FROM SERIAL NO: 397S001001, 398S001001, 399S001001 HANDBOOK: 397011 (Rev.0)
ISSUE 6.07.99
CODE
397S . 398S . 399S
(Push) (Auto Drive) (Auto Drive)
4 Speed
RANGER
OWNER'S HANDBOOK
CERTIFICATE OF CONFORMITY
I, the undersigned M.A. Wright, of:
HAYTER LIMITED, Spellbrook, Bishop’s Stortford
Herts CM23 4BU
ENGLAND
certify that the lawnmowers:
CODE 397S CODE 398S CODE 399S
1. Machine Type No. 397S 398S 399S
2. Category. Combustion Engine Combustion Engine Combustion Engine
3. Make. Hayter Hayter Hayter
4. Type. Rotary Rotary Rotary
5. Engine - Manufacturer. Briggs & Stratton Briggs & Stratton Briggs & Stratton
- Type. 127802-1592-21 127802-1592-21 127802-1592-21
- Speed of rotation during test. 2830rpm 2830rpm 3000rpm
Conforms to the specifications of Directive 84/538/EEC as adapted to technical
progress by Directive 87/252/EEC and amended by Directive 88/180/EEC.
Guaranteed maximum sound power level. 96dB(A) 96dB(A) 100dB(A)
- Type of cutting device Cutterbar Cutterbar Cutterbar
- Width of cutting device 48cm 48cm 53cm
- Speed of rotation of the cutting device 2830 rpm 2830 rpm 3000 rpm
TESTED AT SUDBURY, 26/01/99 26/01/99 26/01/99
SUFFOLK, ENGLAND
M.A. Wright
(Technical Director)
Signed
EC DECLARATION OF CONFORMITY
Company Name HAYTER LIMITED
Company Address Spellbrook
Bishop’s Stortford
Herts. CM23 4BU
ENGLAND
Machine Type No.. Code 397S Code 398S Code 399S
Models
Directives complied with: 98/37/EC.
Essential Health & Safety Requirements Relating to the Design & Construction of Machinery
and Safety Components.
84/538/EEC amended by 87/252/EEC and 88/180EEC Permissible Sound Power Levels of Lawn Mowers
89/336/EEC amended by 92/31/EEC Electromagnetic Compatibility
Standards Used: EN292, EN836, and ENIS0 14982.
I declare on behalf of Hayter Limited that these machines conform to the EC Essential Health & Safety
Requirements.
Date: 6.07.99
M.A. Wright
(Technical Director)
Signed
VIBRATION INFORMATION
Lawnmower vibration information. RMS acceleration measured in 3 - axes at operators contact position on the
handlebars. CODE 397S, 398S = 6.8ms-2 CODE 399s = 7.3 -2
1.11.1 CONTENTS
Page No.
CONTENTS
INTRODUCTION.
WARRANTY.
SAFETY PRECAUTIONS.
Decals
SPECIFICATIONS.
ASSEMBLY INSTRUCTIONS.
General Assembly.
Assembling the Mower for the First Time.
STARTING THE ENGINE.
Before Starting the Engine.
To Start the Engine.
STOPPING THE ENGINE.
OPERATING THE MOWER.
Height of Cut.
Travel.
Turning the Mower.
Mowing with Grass Collection.
Mowing without Grass Collection.
Heavy Growth.
Moving the Mower Across Non-Grassed Areas.
Cutterbar Operation.
Mowing and Grass Care Tips.
MAINTENANCE.
Engine.
Oil Service
Air Cleaner Service
Grassbag
Deck Housing
Securing Nuts and Bolts
Lubrication
Speed Change Cable
Clutch Cable Adjustment
Cutterbar
Maintenance Schedule
- After First 5 Hours
- Every 5 Hours or Daily
- Every 25 Hours or Every Season
- Every 50 Hours or Every Season
- Every 100 Hours or Every Season
1.3
1.4
1.5 - 1.8
1.8
1.9
1.10 - 1.12
1.10
1.11 - 1.12
1.13 - 1.14
1.13 - 1.14
1.14
1.15
1.16 - 1.21
1.16
1.17
1.17
1.18
1.19
1.19
1.19
1.20
1.20 - 1.21
1.22 - 1.29
1.22
1.23
1.24
1.24
1.24
1.25
1.25
1.25
1.26
1.26 - 1.27
1.28 - 1.29
1.28
1.28
1.28
1.29
1.29
397011MA260599A
