Sida 1/24
Contents
Introduction, 7
Safety instructions, 2
Installation tips, 8
Electrical Connection, 11
Burner and Nozzle Specifications, 12
Features, control panel, 6
Hotplates, 13
Grill, 14
Top Oven Cooking Charts, 15
Main Oven, 17
Main Oven Cooking Chart, 18
Using the Main Oven for Other Functions, 19
50 cm Gas Cooker
HD5G00CCX/UK
HD5G00CCW/UKHD5G00CCW/UKHD5G00CCW/UKHD5G00CCW/UK
HD5G00CCX/UKHD5G00CCX/UKHD5G00CCX/UK
Electronic Minute Minder, 16
EN
HD5G00CCBK/UKHD5G00CCBK/UKHD5G00CCBK/UK
EN
Instructions for
Installation and Use
Care and maintenance, 20
Installation, 22
2
EN
SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
These instructions are valid if the country
symbol appears on the appliance. If the symbol
does not appear on the appliance, please refer to
the technical instructions which will provide the
necessary instructions concerning modification of
the appliance to the conditions of use of the
country.
CAUTION : Use of the gas cooking appliance
results in the production of heat, moisture and
products of combustion in the room in which
it is installed. Ensure that the kitchen is well
ventilated, especially when the appliance is in
use: keep natural ventilation holes open or
install a mechanical ventilation device (mechanical
extractor hood). Prolonged intensive use of the
appliance may call for additional ventilation, such
as opening awindow, ormore effectiveventilation,
for example increasing the level of mechanical
ventilation (if possible).
Failure to follow the information in this manual exactly may cause a
fire or explosion, resulting in property damage or personal injury.
Before using the appliance, read these safety
instructions. Keep them nearby for future
reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all
times. The manufacturer declines any liability for
failure to observe these safety instructions, for
inappropriate use of the appliance or incorrect
setting of controls.
WARNING: The appliance and its accessible
parts become hot during use. Care shoul be taken
to avoid touching heating elements. Children less
than 8 years of age must be kept away unless
continuously supervised.
WARNING : If the hob surface is cracked, do not
use the appliance risk of electric shock.–
WARNING : Danger of fire : Do not store items
on the cooking surfaces.
CAUTION : The cooking process has to be
supervised. A short cooking process has to be
supervised continuously.
WARNING: Leaving the hob unattended when
cooking with fat or oil can be dangerous risk of–
fire. NEVER try to extinguish a fire with water, but
switch off the appliance and then cover the flames
e.g. with a lid or a fire blanket.
Do not use the hob as a work surface or support.
Keep clothes or other flammable materials away
from the appliance, unitl all the components have
cooled down completely - risk of fire.
Very young children (0-3 years) should be kept
away from the appliance. Young children (3-8
years) should be kept away from the appliance
unless continuously supervised. Children from 8
years old and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge can use this appliance
only if they are supervised or have been given
instructions on safe use and understand the
hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must
not becarried out by children withoutsupervision.
CAUTION : In case of hotplate glass breakage:-
shut immediately off all burners and any electrical
heating element and isolate the appliance from
the power supply; - do not touch the appliance
surface; -do not use the appliance
The glass lid can break in if it is heated up.
Turn off all the burners and the electric
plates before closing the lid. Do not shout
down lid when burner alight
WARNING: The appliance and its accessible
parts become hot duringuse. Care should be taken
to avoid touching heating elements. Children less
than 8 years of age must be kept away unless
continuously supervised.
Never leave the appliance unattended during
food drying. If the appliance is suitable for
probe usage, only use a temperature probe
recommended for this oven - risk of fire.
Keep clothes or other flammable materials
away from the appliance, until all the components
have cooled down completely - risk of fire. Always
be vigilant when cooking foods rich in fat, oil or
when adding alcoholic beverages - risk of fire. Use
oven gloves to remove pans and accessories. At
the end of cooking, open the door with caution,
allowing hot air or steam to escape gradually
before accessing the cavity - risk of burns. Do not
obstruct hot air vents at the front of the oven - risk
of fire.
Exercise caution when the oven door is in the
open or down position, to avoid hitting the door.
When you place the rack inside, make sure that
the stop is directed upwards and in the back of the
cavity.
The device shall not be operated for more 15 s. If
after 15s the burner has not lit, stop operating the
device and open the compartment door and/or
wait at least 1 min before attempting a further
ignition of the burner.
PERMITTED USE
CAUTION: The appliance is not intended to
be operated by means of an external switching
device, such as a timer, or separate remote
controlled system.
This appliance is intended to be used in
household and similar applications such as: staff
kitchen areas in shops, offices and other working
environments; farm houses; by clients in hotels,
3
motels, bed & breakfast and other residential
environments.
No other use is permitted (e.g. heating rooms).
This appliance is not for professional use. Do
not use the appliance outdoors.
Do not store explosive or flammable
substances (e.g. gasoline or aerosol cans) inside or
near the appliance - risk of fire.
Use pots and pans with bottoms the same
width as that of the burners or slightly larger (see
specific table). Make sure pots on the grates do
not protrude beyond the edge of the hob.
Improper use of the grids can result in damage
to the hob: do not position the grids upside down
or slide them across the hob.
Do not let the burner flame extend beyond the
edge of the pan
Do not use : Cast iron griddles, ollar stones,
terracotta pots and pans. Heat diffusers such as
metal mesh, or any other types. Two burners
simultaneously for one receptacle (e.g. Fish
kettle).
Should particular local conditions of the delivered
gas make the ignition of burner difficult, it is
advisable to repeat the operation with the knob
turned to small flame setting.
In caseofinstallation of a hood above thecooktop,
pleaserefer to thehood instructionsfor the correct
distance.
The protective rubber feet on the grids represent
a chocking hazard for young children. After
removing the grids, please ensure that all the feet
are correctly fitted.
INSTALLATION
The appliance must be handled and installed
by two or more persons - risk of injury. Use
protective gloves to unpack and install - risk of
cuts.
The electrical and gas connections must
comply with local regulation.
Installation, including water supply (if any),
electrical connections and repairs must be carried
out by a qualified technician. Do not repair or
replaceanypartof theapplianceunlessspecifically
statedin theusermanual. Keepchildrenawayfrom
theinstallationsite. Afterunpackingtheappliance,
make sure that it has not been damaged during
transport. In the event of problems, contact the
dealer or your nearest Aftersales Service. Once
installed, packaging waste (plastic, styrofoam
parts etc.) must be stored out of reach of
children - risk of suffocation. The appliance must
be disconnected from the power supply before
any installation operation - risk of electric shock.
During installation, make sure the appliance does
not damage the power cable - risk of fire or electric
shock. Only activate the appliance when the
installation has been completed.
WARNING : Modification of the appliance and
its method of installation are essential in order to
use the appliance safely and correctly in all the
additional countries
Use pressure regulators suitable for the gas
pressure indicated in the instruction.
The room must be equipped with an air
extraction system that expels any combustion
fumes.
Theroommustalso allowproperaircirculation,
as air is needed for combustion to occur normally.
The flow of air must not be less than 2 m³/h per
kW of installed power.
The air circulation system may take air directly
from the outside by means of a pipe with an inner
cross section of at least 100 cm²; the opening must
not be susceptible to blockages.
The system can also provide the air needed for
combustion indirectly, i.e. from adjacent rooms
fittedwith air circulationtubes asdescribed above.
However, these rooms must not be communal
rooms, bedrooms or rooms that may present a fire
hazard.
Liquid petroleum gas sinks to the floor as it
is heavier than air. Therefore, rooms containing
LPG cylinders must also be equipped with vents
to allow gas to escape in the event of a leak.
This means LPG cylinders, whether partially or
completely full, must not be installed or stored
in rooms or storage areas that are below ground
level (cellars, etc.). It is advisable to keep only the
cylinder being used in the room, positioned so
that it is not subject to heat produced by external
sources (ovens, fireplaces, stoves, etc. ) which
could raise the temperature of the cylinder above
50 C.°
Should you find it difficult to turn the knobs for the burner, please
contact the After-sales Service, who can replace of the burner tap if
found to be faulty.
The openings use for the ventilation and dispersion of heat must never
be covered.
Carry out all cabinet cutting works before
fitting the appliance in place and remove all wood
chips and sawdust.
Do not remove the appliance from its polystyrene
foam base until the time of installation.
If the appliance is not installed above an oven,
a separator panel (not included) must be installed
in the compartment under the appliance.
Connection with rigid pipe (copper or steel):
If the gas pressure is different from the
recommended pressure, a suitable pressure
regulator must be fitted to the inlet pipe in
accordance with the current national regulations.
Use an appropriate cabinet to ensure that the
appliance operates properly: To install the oven
under the counter (see diagram) or in a kitchen
unit, the cabinet must have the dimensions as the
picture.

