Sida 1/36
INSTRUCTION MANUAL
iF620
UHF TRANSCEIVER
iF520
VHF TRANSCEIVER
RWARNING! NEVER connect the transceiver to an
AC outlet. This may pose a fire hazard or result in an electric
shock.
NEVER connect the transceiver to a power source of more
than 16 V DC such as a 24 V battery. This connection will
damage the transceiver.
NEVER cut the DC power cable between the DC plug and
fuse holder. If an incorrect connection is made after cutting,
the transceiver might be damaged.
NEVER place the transceiver where normal operation of
the vehicle may be hindered or where it could cause bodily
injury.
NEVER allow children to touch the transceiver.
NEVER expose the transceiver to rain, snow or any liquids.
USE the supplied microphone only. Other microphones
have different pin assignments and may damage the trans-
ceiver.
i
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAVE THIS INSTRUCTION MANUAL— This in-
struction manual contains important operating instructions for
the IC-F520
VHF TRANSCEIVER
and IC-F620
UHF TRANSCEIVER
.
EXPLICIT DEFINITIONS
WORD DEFINITION
RWARNING!
CAUTION
NOTE
Personal injury, fire hazard or electric shock
may occur.
Equipment damage may occur.
Recommended for optimum use. No risk of
personal injury, fire or electric shock.
Icom, Icom Inc. and the logo are registered trademarks of Icom Incor-
porated (Japan) in the United States, the United Kingdom, Germany, France,
Spain, Russia and/or other countries.
SmarTrunk II™ and SmarTrunk 3G™ are Trademark of SmarTrunk Systems,
Inc.
PRECAUTION
ii
DO NOT use or place the transceiver in areas with tem-
peratures below –22°F (–30°C) or above +140°F (+60°C) or,
in areas subject to direct sunlight, such as the dashboard.
AVOID operating the transceiver without running the vehi-
cle’s engine. The vehicle’s battery will quickly run out if the
transceiver is in transmission while the vehicle’s engine OFF.
AVOID placing the transceiver in excessively dusty envi-
ronments.
AVOID placing the transceiver against walls. This will ob-
struct heat dissipation.
AVOID the use of chemical agents such as benzine or al-
cohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority to
operate this transceiver under FCC regulations.
TABLE OF CONTENTS
IMPORTANT .................................................................................................... i
EXPLICIT DEFINITIONS ................................................................................. i
PRECAUTION ................................................................................................. i
TABLE OF CONTENTS .................................................................................. ii
1 PANEL DESCRIPTION .......................................................................... 1–7
■Front panel ............................................................................................ 1
■Function display ..................................................................................... 3
■Programmable function keys ................................................................. 4
2 OPERATION ......................................................................................... 8–10
■Turning power ON ................................................................................. 8
■Channel selection .................................................................................. 8
■Receiving and transmitting .................................................................... 9
3 BIIS OPERATION ............................................................................... 11–22
■Default setting ...................................................................................... 11
■Receiving a call .................................................................................... 11
■Transmitting a call ................................................................................ 13
■Receiving a message .......................................................................... 15
■Transmitting a status ........................................................................... 17
■Transmitting an SDM ........................................................................... 18
■Position data transmission ................................................................... 20
■Printer connection ................................................................................ 20
■PC connection ..................................................................................... 20
■Digital ANI ............................................................................................ 20
■Auto emergency transmission ............................................................. 21
■Stun function ........................................................................................ 21
■BIIS indication ...................................................................................... 21
■Horn output .......................................................................................... 21
■Priority A channel selection .................................................................. 22
4 Optional SmarTrunk OPERATION ................................................... 23–24
■SmarTrunk II™, SmarTrunk 3G™ and conventional modes ............... 23
■SmarTrunk II™ and SmarTrunk 3G™ operation ................................. 23
5 CONNECTION AND INSTALLATION ................................................ 25–30
■Rear panel description and connection ............................................... 25
■Supplied accessories ........................................................................... 26
■Mounting the transceiver ...................................................................... 27
■Optional unit installation ...................................................................... 28
■Antenna ................................................................................................ 30
■Fuse replacement ................................................................................ 30
■Cleaning .............................................................................................. 30
6 OPTIONS .................................................................................................. 31
7 SAFETY TRAINING INFORMATION ....................................................... 32
