Ibiza Sound PORT85VHF-BT Bruksanvisning

Ibiza Sound hi-fi system PORT85VHF-BT

Läs nedan 📖 manual på svenska för Ibiza Sound PORT85VHF-BT (24 sidor) i kategorin hi-fi system. Denna guide var användbar för 5 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/24
1
©Copyright LOTRONIC 2013 - PORT85VHF BT www.ibiza- sound.net
PORTABLE SOUND SYSTEM 8" 500W
SYSTEME SONO PORTABLE 8"/20cm 500W
TRAGBARE BESCHALLUNGSANLAGE MIT BATTERIE
SISTEMA PA PORTATIL ACTIVO COM BATERIA
MOBILNY ZESTAW NAGŁOŚNIENIOWY
SISTEM PA PORTABIL 8” 500W
MEGAFONIA PORTATIL 8”
PRENOSNI ZVOČNIŠKI SISTEM 8”/20cm 500W
PRENOSNI ZVUČNIŠKI SISTEM SA BATERIJOM 8”
Ref. PORT85VHF- : BT
INSTRUCTION MANUAL
MANUEL D’UTILISATION
MANUAL DE UTILIZARE
MANUAL DE USO
NAVODILA ZA UPORABO
Imported from China by:
LOTRONIC SA - Avenue Zénobe Gramme 11
1480 SAINTES - Belgium
Thank you for purchasing this portable sound system. Prior to using the unit for the first
time, please read the manual and keep it for future reference.
SAFETY RECOMMENDATIONS
All safety instructions and warnings must be adhered to. They are part of the manual and
must be kept with the manual.
Any guarantee claims are rendered invalid if damage occurs due to non-observance of
these operating instructions. We assume no liability for any consequent damage.
We assume no liability for personal injury or damage to property caused by incorrect
handling or nonobservance o the safety instructions. Any guarantee claims expire in such
cases.
Unauthorized conversions and/or modifications of the appliance are not permitted for
safety and licensing reasons (CE).
The appliance is approved for operation in dry, closed rooms only. Do not operate the
device nearby water, such as in bathrooms or nearby swimming pools.
The appliance may not be exposed to extreme temperatures (<＋5 -℃>+35℃) during
operation.
The appliance may not be subjected to strong vibrations or heavy mechanical strain.
The appliance may not be exposed to excessive moisture (due to dripping or sprayed
water, for example).
Do not place any recipients filled with liquids, such as glasses or vases, on top of or
directly next to the appliance. They could fall over, causing water to enter the appliance.
Never pour out liquids above the appliance. Do not place any small objects, such as coins
or paper clips, on the appliance since they could fall inside the appliance. You run a high
risk of causing a fire or life-threatening electrocution! If any liquid or objects enter the
appliance nevertheless, pull the mains plug out of the socket immediately and contact a
specialist.
The appliance has been constructed according to protection class ll (only for double
insulated units without earth terminal).
220- 240 Vac/50 Hz mains socket may be used as source of power for the appliance.
Never try to operate the appliance with any other voltage.
Only pull the mains plug out of the socket by the intended gripping surface. Do not pull it
by the cable.
Never plug the mains plug in or out with damp or wet hands.
Always pull the mains plug out of the mains socket:
- Before cleaning the appliance
2
©Copyright LOTRONIC 2013 - PORT85VHF BT www.ibiza- sound.net
- If there is a thunderstorm
- If you will not be using the appliance for a long period of time (＞1 week)
Electrical appliances must be kept out of the reach of children. Be particularly careful if
children are present. Children are not aware of the hazards involved in handing electrical
appliances improperly. Children could attempt to poke objects into the appliance. There is
a life-threatening danger of electrocution.
Do not leave the appliance unattended while operating it.
Never place the appliance on an unstable or movable surface. Persons could be injured or
the appliance damaged by it falling down.
When using a rack, make sure it is in a stable position and is transported securely.
Installation on uneven, slanted surfaces or stopping the rack abruptly during transport can
result in the rack overturning or appliances falling from or out of the rack and injuring
people.
Live components can be exposed by opening covers or removing components (unless this
can be done without tools). Contact points can also be live. If the appliance has to be
opened in order to calibrate, service, repair or replace components or assemblies, all of its
poles must be disconnected from all sources of voltage first. If the appliance has to be
kept open and under voltage during maintenance or repairs, this work may only be
carried out by a specialist who is familiar with the risks involved and the relevant
regulations.
Never connect the appliance directly after transferring it from a cold to a warm room. The
condensation water that forms could destroy the appliance or result in an electric shock.