Produktspecifikationer

Varumärke: Hotpoint
Kategori: Ugn
Modell: HD5G00CCX/UK

Behöver du hjälp?

Om du behöver hjälp med Hotpoint HD5G00CCX/UK ställ en fråga nedan och andra användare kommer att svara dig


Ugn Hotpoint Manualer

Hotpoint

Hotpoint SA2 540 H WH Bruksanvisning

17 Oktober 2024
Hotpoint

Hotpoint OS 89 IX Bruksanvisning

14 Oktober 2024
Hotpoint

Hotpoint PC 640 X /HA Bruksanvisning

8 Oktober 2024
Hotpoint

Hotpoint SI5 851 C IX Bruksanvisning

4 Oktober 2024
Hotpoint

Hotpoint G750TX Bruksanvisning

4 Oktober 2024
Hotpoint

Hotpoint RBS360DMWW Bruksanvisning

4 Oktober 2024
Hotpoint

Hotpoint HD5G00KCB Bruksanvisning

3 Oktober 2024
Hotpoint

Hotpoint FID 834 H MR HA Bruksanvisning

2 Oktober 2024
Hotpoint

Hotpoint FIT 801 H AN HA Bruksanvisning

29 September 2024
Hotpoint

Hotpoint BS43B Bruksanvisning

29 September 2024

Ugn Manualer

Nyaste Ugn Manualer

Taurus

Taurus HM778WHD Bruksanvisning

27 Oktober 2024
Lacanche

Lacanche CITEAUX Bruksanvisning

27 Oktober 2024
JennAir

JennAir JDS1450FS Bruksanvisning

27 Oktober 2024
Orima

Orima ORP-76-IN Bruksanvisning

27 Oktober 2024
Breville

Breville the Handy Hot Plate BHP150 Bruksanvisning

27 Oktober 2024
JennAir

JennAir JGRP436HL Bruksanvisning

27 Oktober 2024
Neff

Neff C17MS22G1 Bruksanvisning

27 Oktober 2024
Pit Boss

Pit Boss BK24 Bruksanvisning

27 Oktober 2024
Guzzanti

Guzzanti GZ-8206 Bruksanvisning

27 Oktober 2024
Avanti

Avanti DE2402SC Bruksanvisning

27 Oktober 2024
