Sida 1/15

RB80 n RB110

ULTRA ProTM | Ventilation Fan

with ULTRAQuickTM Installation Technology

INSTALLATION GUIDE

READ AND SAVE

THESE INSTRUCTIONS

Installer: leave this guide with homeowner.

Easy installation in both

new construction and retrofit

Table of Contents

Warnings and Cautions 2

Typical Installation 2

New Construction Installation 3

Retrofit Installation 7

Operation 12

Cleaning and Maintenance 12

Troubleshooting 12

Service Parts 13

Warranty 13

RB80 n

RB110 Installation GuidePage 2

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer.

If you have questions, contact the manufacturer at the address

or telephone number listed in the warranty.

2. Before servicing or cleaning unit, switch power off at service

panel and lock the service disconnecting means to prevent

power from being switched on accidentally. When the service

disconnecting means cannot be locked, securely fasten a

prominent warning device, such as a tag, to the service panel.

3. Installation work and electrical wiring must be done by a

qualified person(s) in accordance with all applicable codes

and standards, including fire-rated construction codes and

standards.

4. Sufficient air is needed for proper combustion and exhausting

of gases through the flue (chimney) of fuel burning equipment

to prevent backdrafting. Follow the heating equipment

manufacturer’s guideline and safety standards such as those

published by the National Fire Protection Association (NFPA),

and the American Society for Heating, Refrigeration and

Air Conditioning Engineers (ASHRAE), and the local code

authorities.

5. When cutting or drilling into wall or ceiling, do not damage

electrical wiring and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. If this unit is to be installed over a tub or shower, it must be

marked as appropriate for the application and be connected

to a GFCI (Ground Fault Circuit Interrupter) - protected branch

circuit.

8. Use an ON/OFF switch, timer, or speed control to operate this

ventilator. Use of speed control other than the Broan 78V and

78W may cause a motor humming noise.

9. This unit must be grounded.

Typical Installation

CAUTION

1. For general ventilating use only. Do not use to exhaust

hazardous or explosive materials and vapors.

2. This product is designed for installation in ceilings up to a

12/12 pitch (45 degree angle). Duct connector must point up.

DO NOT MOUNT THIS PRODUCT IN A WALL.

3. To avoid motor bearing damage and noisy and/or unbalanced

impellers, keep drywall spray, construction dust, etc. off power

unit.

4. Please read specification label on product for further

information and requirements.

45° 45°

• Installation is the same for:

• Fits in 2" x 8" ceiling construction.

• Infinitely adjust the fan position

between joists from 14" to 24"

on center.

*Purchase

separately.

INSULATION*

(Place around and

over Fan Housing.)

ROOF CAP*

(with built-in

damper)

FAN

HOUSING

POWER

CABLE*

4-IN. ROUND

DUCT*

ROUND

ELBOWS*

Seal gaps

around

Housing.

Seal duct

joints with

tape.

Keep duct

runs short.

WALL CAP*

(with built-in

damper)

NOT FOR USE IN A COOKING AREA

Do not install above or inside this area

Floor

Cooking

Equipment

Joists I-Joists Trusses

The ducting from this fan to the outside of the building has a strong effect on the air flow, noise and en-

ergy use of the fan. Use the shortest, straighest duct routing possible for best performance, and avoid

installing the fan with smaller ducts than recommended. Insulation around the ducts can reduce en-

ergy loss and inhibit mold growth. Fans installed with existing ducts may not achieve their rated airflow.

RB80 n

RB110 Installation GuidePage 3

Parts Bag holds

Knockout Plate

and six (6)

screws

Remove

Instruction

Sheet

Punch out Mask from

packaging. See Step 6.

New Construction Installation

Tools needed

• Power screwdriver with a Phillips bit

• Phillips screwdriver

• Flathead screwdriver

• Pliers

• Wire insulation stripper

• Wire cutter

Materials needed

• 4" round metal ducting recommended for best performance.

Use of other ducting is acceptable but may impact performance.

• Roof cap or wall cap (built-in damper recommended)

• Tape to seal duct connections

• Electrical wiring and supplies per local code requirements

1 Remove Packaging

2 Install

Mounting

Frame
