Sida 1/8
Powered by
Ethernet
over Coax
Transceiver
DA-EC1101R
DA-EC1101T
Operation Manual
2
Before Using the Product
FCC Compliance Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at
his own expense.
User’s Caution Statement
Caution: Any changes or modifications to the equipment not expressly approved by the
party responsible for compliance could void your authority to operate the equipment.
Product Overview
DA-EC1101R / DA-EC1101T is a networking device(EOC: Ethernet Over Coax) that uses
coaxial cables. It makes it possible to supply Power over Ethernet and transmit data
between a network camera that uses RJ45 port and a DVR using coaxial cables.
3
Product Features
●Makes it possible to install Full-HD network cameras using existing coaxial cables.
●10/100Base-T two-way communication allows use of the product as a transmitter or
a receiver.
●Supports PoE (IEEE 802.3af, IEEE 802.3at)
●Supports Plug & Play without setting up special IP addresses.
●Supports up to 800 meters in distance.
Accessories
The product consists of the following components.
BNC
48VDC
RJ45
Power
PoE
Mac Address
Main unit
(DA-EC1101R /
DA-EC1101T)
48V DC adapter &
220V power cable
(DA-EC1101R only)
Operation Manual MAC address
sticker
MAC Address is required for warranty services. Please keep the sticker attached on the product.
First, connect the adapter to the product. Then, turn the device On. If the adapter is connected while the
switch is turned On, it may cause an electric spark. Be careful when using the product at a gas station or
near combustible substances.
