Mars 4K
The new Hollyland Mars 4K wireless video transmission system is capable of a 450ft
(150m) LOS range and ultra-low latency of 0.06s. The Mars 4K is designed to combine
high performance and reliable quality at an affordable price.
www.hollyland-tech.com
0.06s Low Latency
450ft (150m) LOS Range SDI & HDMI Support
Smart Channel Scan & Selection
Decimal-Point Frame Rate
xx.xx
Flexible Monitoring Options
M1
Item
Transmitter Receiver
PARAMETERS
PACKING LIST
Interface
Voltage
Power consumption
Antenna (RP-SMA male)
HDMI 1.4 b input (Type-A female)
3G-SDI input
DC input (2.0mm core socket)
USB Type-C (USB 2.0 OTG)
Antenna (RP-SMA male)
HDMI 1.4 b output (Type-A female)
3G-SDI output
DC input (2.0mm core socket)
USB Type-C (USB 2.0 OTG)
DC input: 6V–16V
USB Type-C: 5V/2.5A
(not supporting the QC and PD protocols)
NP-F battery: 6.8V–8.4V
DC input: 6V–16V
USB Type-C: 5V/2.5A
(not supporting the QC and PD protocols)
NP-F battery: 6.8V–8.4V
<8.5W (typical) <5W (typical)
Weight
223g (7.9oz)
(excluding the antennas)
223g (7.9oz)
(excluding the antennas)
Dimension
(LxWxH): 115x65x32mm (4.5"x2.5"x1.3") (LxWxH): 115x65x32mm (4.5"x2.5"x1.3")
Modulation mode
802.11n 802.11n
TX power
21dBm (max.) 21dBm (max.)
RX sensitivity
N/A –90dBm
Bit rate
8Mbps–20Mbps
Latency
0.06s (test data when 1080p60 signals are transmitted in a laboratory)
Range
450ft (150m) (test data in an open, interference-free outdoor environment)
Bandwidth
20MHz
Audio format
2 audio channels for the 3G-SDI and 8 audio channels for the HDMI 1.4b
Operating temperature
–10 to 60℃ ℃
Storage temperature
– 40 to 60℃ ℃
ESD protection
Contact discharge: ±6kV; air discharge: ±8kV (test data)
Operating frequency
5.1GHz–5.8GHz 5.1GHz–5.8GHz
Transmitter *1 Receiver *2 Antenna *5 Cold shoe *1 Type-C OTG converter *1
Self-locking DC adapter *1 User manual *1 Warranty card *1 Expansion accessory *1
