DUVAL 52” CEILING FAN

MODELS #50201, 50206

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday,

8 am - 5 pm, EST.

Español p. 19

LISTED FOR DAMP

LOCATION

WELCOME

PREPARATION

Before beginning the assembly of this product, ensure

that all parts are present. Compare all parts with the

package contents list and hardware contents list. If

any part is missing or damaged, do not attempt to

assemble the product.

After opening the top of the carton, remove the

mounting hardware package from the foam inserts,

then remove the motor from the packaging and

place it on a soft surface, such as a carpet, to avoid

damage to the nish.

Estimated Assembly Time: Under 60 minutes

Tools Required for Assembly (not included): Electrical

Tape, Phillips Screwdriver, Pliers, Safety Glasses,

Step Ladder, and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape

Measure, Wiring Handbook, and Wire Cutters

CARE AND MAINTENANCE

At least twice each year, lower the canopy to check

the downrod assembly, and then tighten all screws

on the fan. Clean the motor housing with only a soft

brush or lint-free cloth to avoid scratching the nish.

Clean the blades with a lint-free cloth. You may

occasionally apply a light coat of furniture polish to

wood blades for added protection.

Important: Shut off the main power supply before you

begin any maintenance tasks. Do not use water or a

damp cloth to clean the ceiling fan.

FAN WEIGHT

The net weight of this fan is: 18.7 lbs. (8,48 kg).

TABLE OF CONTENTS

ATTACH YOUR RECEIPT HERE

Serial Number

Purchase Date

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . .2

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Mounting Bracket Installation . . . . . . . . . . . . . . . . . . .6

Standard or Angle Mounting Instructions . . . . . . . . . .7

Closemount Instructions. . . . . . . . . . . . . . . . . . . . . .10

Wiring....................................11

Canopy Installation. . . . . . . . . . . . . . . . . . . . . . . . . .12

Blade Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Switch Housing Installation. . . . . . . . . . . . . . . . . . . .14

Operating Instructions . . . . . . . . . . . . . . . . . . . . . . .15

Replacement Parts List . . . . . . . . . . . . . . . . . . . . . .16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Limited Lifetime Warranty. . . . . . . . . . . . . . . . . . . . .18

PACKAGE CONTENTS

Unpack your fan and check the contents. You

should have the following items:

1. Blades (5)

2. Canopy

3. Mounting Bracket

4. Canopy Cover

5. Yoke Cover

6. Downrod

7. Blade Arm (5)

8. Motor Housing

9. Switch Housing

10. Loose parts bags containing (not shown):

Mounting hardware, electrical hardware, pull

chains, wire connectors, etc.
