Sida 1/16

Product Manual

H E AT S T R I P ® E l e c t r i c I N T E N S E

H e a t e r s

Innovative, High Performance Electric Heating Technology

Features & Benefits

High Output radiant heat

HEATSTRIP® electric radiant heaters produce radiant heat that travels through the air directly to people and surfaces Intense

below – similar to the heat rays emitted by the Sun. Radiant heating is the only viable option for outdoor or tough indoor sites.

Maximum heat performance – multiple applications

The high temperature output of the HEATSTRIP

® is perfect for exposed outdoor sites, high ceilings and hard heat Intense -to-

indoor and outdoor applications.

Suitable for permanent outdoor mounting, no protection needed.

For outdoor applications, the HEATSTRIP® is suitable for both permanently exposed (eg. courtyards and patios) and Intense

undercover installations does not need to be fully protected from the elements.-

Corrosion protection

Built from corrosion resistant alloy, it is suitable for use in most applications, including difficult corrosive environments ch as su

coastal areas.

Multi Purpose Mounting Options-

The HEATSTRIP® is supplied with flexible mounting options. The standard bracket will allow both ceiling and wall Intense

mounting, at various angles, as well as suspension by chains/wires and metal rods.

DIY

The THY2200 & THY2200W is supplied with a lead and plug, and is therefore ideal for DIY installations with brackets included.

Element

Carbon filament infra red heating element provides high performance instant heat.-

Warranty

2–year residential and 1 year commercial warranty. -

Material & Design

Anodised alloy casing and end caps with a powder coat hexagon grille. Available in both a black and off white colour. -

Specifications Australia-

MODEL POWER

(WATTS)

CURRENT

(AMPS)

DIMENSIONS

(mm)

WEIGHT

(Kg)

LEAD

LENGTH

(mm)

PLUG COLOUR

THY2200 9.2 1068 x 120 x 90 6 YES Black 2200 1000

THY3200 13.3 1270 x 120 x 90 7 Black 3200 1000 NO

THY2200W 9.2 1068 x 120 x 90 6 YES Off White 2200 1000 -

THY3200W 13.3 1270 x 120 x 90 7 Off White 3200 1000 NO -

MODEL

HEATER TYPE High intensity electric radiant, infra red overheat heater with carbon filament -

element.

OUTPUT 2200 watts or 3200 watts

POWER 240 Volts Nominal at — Hertz, Single Phase 230-50 60

CONNECTION 3 Core Cable 2.5mm 2

APPROVALS AUSTRALIA / NZ / EU

MOUNTING HEIGHT MINIMUM

RECOMMENDED

MAXIMUM

2.1 m

2.3 m 2.5 m -

2.8m Outdoors and 3m Indoors

(For higher ceiling heights, units can be

lowered using optional brackets kits)

MOUNTING OPTIONS

Suitable for ceiling, wall, and beam mounting as well as suspension by chains &

wires using standard brackets. Optional mounting accessories include extension

mount poles and flush ceiling mount kit.

PROTECTION RATING IPX5 Protection from water ingress from all directions

MATERIALS OF CONSTRUCTION Anodised alloy casing and end caps with powder coat grille (THY2200 & THY3200)

Anodised alloy with high temperature Off White ceramic coating (THY2200W & -

THY3200W).

THY2200 & THY2200W THY3200 & THY3200W
