PREFACE
Thank you for selecting a Hero MotoCorp MAESTRO EDGE 125 PROGRAMMED FI
vehicle. We wish you many miles of continued riding pleasure in the years ahead.
We, at , are committed to demonstrate excellence in our environment Hero MotoCorp
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with all applicable legislation including environment legislation and
strengthen the green supply chain.
Your vehicle is conforming to latest (Bharat stage- I norms) regulation for emission, safety & V
noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are
environment friendly in nature.
This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature
is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of
India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in
conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when
the engine gets ON.
This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp MAESTRO EDGE 125 PROGRAMMED FI vehicle. Please take time to
read it carefully. As with any fine machine, proper care and maintenance is essential for
trouble-free operation and optimum performance.
Your Authorised dealer will be glad to provide further information or Hero MotoCorp
assistance and is equipped to handle your future service needs.
Let us make this world a safer, healthier and more environment friendly place.
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
NOTE
ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT
IS OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS
COULD LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT
NOTICE. ‘MAESTRO EDGE 125 PROGRAMMED FI’ Hero MotoCorp Ltd
COMPLIES WITH THE LATEST EMISSION NORMS.
CONTENTS
Pg. No.Pg. No.
BODY PARTS REMOVAL 53
•Center compartment 53
•Body cover 53
•Front center cover 57
•Front cover 58
•Floor side cover 59
•Rear view mirror/Headlamp assembly 60
•Headlamp focus adjustment 62
PRE-RIDE INSPECTION 62
ANTI-THEFT TIPS 63
STARTING THE ENGINE 64
RUNNING IN 66
RIDING 66
PARKING 70
TOOL KIT/FIRST AID KIT 71
CLEANING OF VEHICLE/WASHING OF VEHICLE 71
MAINTENANCE 73
SAFETY PRECAUTIONS 74
MAINTENANCE SCHEDULE 75
AIR CLEANER ELEMENT 78
THROTTLE OPERATION 80
AIR CLEANER DRAIN TUBE CLEANING 81
ENGINE OIL 81
FINAL DRIVE OIL REPLACEMENT 83
SPARK PLUG 84
BRAKE SHOE WEAR/BATTERY 85
FUSE REPLACEMENT 87
SUSPENSION/BULB/LED REPLACEMENT 88
CATALYTIC CONVERTER 90
EVAPORATIVE EMISSION CONTROL SYSTEM 91
POLISHING OF VEHICLE 91
REMOVING ROAD SALT 92
STORAGE GUIDE 92
BASIC TROUBLESHOOTING 93
ROAD SIGNS 97
NAVIGATION SIGNS 99
WARRANTY DETAILS
HERO GENUINE PARTS
ZONAL/REGIONAL/AREA OFFICES
VEHICLE IDENTIFICATION 1
VEHICLE SPECIFICATION 2
VEHICLE SAFETY 4
•Important safety information 4
•Protective apparel 5
•Load limits and guidelines 7
•Accessories and modifications 8
SAFE RIDING TIPS 9
TIPS FOR HEALTHY ENVIRONMENT 10
VEHICLE VIEWS 11
PARTS FUNCTION 14
•Instruments and indicators 14
•LCD panel 16
•Keys 21
MAJOR COMPONENTS 21
•Brakes (Integrated Braking) 21
•Fuel 23
•Tyres (Tubeless) 25
ESSENTIAL INDIVIDUAL COMPONENTS 29
•Ignition switch 29
HANDLEBAR SWITCHES CONTROL 30
FEATURES 31
•i3s (Idle Stop Start System) 31
•Eco mode 33
•Hero ride guide/Navigation 33
•Hero connect 38
•Steering lock 47
•Fuel tank lid lock/Seat lock/Helmet holder 47
•Center compartment 48
•Document compartment/First aid kit/
Tool kit holder 48
•Boot lamp/Boot lamp switch/USB charger 49
•Luggage hooks 50
•Side stand indicator/switch/Side stand 51
•Pillion footrest 52
