DESCRIPTION

HyperX HX316C10FBK2/16 is a kit of two 1G x 64-bit (8GB)

DDR3-1600 CL10 SDRAM (Synchronous DRAM) 2Rx8 memory

modules, based on sixteen 512M x 8-bit DDR3 FBGA compo-

nents per module. Total kit capacity is 16GB. Each module kit

has been tested to run at DDR3-1600 at a low latency timing of

10-10-10 at 1.5V. Additional timing parameters are shown in

the PnP Timing Parameters section below. The JEDEC stan-

dard electrical and mechanical specifications are as follows:

Document No. 4807008-001.B00 04/23/15 Page 1

SPECIFICATIONS

selcyc 01)DDI(LC

Row Cycle Time (tRCmin) 48.125ns (min.)

Refresh to Active/Refresh 260ns (min.)

Command Time (tRFCmin)

Row Active Time (tRASmin) 37.5ns (min.)

Maximum Operating Power TBD W* (per module)

0 - V 49gnitaR LU

Operating Temperature 0o C to 85o C

Storage Temperature -55o C to +100o C

*Power will vary depending on the SDRAM used.

FEATURES

•JEDEC standard 1.5V (1.425V ~1.575V) Power Supply

•VDDQ = 1.5V (1.425V ~ 1.575V)

•800MHz fCK for 1600Mb/sec/pin

•8 independent internal bank

•Programmable CAS Latency: 11, 10, 9, 8, 7, 6

•Programmable Additive Latency: 0, CL - 2, or CL - 1 clock

•8-bit pre-fetch

•Burst Length: 8 (Interleave without any limit, sequential with

starting address “000” only), 4 with tCCD = 4 which does not

allow seamless read or write [either on the y using A12 or

MRS]

•Bi-directional Dierential Data Strobe

•Internal(self) calibration : Internal self calibration through ZQ

pin (RZQ : 240 ohm ± 1%)

•On Die Termination using ODT pin

•Average Refresh Period 7.8us at lower than TCASE 85°C,

3.9us at 85°C < TCASE < 95°C

•Asynchronous Reset

•Height 1.291” (32.80mm) w/heatsink, double sided

component

HX316C10FBK2/16

16GB (8GB 1G x 64-Bit x 2 pcs.)

DDR3-1600 CL10 240-Pin DIMM Kit

Continued >>

kingston.com/hyperx

PnP JEDEC TIMING PARAMETERS:

•DDR3-1600 CL10-10-10 @1.5V

•DDR3-1333 CL9-9-9 @1.5V

•DDR3-1066 CL7-7-7 @1.5V

Note: The PnP feature oers a range of speed and timing options to support

the widest variety of processors and chipsets. Your maximum speed will

be determined by your BIOS.

Document No. 4807008-001.B00 Page 2

continued HyperX

All Kingston products are tested to meet our published specications. Some motherboards or system congurations may not operate at

the published HyperX memory speeds and timing settings. Kingston does not recommend that any user attempt to run their computers

faster than the published speed. Overclocking or modifying your system timing may result in damage to computer components.

FOR MORE INFORMATION, GO TO WWW.KINGSTON.COM/HYPERX

kingston.com/hyperx

7.08 mm

133.35 mm

32.8 mm

MODULE DIMENSIONS

MODULE WITH HEAT SPREADER
