1. SELECTION KNOB

For switching the oven on by

selecting a function.

Turn to the position to switch

the oven off.

2. LIGHT

With the oven switched on, press

to turn the oven compartment

lamp on or off.

3. SETTING THE TIME

For accessing the cooking time

settings, delayed start and timer.

For displaying the time when the

oven is off.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time

settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions. Automatic functions use

0/A.

1 32 4 5 6

PRODUCT DESCRIPTION

DAILY REFERENCE

GUIDE

Read the safety instructions carefully before using the product

THANK YOU FOR PURCHASING AN

HOTPOINT PRODUCT

To receive more comprehensive help and

support, please register your product at

www. hotpoint. eu/ register

WWW

You can download the Safety Instructions

and the Use and Care Guide by visiting our

website www.hotpoint.eu and following

the instructions on the back of this booklet.

1. Control panel

2. Fan

3. Lamp

4. Runners for accessories

(the level is indicated on the wall

of the cooking compartment)

5. Door

6. Upper heating element/grill

7. Identification plate

(do not remove)

8. Bottom heating element

(non-visible)

CONTROL PANEL

* Function used as reference for the energy eciency

declaration in accordance with Regulation (EU) No. 65/2014

CONVENTIONAL*

For cooking any kind of dish on one shelf only.

CONVECTION BAKE

To cook on a maximum of two shelves at the

same time. It is a good idea to swap the position of

the baking trays halfway through cooking.

GRILL

For grilling steaks, kebabs and sausages,

cooking vegetables au gratin or toasting bread.

When grilling meat, we recommend using a drip tray

to collect the cooking juices: Position the pan on any

of the levels below the wire shelf and add 200 ml of

drinking water.

TURBO GRILL

For roasting large joints of meat (legs, roast

beef, chicken). We recommend using a drip tray to

collect the cooking juices: Position the pan on any

of the levels below the wire shelf and add 200 ml of

drinking water.

DEFROSTING

For defrosting food more quickly.

ECO FORCED AIR*

For cooking roasts and stuffed roasting joints

on a single shelf. Food is prevented from drying out

excessively by gentle, intermittent air circulation.

When this ECO function is in use, the light will

remain switched off during cooking but can be

switched on again by pressing .

WIRE SHELF BAKING TRAY

The number of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

. Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the

raised rear side (pointing upwards) down first. Then

slide it horizontally along the shelf guide as far as

possible.

. Other accessories, like the baking tray, are to be

inserted horizontally, letting them slide on the shelf

guides.

BREAD AUTO

This function automatically selects the ideal

temperature and baking time for bread. For best

results, carefully follow the recipe . Activate the

function when the oven is cold.

PASTRY AUTO

This function automatically selects the ideal

temperature and baking time for cakes. Activate the

function when the oven is cold.

ACCESSORIES

Download the Use and Care Guide from

www.hotpoint.eu for more information

WWW

Download the Use and Care Guide from

www.hotpoint.eu for more information

WWW

FUNCTIONS

1. SETTING THE TIME

You will need to set the time when you switch on the

appliance for the first time: Press

until the icon and the current time start flashing

on the display.

Use or to set the hour and press to confirm.

The two digits for the minutes will start flashing. Use

or to set the minutes and press to confirm.

Please note: When the icon is flashing, for example

following lengthy power outages, you will need to reset the

time.

2. REHEAT THE OVEN

A new oven may release odours that have been left

behind during manufacturing: This is completely

normal.

Before starting to cook food, we therefore

recommend heating the oven with it empty in order

to remove any possible odours.

Remove any protective cardboard or transparent

film from the oven and remove any accessories from

inside it.

Heat the oven to 250 ° C for about one hour,

preferably using the “Convection Bake” function. The

oven must be empty during this time.

Follow the instructions for setting the function

correctly.

Please note: It is advisable to air the room after using the

appliance for the rst time.

1. SELECT A FUNCTION

To select a function, turn the selection knob to the

symbol for the function you require: The display will

light up and an audible signal will sound.

2. ACTIVATE A FUNCTION

MANUAL

To start the function you have selected, turn the

thermostat knob to set the temperature you require.

Please note: During cooking you can change the function

by turning the or adjust the temperature by selection knob

turning the .thermostat knob

The function will only start if the thermostat knob is on 0 °C.

You can set the cooking time, cooking end time (only if

you set a cooking time) and a timer.

AUTOMATIC

To start the automatic function you have selected

(“Bread” or “Pastry”), keep the thermostat knob at the

position for automatic functions (0/A).

To finish cooking, turn the selection knob to position 0.

Please note: You can set the cooking end time and timer.

3. PREHEATING

Once the function starts, an audible signal and a

flashing icon on the display indicate that the

preheating phase has been activated.

At the end of this phase, an audible signal and the

fixed icon on the display will indicate that the oven

has reached the set temperature: At this point, place

the food inside and proceed with cooking.

Please note: Placing the food in the oven before preheating

has nished may have an adverse eect on the nal cooking

result.

. PROGRAMMING COOKING

You will need to select a function before you can start

programming cooking.

DURATION

Keep pressing until the icon and “00:00” start

flashing on the display.

Use or to set the cooking time you require, then

press to confirm.

Activate the function by turning the thermostat knob

to the temperature you require: An audible signal will

sound and the display will indicate that cooking is

complete.

Notes: To cancel the cooking time you have set, keep

pressing until the icon starts ashing on the display,

then use to reset the cooking time to “00:00”.

This cooking time includes a preheating phase.

USING THE APPLIANCE FOR THE FIRST TIME

DAILY USE
