Sida 1/40

Coil Top and

Radiant Top Models

Standard

Clean Models

JBS03

JBS07

JBS15

JBS27

JBS56

RB525

RB526

RB536

RB540

Self-Clean

Models

JB600

JBP15

JBP22

JBP27

JBP60

JBP61

RB740

RB757

RB758

RB787

RB790

RB800

49-88044 06-10 GE

Safety Information . . . . . . . . . . . . 2-5

Operating Instructions

Adjust the Oven

Thermostat 20 . . . . . . . . . . . . . . . . . . . . . . . . .

Clock and Timer 14, 15 . . . . . . . . . . . . . . . . .

Oven 11–13 . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Oven Controls 9, 10 . . . . . . . . . . . . . . . . . . . .

Sabbath Feature 18, 19 . . . . . . . . . . . . . . . .

Selecting Types of Cookware . . . . . . . .8

Self-Cleaning 23, 24 . . . . . . . . . . . . . . . . . . . .

Special Features 17 . . . . . . . . . . . . . . . . . . . .

Surface Units . . . . . . . . . . . . . . . . . . . . . . 6, 7

Timed Baking and Roasting 16 . . . . . . . .

Warming Drawer 21, 22 . . . . . . . . . . . . . . .

Care and Cleaning . . . . . . . . . 26–30

Aluminum Foil 4, 5, 12 . . . . . . . . . . . . . . . . .

Glass Cooktop 29, 30 . . . . . . . . . . . . . . . . . .

Troubleshooting Tips . . . . . . 31–34

Accessories . . . . . . . . . . . . . . . . . . . . . . 35

Consumer Support

Consumer Support Back Cover . . . . . . . .

Warranty 39 . . . . . . . . . . . . . . . . . . . . . . . . . . .

GEAppliances.com

Write the model and serial

numbers here:

Model # __________________

Serial # __________________

You can find them on a label,

behind the storage drawer or

warming drawer on the oven frame.

Owner’s Manual

Ranges

Electric Coil & Radiant

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Read all safety instructions before using the product. Failure to follow these instructions may result in fire, electric

shock, serious injury or death.

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances

known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of

potential exposure to such substances.

The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during the cleaning cycle. Exposure

can be minimized by venting with an open window or using a ventilation fan or hood.

To reduce the risk of tipping the range, the range must be secured by a

properly installed anti-tip bracket. See installation instructions shipped

with the bracket for complete details before attempting

to install.

For Freestanding Ranges:

To check if the bracket is installed and engaged properly, remove the

storage drawer or kick panel and look underneath the range

to see that the leveling leg is engaged in the bracket. On models without

a storage drawer or kick panel, carefully tip the range forward. The

bracket should stop the range within 4 inches. If it

does not, the bracket must be reinstalled. If the range is pulled

from the wall for any reason, always repeat this procedure to

verify the range is properly secured by the anti-tip bracket.

Never completely remove the leveling legs or the range will not

be secured to the anti-tip device properly.

For Slide-In Ranges:

To check if the bracket is installed and engaged properly, remove the

storage drawer or kick panel and look underneath the range to see that

the leveling leg is engaged in the bracket.

For Drop-In Ranges:

To check if the bracket is installed and engaged properly, lower

the oven door and gently apply medium force at the handle end until

movement of the range is detected. Continue pressing until the anti-tip

bracket is engaged and movement stops. A small amount of

movement is acceptable at the back of the range top, but it should be

stable and not tip once the anti-tip bracket is engaged. If it does not,

the bracket must be reinstalled.

If you did not receive an anti-tip bracket with your purchase,

call 1.800.626.8774 to receive one at no cost (in Canada, call

1.800.561.3344). For installation instructions of the bracket,

visit GEAppliances.com (in Canada, GEAppliances.ca).

ANTI-TIP DEVICE

WARNING

GEAppliances.com

Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips

Consumer Support

■Use this appliance for its intended purpose as described

in this Owner’s Manual.

■Be sure your appliance is properly installed and

grounded

by a qualified installer in accordance with the provided

installation instructions.

■ Do not attempt to repair or replace any part of your

range unless it is specifically recommended in this

manual. All other servicing should be transferred to a

qualified technician.

■ Before performing any service, unplug the range or

disconnect the power supply at the household

distribution panel by removing the fuse or switching off

the circuit breaker.

■ Do not leave children alone—children should not be left

alone or unattended in an area where an appliance is in

use. They should never be allowed to climb, sit or stand

on any part of the appliance.

■ CAUTION: Do not store items of interest to

children above a range or on the backguard of a

range—children climbing on the range to reach items

could be seriously injured.

■ Use only dry pot holders—moist or damp pot holders on

hot surfaces may result in burns from steam. Do not let

pot holders touch hot surface units or heating elements.

Do not use a towel or other bulky cloth in place of pot

holders.

■ Never use your appliance for warming or heating the

room.

■Do not touch the surface units, the heating elements or

the interior surface of the oven. These surfaces may be

hot enough to burn even though they are dark in color.

During and after use, do not touch, or let clothing or

other flammable materials contact the surface units,

areas nearby the surface units or any interior area of

the oven; allow sufficient time for cooling first. Other

surfaces of the appliance may become hot enough to

cause burns. Potentially hot surfaces include the

cooktop, areas facing the cooktop, oven vent opening,

surfaces near the opening and crevices around the

oven door.

■Do not heat unopened food containers. Pressure could

build up and the container could burst, causing an

injury.

■ Avoid scratching or impacting glass doors, cooktops or

control panels. Doing so may lead to glass breakage. Do

not cook on a product with broken glass. Shock, fire or

cuts may occur.

■Cook meat and poultry thoroughly—meat to at least an

internal temperature of 160°F and poultry to at least an

internal temperature of 180°F. Cooking to these

temperatures usually protects against foodborne illness.

■Do not store or use flammable materials in an oven or

near the cooktop, including paper, plastic, pot holders,

linens, wall coverings, curtains, drapes and gasoline or

other flammable vapors and liquids.

■Never wear loose-fitting or hanging garments while

using the appliance. These garments may ignite if they

contact hot surfaces, causing severe burns.

■ Do not let cooking grease or other flammable materials

accumulate in or near the range. Grease in the oven or

on the cooktop may ignite.

■ Clean ventilating hoods frequently. Grease should not

be allowed to accumulate on the hood or filter.

■Do not use water on grease fires. Never pick up a

flaming pan. Turn the controls off. Smother a flaming

pan on a surface unit by covering the pan completely

with a well-fitting lid, cookie sheet or flat tray. Use a

multi-purpose dry chemical or foam-type fire

extinguisher.

■If there is a fire in the oven during baking, smother the

fire by closing the oven door and turning the oven off or

by using a multi-purpose dry chemical or foam-type fire

extinguisher.

■ If there is a fire in the oven during self-clean, turn the

oven off and wait for the fire to go out. Do not force the

door open. Introduction of fresh air at self-clean

temperatures may lead to a burst of flame from the

oven. Failure to follow this instruction may result in

severe burns.

GENERAl SAFETY INSTRuCTIONS

WARNING

kEEP FlAMMABlE MATERIAlS AWAY FROM

ThE RANGE.

WARNING

IN ThE EVENT OF A FIRE, TAkE ThE FOllOWING

STEPS TO PREVENT ThE FIRE FROM SPREADING:

WARNING
