Sida 1/61

Audio/video receiver

AVR 3650, AVR 365

AVR 2650, AVR 265

Owner’s Manual

Table of Contents

INTRODUCTION 3

SUPPLIED ACCESSORIES 3

IMPORTANT SAFETY INFORMATION 3

PLACE THE RECEIVER 3

FRONT-PANEL CONTROLS 4

REAR-PANEL CONNECTORS 6

SYSTEM REMOTE CONTROL FUNCTIONS 8

ZONE 2 REMOTE CONTROL FUNCTIONS

(AVR 3650/AVR 365 ONLY) 10

INTRODUCTION TO HOME THEATER 12

TYPICAL HOME THEATER SYSTEM 12

MULTICHANNEL AUDIO 12

SURROUND MODES 12

PLACE YOUR SPEAKERS 13

PLACING THE LEFT, CENTER AND RIGHT SPEAKERS 13

PLACING THE SURROUND SPEAKERS IN A

5.1-CHANNEL SYSTEM 13

PLACING THE SURROUND SPEAKERS IN A

7.1-CHANNEL SYSTEM 13

PLACING FRONT HEIGHT SPEAKERS IN A

7.1-CHANNEL SYSTEM 13

PLACING THE SUBWOOFER 13

TYPES OF HOME THEATER SYSTEM CONNECTIONS 14

SPEAKER CONNECTIONS 14

SUBWOOFER CONNECTIONS 14

SOURCE DEVICE CONNECTIONS 14

VIDEO CONNECTIONS 15

RADIO CONNECTIONS 16

NETWORK CONNECTOR 16

USB PORT 16

RS-232 CONNECTOR 16

MAKING CONNECTIONS 17

CONNECT YOUR SPEAKERS 17

CONNECT YOUR SUBWOOFER 17

CONNECT YOUR TV OR VIDEO DISPLAY 17

CONNECT YOUR AUDIO AND VIDEO SOURCE DEVICES 18

CONNECT THE BRIDGE IIIP 20

CONNECT TO YOUR HOME NETWORK 20

CONNECT THE RADIO ANTENNAS 20

INSTALL A MULTIZONE SYSTEM 21

CONNECT IR EQUIPMENT (AVR 3650/AVR 365 ONLY) 22

CONNECT THE 12V TRIGGER OUTPUT 23

CONNECT TO AC POWER 23

SET UP THE REMOTE CONTROL 23

INSTALL THE BATTERIES IN THE REMOTE CONTROL 23

PROGRAM THE REMOTE TO CONTROL

YOUR SOURCE DEVICES AND TV 23

SET UP THE AVR 25

TURN ON THE AVR 25

USING THE ON-SCREEN MENU SYSTEM 25

CONFIGURE THE AVR FOR YOUR SPEAKERS 25

SET UP YOUR SOURCES 26

SET UP THE NETWORK 27

OPERATING YOUR AVR 28

CONTROLLING THE VOLUME 28

MUTING THE SOUND 28

DOLBY® VOLUME 28

LISTENING THROUGH HEADPHONES 28

SELECTING A SOURCE 28

LISTENING TO FM AND AM RADIO 29

LISTENING TO SIRIUS® SATELLITE RADIO 29

LISTENING TO MEDIA ON A USB DEVICE

(AVR 3650/AVR 365) 30

LISTENING TO AN iPod/iPhone DEVICE 30

LISTENING TO INTERNET RADIO 31

LISTENING TO MEDIA VIA YOUR HOME NETWORK 32

SELECTING A SURROUND MODE 32

AUDIO EFFECTS 32

VIDEO MODES 32

ADVANCED FUNCTIONS 33

AUDIO PROCESSING AND SURROUND SOUND 33

VIDEO PROCESSING 34

MANUAL SPEAKER SETUP 36

LISTENING IN ZONE 2 39

SYSTEM SETTINGS 39

SETTINGS LOCK 40

ADVANCED REMOTE CONTROL PROGRAMMING 41

RECORDING 41

SLEEP TIMER 41

RESETTING THE REMOTE 42

PROCESSOR RESET 42

TROUBLESHOOTING 43

SPECIFICATIONS 44

APPENDIX 45

Introduction, Supplied Accessories,

Important Safety Information and Place the Receiver

AVR

Introduction

Thank you for choosing this Harman Kardon product!

