Fish Tapes
n Industry leading durability
n Wide variety of tapes
and cases to meet your
specific needs
n
Available in Blued Steel™,
Stainless Steel, S-Class®,
Gold-Fish®, Zoom™ and
Volt-Guard™ to meet all
industry applications
n
Specific types for pushing
power, fishing bends and
non-conductive needs
Length marked! Now
laser etched in 12”
increments to provide
instant conduit length.
Why IDEAL?
Visit www.idealindustries.com, click the Fish Tape
link and watch our Drop Test video today!
Kink Resistance Test (Blued Steel™)
The test was performed by supporting the sample
at two points (3.8 in. apart) and then exerting
a force centrally between the two points. The
maximum force that the wire would exert upon,
1 in. of deflection was recorded.
Importance: The better a tape resists kinking
the longer it will serve you. Kinked tape is
almost impossible to push through conduit.
Kink resistance tape makes your job easier.
Ease of Real-Out Test (Blued Steel™)
This test was performed by connecting a force
gage to the hook of the wire and then pulling
out the wire at a slow pace for about 10 ft. The
fish tape case was held by a person. Three
easurements were taken and the average appears.
Importance: An easy reel out allows you to
finish the job faster without straining your body.
Wire Straightness Test (Blued Steel™)
This test was performed by placing each sample of
wire on a table such that it was touching two pins
that were 3 ft. apart. (A straight edge connected
the two pins.) Each sample was pressed toward the
straight edge and then slowly released until the wire
came to rest at an equilibrium state. The maximum
distance from the wire to the straight edge was
recorded.
Importance: The straighter the steel as it pays out
of the fish tape case the further and easier it will
push down conduits.
Tuff-Grip™ Pro...
Industry’s Leading
Fish Tape!
Exceptionally Durable
Case
Tuff-Grip™ Handle
Large, comfortable
ergonomically-designed,
grasp from the top or side.
Allows for use with gloves.
Available in:
Blued Steel™
Stainless Steel
Zoom™ Jacketed Stainless Steel
Gold-Fish® Brass Plated Steel Coil
S-Class® Nylon Jacketed
Fiberglass
Volt-Guard™ 1000V Non-Conductive
Fiberglass
Full-perimeter handle
band helps keep dirt
and moisture out,
prolonging life
Tuff-Cuff™ tape
retaining feature
keeps tape properly
positioned in the
opening.
Length marked!
Now laser etched in 12”
increments to provide
instant conduit length.
Tuff-Grip™ Pro
25 ft. Drop
Resistant Test
Why IDEAL?
Drop Test
Fish tape samples were subjected to a 25 ft. drop onto concrete. All
samples were new and dropped side by side, under the same conditions,
and at the same time. After each drop the samples were examined for
structural damage.
Importance: Strong, durable, long lasting
28
27
26
25
24
23
22
21
Number of lbs. of Max Force
Fish Tape Wire – Kink Resistance
COMPET IT IVE M ODELS
F
3.8”
Wire Straightness
3 ft. Length of Fish Tape
COMPET IT IVE M ODELS
8
7
6
5
4
3
2
1
0
Pull-Out Force (lbs.)
COMPET IT IVE M ODELS
Easiest!
Ease of Reel Out
(Lowest lbs. of force = easiest reel out)
25
20
15
10
5
0
Number of Drops
CO MPET IT IVE MO DE LS
25 ft. Drop Resistant
Fish Tape Cases & Material
Fish Tape Cases and Handles
Fish Tape Materials
Laser etched in 12” increments to
provide instant conduit length
Unique finish is non-oily and
resists rust
Multiple options in width, length
and eyelet for ease of use
Industry’s straightest wire
Stiffer for long runs
Highest grade carbon steel
Tensile strength 1,600 lbs.
Laser etched in 12” increments to
provide instant conduit length
Won’t rust or corrode in damp
locations or humid environments
Super clean finish prevents marks
on walls or carpets
Great for wet or corrosive work
environment
Smoother pay-out
Tensile strength 1,600 lbs.
Brass-plated coiled steel resists
rust
No “memory” – hangs straight
after being coiled for long periods
Kink proof
Excellent for multiple bends
Non-conductive to 1000V
Rectilinear profile for superior
pushing power
Designed for use around live
circuits
19 strand twisted
radial steel core
encased in high
molecular density
outer jacket.
19 strands of stainless steel
Ultrahard nylon jacket adds
slipperiness, protects cables and
the user’s hands
Excellent for corrugated plastic
conduit
Excellent for multiple bends or
wet/corrosive work environment
The only one in the industry
Non-conductive tape designed for
use around live circuits
Strong S-Class® core for longer
life and greater pushing power
Smooth nylon jacket provides
great handling around bends
Omni-directional pushing
Tuff-Grip™ Pro
Tuff-Cuff™ tape retaining feature keeps
tape properly positioned in the opening
Full-perimeter handle band helps keep dirt
and moisture out.
Superior pull-out and rewind characteristics
Exceptionally durable case and handle
Thumb Winder™
Convenient 7 in. size can be stored in tool bag
Durable, impact resistant ABS case
Easy-to-use thumb-operated rewind
Great for datacomm and small-sized
conduit applications
Rapid-Pak®
Inner rotating reel with winding knob retrieves
tape faster than traditional fish tapes for
increased labor savings
Funneled tape opening reduces kinking and
tape breakage
Reversible, hinged knob for right or left
handed rewinds
Stationary handle for extra durability
Impact-resistant plastic case
Pro Handle
New vertical grip allows for faster payout and rewind
Ergonomically designed handle puts less strain on
your wrist
Large hand opening allows for use with
gloves
Attached to the exceptionally durable
Tuff-Grip™ Pro Case
*On select S-Class
® and Zoom™ Fish Tape Models.
™
