Sida 1/12
1
HA BRITSTIP QUICK START GUIDE
This is a quick start guide on using the HA BRITSTRIP. For more info on it or
more tips on how to use the unit, please check www.heritageaudio.net often,
and make sure to follow Heritage Audio on Facebook, Instagram and You
Tube.
Dec 14th, 2020
Rev. 1.0.
INSTALLING THE BRITSTRIP
Thanks for purchasing the HA BRITSTRIP Channel Strip. Please make sure the
following items are in the box when you open it.
2
• This manual.
• HA BRITSTRIP main unit.
• Power Supply labelled HA-PSU03.
• IEC Cable.
Depending on your system requirements, you will need several XLR and
MONO jack cables to hook up your system. Please check your input sources
and output destinations and purchase the correct cables.
The power supply is of the auto switching type so it works worldwide without
adjusting anything. In case your country uses a different mains cable other
than the one provided in the box, just get the correct one and you are done.
Basic audio connections are just balanced input and output connections by
means of XLR.
In case you want to make use of the external sidechain facilities, additional
MONO Jack cables are needed as explained below:
If you want to be able to trigger the BRITSTRIP Successor-like detector with
an external signal, a MONO jack is needed. If, in addition to this, you want to
be able to further externally process the internal detector signal and return it
into the unit, another additional MONO jack is needed.
In case you have TRS JACKS instead of MONO (TS) ones, those are compatible
as well, but keep in mind that the signals are unbalanced.
The HA BRITSTRIP is able to accept input levels in excess of those that any
interface can provide, so the chance that its input is overloaded is rare.
However, it is able to provide output levels in excess of those that most
interfaces can accept, so please keep this in mind.
3
GENERAL DESCRIPTION
The Heritage Audio BRITSTRIP is a professional channel strip comprising a 73
preamplifier, DI, equalizer and diode bridge based dynamics processor - in a
convenient 1 RU format. It features transformer balanced inputs and outputs,
and the outputs are driven by means of 73 type Class A amplifiers.
The signal path consists of:
- Preamplifier, being it the mic, line or instrument preamp.
- Equalizer.
- Compressor.
- Output stage.
The DI input is ahead of the mic preamp. The equalizer can be placed before
or after the compressor. With these possible exceptions, the signal flows in
the aforementioned order. Keep this in mind when setting the individual
block´s levels for optimum headroom.
THE PREAMPLIFIER:
First thing to set is the correct input source, being MIC the default one.
Inserting a mono jack into the DI input will automatically detect it and switch
it to DI (green LED on). Pressing LINE will switch the pre to the LINE input XLR
on the back.
When in MIC mode, the PAD, 48v and LOZ buttons can be operated. Use the
PAD for higher headroom when using hot microphones and/or loud sources.
The LOZ will lower the input impedance from 1200 to 300 ohms, great to get
6 noise free dBs of gain when using low impedance mics such as
transformerless condensers. Using the LOZ setting will also darken vintage
ribbon and dynamic mics. Use it to taste.