For more than ﬁfty years, the Harman Kardon mission has been to share a passion for music

and entertainment, using leading-edge technology to achieve premium performance.

Sidney Harman and Bernard Kardon invented the receiver, a single component designed

to simplify home entertainment without compromising performance. Over the years,

Harman Kardon products have become easier to use, while offering more features and

sounding better than ever.

The AVR 3650, AVR 2650, AVR 365 and AVR 265 7.1-channel digital audio/video receivers

continue this tradition with some of the most advanced audio and video processing

capabilities yet, and a wealth of listening and viewing options.

To obtain the maximum enjoyment from your new receiver, please read this manual

and refer back to it as you become more familiar with its features and their operation.

If you have any questions about this product, its installation or its operation, please

contact your Harman Kardon retailer or custom installer, or visit the Web site at

www.harmankardon.com.

Supplied Accessories

The following accessory items are supplied with your receiver. If any of these items are

missing, please contact your Harman Kardon dealer or Harman Kardon customer service

at www.harmankardon.com.

• System remote control

• Zone 2 remote control (AVR 3650/AVR 365 only)

• EzSet/EQ™ microphone

• AM loop antenna

• FM wire antenna

• Six AAA batteries (AVR 3650/AVR 365); four AAA batteries (AVR 2650/AVR 265)

• AC power cord

IMPORTANT SAFETY INFORMATION

Verify Line Voltage Before Use

The AVR 3650 and AVR 2650 have been designed for use with 120-volt AC current.

The AVR 365 and AVR 265 have been designed for use with 220 – 240-volt AC current.

Connection to a line voltage other than that for which your receiver is intended can

create a safety and ﬁre hazard and may damage the unit. If you have any questions

about the voltage requirements for your speciﬁc model, or about the line voltage in your

area, contact your selling dealer before plugging the unit into a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord supplied with your unit. We do not

recommend that extension cords be used with this product. As with all electrical

devices, do not run power cords under rugs or carpets, or place heavy objects on them.

Damaged power cords should be replaced immediately by an authorized service center

with a cord meeting factory speciﬁcations.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always pull the plug; never pull

the cord. If you do not intend to use your receiver for any considerable length of time,

disconnect the plug from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product. Opening the cabinet may

present a shock hazard, and any modiﬁcation to the product will void your warranty.

If water or any metal object such as a paper clip, wire or staple accidentally falls inside

the unit, disconnect it from the AC power source immediately, and consult an authorized

service center.

CATV or Antenna Grounding (AVR 3650/AVR 2650)

If an outside antenna or cable system is connected to this product, be certain that it is

grounded so as to provide some protection against voltage surges and static charges.

Section 810 of the United States National Electrical Code, ANSI/NFPA No. 70-1984,

provides information with respect to proper grounding of the mast and supporting

structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding

conductors, location of antenna discharge unit, connection to grounding electrodes and

requirements of the grounding electrode.

NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (cable TV)

system installer’s attention to article 820-40 of the NEC, which provides guidelines for

proper grounding and, in particular, speciﬁes that the cable ground shall be connected

to the grounding system of the building, as close to the point of cable entry as possible.

Place the Receiver

• Place the receiver on a ﬁrm and level surface. Be certain that the surface and any

mounting hardware can support the AVR’s weight.

• Provide proper space above and below the receiver for ventilation. If you install the

receiver in a cabinet or other enclosed area, provide cooling air within the cabinet.

Under some circumstances, a fan may be required.

• Do not obstruct the ventilation slots on the top of the receiver or place objects directly

over them.

• Do not place the receiver directly on a carpeted surface.

• Do not place the receiver in moist or humid locations, in extremely hot or cold locations,

in areas near heaters or heat registers, or in direct sunlight.
