Sida 1/5
Power ON/OFF
Safety Precautions and Maintenance
1 Unplug the monitor before cleaning it with a slightly damp cloth.
2 Wiping the screen with a dry cloth is recommendable, and only during the
power has been switched off.
3 Do not use alcohol or ammonia-based liquids.
4 This monitor is designed with ventilation holes on the cabinet back, please
do not cover them or block it.
5 Also avoid placing the monitor near the electric heater or heater, including
in an enclosed room with no ventilations.
6 Please do not insert any matter or spray any liquid on it.
7 Please do not position the monitor on unsafe space, if it falls, it may be
damaged and may hurt the user.
8 Unplug the monitor if it is not going to be in use for an extended period of
time.
9 Please do not put heavy items on the monitor, or electric cord.
10 Please do not open the monitor back panel because the monitor contained
high voltage current.
Contents
•
•
A
warranty card
•
A
user manual instruction
Features:
•16.7M high quality image colors
•Smart image screen setting – OSD with simple layout and easy selection
•Smart control interfaces for easy settings
•Auto function; when no settings are set, it will auto-adjust to optimum settings
Basic setup
a) Insert the VGA cable (signal cord) to the PC graphic card (signal input).
b) The monitor has a wide power voltage range; it can be used on AC 100-240
50/60Hz power supply.
c) Connect the power cable to the Monitor power socket and to the power source in
the room.
d) Turn on the power source supply.
e) To switch on the monitor, press the power control on/off key
(first button from the bottom at the rear panel.
Power indicator light
•Blue (green) light indicates the power is on.
•Blue (green) light indicates the signal is
operating normally.
•Blue (green) flash indicates there is no input signal.
VGA connector
DVI connector
AC Adapter
12
11
Menu /
Enter
Up
Down
Exit
Power
On/ Off
Screen image setups
•The Control panel at the rear have five keys to adjust the monitor settings with the
aid of the Onscreen Display
The control panel buttons:
•Menu /Enter: Shows main choice menus
•Down: Adjust the options - move down or lower /Hot
key (option)
•Power ON/OFF button
•Up: Adjust the options - move up or higher /Hot key
(option)
•EXIT: Exit main menu, or when no menus - auto adjust image.
Adjustment settings
Main menu
item
Main menu
icon
Submenu item Sub-submenu
item
Description
Brightness
Contrast ratio
Brightness None Adjusts display
brightness
Contrast ratio None Adjusts display
contrast ratio
ECO mode
Standard Normal use mode
Text Text application
mode
Game Game application
mode
Movie Movie playing
application mode
Dynamic
contrast ratio
(DCR)
Enable Enables DCR
Disable Disables DCR
Image setting
Clock None Adjusts the picture
clock to reduce the
vertical noise
Focus None Adjusts the picture
phase to reduce
the horizontal noise
Horizontal
position
None Adjusts the picture
horizontal position
Vertical
position
None Adjusts the picture
vertical position
Image ratio
(only for wide-
screen model)
Auto Auto checks and
adjusts the image
display aspect ratio
Wide screen Adjusts the image
aspect ratio as
wide-screen mode
4:3 Adjusts the image
aspect ratio as 4:3
mode
Color
temperature
Warm color
temperature
None Set as warm color
temperature
Cold color
temperature
None Set as cold color
temperature
Custom setting
Red Finely tunes red
color temperature
Green Finely tunes green
color temperature
Blue Finely tunes blue
color temperature
34
11
