©Copyright LOTRONIC 2015 2 - 1 DJM 50BT MKII
USB STEREO MIXER
TABLE DE MIXAGE STEREO USB
USB STEREOMISCHPULT
MIXER STEREO USB
MESA DE MISTURA STEREO
USB STEREO MIKSER
USB STEREO MENGPANEEL
MEZCLADOR USB ESTEREO
Ref.: DJM250BT- MKII
USER MANUAL
MANUEL D’UTILISATION
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUÇÕES
MANUAL DE UTILIZARE
NAVODILA ZA UPORABO
HANDLEIDING
MANUAL DE INSTRUCCIONES
©Copyright LOTRONIC 2015 2 - 2 DJM 50BT MKII
TOP PANEL:
Rear Panel:
SAFETY RECOMMENDATIONS
MAGNETIC FIELD
CAUTION! Do not locate sensitive high gain equipment such as preamplifiers or tape decks directly above or below
the unit. This unit has a strong magnetic field which can induce hum into unshielded devices that are located nearby.
The field has strongest spots just above and below the unit. Locate the amplifier at the bottom of the rack and the
preamplifier or other sensitive equipment at the top.
To prevent electric shock, do not remove top or bottom covers.
No user serviceable parts inside.
Refer servicing to qualified servicing personnel.
Disconnect power cord before removing back panel cover to access gain switch.
No naked flame sources, such as lighted candles, should be placed on the
apparatus
The unit should only be used in moderate climates
This unit should be cleaned only with a dry cloth. Avoid solvents or other
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
GB
©Copyright LOTRONIC 2015 2 - 3 DJM 50BT MKII
cleaning detergents
A minimum distance of 0.5m around the unit must be kept to ensure sufficient ventilation and avoid
overheating
WARNING! To reduce the risk of electric shock, do not expose this equipment to rain or moisture!
The exclamation point triangle is used to alert the user to important operating or maintenance instructions
The lightning bolt triangle is used to alert the user to the risk of electric shock
Controls
1. Mic 1 Socket
Connect your microphone with 1/4” jack plug here.
2. MIC Level Control
With this knob, you can adjust the microphone volume。
3. MIC Treble
Used to increase or lower the microphone’s higher frequencies.
4. MIC Bass
Used to increase or lower the microphone’s lower frequencies.
5. Talkover Button
Press this button if you want to use your microphone. When the button is pressed, all other signal sources
will be attenuated by 14dB, so that the microphone can be clearly heard. In the OFF position, all signals
returns to their original level.
6. Phono/Line Switch
Use this switch to select the input to be sent to the individual channel.
7. Treble Control
Used to increase or lower the HIGHS of the input channel.
8. Middle Control
Used to increase or lower the MIDS of the input channel.
9. Bass Control
Used to increase or lower the LOWS of the input channel
10. Channel Fader
Used to adjust the level of each channel.
11. Crossfader
Mixes the signals of one channel with another. If the crossfader is in the center position. Both channels can
be heard.
12. Headphone Socket
Connect your headphone with impedance between 8 and 600 Ohms to this connector.
13. Cue Button
Use this button in order to select the channel(s) to be monitored by headphones.
14. HEADPHONE LEVEL CONTROL
Let you to control the volume level of headphone
15. HEADPHONE CUE/PGM CONTROL
Allows you to listen simultaneously or separately to the CUE material or the active program.
16. Master Control
Adjust the level of the master-output.
