reminder:
SIMPLE FAULTS AND
TROUBLESHOOTING METHODS
Errors Check the product Troubleshoot
Turn on light is
off
Whether the connection between
the lamp and the power supply is
normal.
Make sure the adapter plug is
making good contact
When using lithium battery for
power supply, make sure that the
batte ry does not hav e "lo w
power" protection.
U s i n g t h e p r o d u c t a f t e r
charging the battery
After the App
enters the Add
Device, the
device Bluetooth
cannot be
searched
Check whether the device is
turned on normally and whether it
has been bound by others.
Normal steps:
②Reset the device Bluetooth.
①The mobile phone has the
Bluetooth and network data
functions enabled, and the
Android system needs to
e n a b l e t h e l o c a t i o n
permission;
App failed to
connect to the
device network
Check whether the device is
turned on normally and whether it
has been bound by others; check
wh e t h e r th e B l ue t oo t h an d
network conditions of the mobile
phone are in good condition.
Retry the connection after
resetting the device Bluetooth
and restarting the app.
The device
cannot be
searched after
being removed
from the app
Whether to remove the device
when the device is offline or in
poor network conditions.
After resetting the device's
Bluetooth, search again to add
the device.
The device click
in the APP
cannot enter the
control
Check if the device is online (a
small green dot is displayed); if it
is offline, follow the steps of the
network connection failure step to
check.
Restart the device, wait for 5
seconds, it can be controlled
when it is displayed as online;
reset the device's Bluetooth,
and add the device to the
device list again.
PACKAGE LIST
Name
Quantity
Notes
GVM-
SD80D
Photography light 1
Power Cable 1
Adapter 1
Diffuser 1
Instruction 1
Product introduction ------------------------------------------- Page 1
Disclaimers -------------------------------------------------------- Page 2
Use and preservation ------------------------------------------ Page 2
Product parameter --------------------------------------------- Page 3
Product structure analysis ------------------------------------ Page 4
Installation method ------------------------------------------ Page 5~7
Description of product control keys ----------------------- Page 8
Function introduction & instruction for use --------- Page 9~10
APP control ------------------------------------------------- Page 10~11
Simple faults and troubleshooting ------------------------ Page 12
Packing list ------------------------------------------------------- Page 13
Precautions ------------------------------------------------------ Page 13
C O N T E N T S

Produktspecifikationer

Varumärke: GVM
Kategori: Lättnad
Modell: SD80S

Behöver du hjälp?

Om du behöver hjälp med GVM SD80S ställ en fråga nedan och andra användare kommer att svara dig


Lättnad GVM Manualer

GVM

GVM SD80S Bruksanvisning

11 December 2024
GVM

GVM 520LS-R Bruksanvisning

11 December 2024
GVM

GVM PRO-SD200B Bruksanvisning

5 December 2024
GVM

GVM YU200R Bruksanvisning

23 September 2024
GVM

GVM SD80D Bruksanvisning

23 September 2024
GVM

GVM SD300D Bruksanvisning

22 September 2024
GVM

GVM SD300S Bruksanvisning

22 September 2024
GVM

GVM B200C Bruksanvisning

22 September 2024
GVM

GVM PR150D Bruksanvisning

22 September 2024
GVM

GVM -PRO-SD300C Bruksanvisning

22 September 2024

Lättnad Manualer

Nyaste Lättnad Manualer

Angler

Angler BI-90W-RL Bruksanvisning

11 December 2024
Angler

Angler Sparta 865BLED Bruksanvisning

11 December 2024
Angler

Angler Beauty Flex FTS-11B Bruksanvisning

11 December 2024
Angler

Angler BI-45W-RL Bruksanvisning

11 December 2024
LUPO

LUPO DayledPRO Dual Color 650 Bruksanvisning

11 December 2024
Raya

Raya SDR-400 Bruksanvisning

11 December 2024
Dracast

Dracast LED1500 Bruksanvisning

11 December 2024
Dracast

Dracast LED1000 Pro Bruksanvisning

11 December 2024
Dracast

Dracast Kala Plus LED3000 Bruksanvisning

11 December 2024
Dracast

Dracast Kala Plus LED1000 Bruksanvisning

11 December 2024