Allow the device to reach room temperature before connecting it. Wait until the
condensation water has evaporated. This can take some hours.
Do not place any naked flames such as those of burning candles on or next to the
appliance.
Do not place the appliance on soft surfaces such as carpets or beds. Do not cover the air
vents of the appliance. Do not obstruct the air circulation with objects such as magazines,
table cloths or curtains. This prevents the dissipation of heat from the appliance and can
result in overheating.
Only use the appliance in a moderate climate, not in tropical environments.
All persons involved in operating, installing and servicing the appliance and putting it into
service must be trained and qualified accordingly and observe these operating
instructions.
Defective mains cables may only be replaced by specialists. Danger of shock hazard!
Do not leave the packaging material lying around carelessly since it can become a source
of danger for children playing with it.
The accident prevention regulations and the regulations of the employers’ liability
insurance association should be observed at commercial institutions.
If you are not sure about the correct connection or if questions arise which are not
answered by the operating instructions, please do not hesitate to contact support or a
specialist of your choice. Consult a specialist if you are in doubt the operating principle or
the safety of the product.
FEATURES
- Bluetooth function
- Built- in amp
- Built- - in USB MP3 player
- 2x VHF microphones
- Remote control
- Treble & Bass control
- Mic VOL & ECHO controls
- MUSIC volume control
- MIC & LINE input
- Built- in rechargeable battery
- Installed handle & wheel
FRONT PANEL
POWER SUPPLY: BATTERY & AC OPERATION
1. Built -in rechargeable battery and AC power. Prior to using this system for the first
time, please insert the AC lead into the AC socket of the player and plug the other
end on a suitable wall outlet. Make sure that the “CHARGE INDICATOR” is ON 10
hours continuously.
2. Please recharge once every 6 months if you don’t use the system for a longer period
of time.
3
©Copyright LOTRONIC 2013 - PORT85VHF BT www.ibiza- sound.net
NOTE: Please shut down the power switch after you have finished using the system.
REAR PANEL
TO PLAY U- DISK MP3/WMA MUSIC
1. Switch power source to ON.
2. Insert a U-DISK
3. Select a title and press►
TO PLAY MUSIC
1. Insert an RCA plug into the LINE IN socket and press USB/AUX.
2. Insert a microphone TRS Jack into MIC1 or MIC2 and switch the VHF on.
3. Adjust the MIC VOL, ECHO, MASTER VOL.
USE OF THE BLUETOOTH FUNCTION
1. Press the MODE button until BLUETOOTH displays. The BLUETOOTH function is now
activated.
2. Activate the Bluetooth function on your smartphone or any other tablet PC.
3. The product appears under the name « » and ready to be connected to - IBIZA PORT is
your equipment.
4. Now play your music via the portable sound system. Set the volume via the Master
volume button.
5. Don’t set the volume of pour smartphone or tablet PC too high. Do not exceed ¾ of
the total volume to avoid distortion.
Specifications
Speaker ................................................................................................8 ”/20cm
RMS power .............................................................................................. 250W
Max. power ............................................................................................. 500W
Power of built-in amplifier ............................................................. 200W max.
Sensitivity ................................................................................................. 93dB
Frequency range ......................................................................... 45Hz – 20kHz
Battery .......................................................................................... 12Vdc 2.3Ah
Power supply ................................................................. 220- ~ 240Vac 50/60Hz
Dimensions ........................................................................................................
IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling
centre. Ask your local authorities or your dealer about the way to proceed.
Nous vous remercions pour l’achat de ce système de sonorisation portable. Avant la
première utilisation, lisez attentivement le manuel et conservez le pour référence -
ultérieure.
Consignes de sécurité
Nous déclinons toute responsabilité pour des dommages aux biens et aux personnes dus à
une mauvaise manipulation ou le non-respect des consignes de sécurité. Le droit de
garantie ne s’applique pas.
Des modifications non-autorisées de l’appareil sont interdites pour des raisons de sécurité
et de licence (CE).
Utiliser uniquement à l’intérieur dans une pièce sèche et fermée. Ne pas utiliser à
proximité d’eau tel que dans une salle de bains ou à proximité d’une piscine.
Ne pas exposer l’appareil à des températures extrêmes (<+5°C/>+35°C) pendant le
fonctionnement.
Tenir à l’abri des vibrations fortes et des contraintes mécaniques.
Tenir à l’abri de l’humidité extrême (due à de l’eau pulvérisée p.ex.)
F
