GB TABLE OF CONTENTS

INSTALLATION PAGE 13

ELECTRICAL CONNECTION PAGE 14

BEFORE USING THE OVEN PAGE 15

PROTECTING THE ENVIRONMENT PAGE 15

PRECAUTIONS AND GENERAL

RECOMMENDATIONS PAGE 15

OVEN ACCESSORIES PAGE 16

COOKING CHART PAGE 17

CLEANING THE OVEN AND ACCESSORIES PAGE 18

TROUBLESHOOTING GUIDE PAGE 19

AFTER-SALES SERVICE PAGE 20

DECLARATION OF CONFORMITY CE PAGE 20

53932-gb.fm5 Page 12 Wednesday, April 4, 2001 3:38 PM

Technical information for the installer

•After removing the oven from its packaging,

before making the connections place it on the

polystyrene foam base to protect it from

damage.

•Do not attempt to lift the oven by the handle.

Lift at the sides as shown in the figure (see

arrow).

•Check that the appliance has not been

damaged in transit.

•Oven dimensions and kitchen unit

dimensions are shown in the opposite figure.

•Kitchen units in contact with the oven must

be heat resistant (80° C min).

•Install the oven in the housing, lifting it at the

sides, taking care not to trap the wires of the

electrical supply cable.

•For correct ventilation, follow the ventilation

opening directions shown in the figure

(500 min x 80 mm and 500 min x 50 mm

inside the cabinet).

•Secure the oven to the kitchen unit with

screws (A) as shown.

•The oven has also been designed for

building-in under a cooktop.

NOTE: To allow for proper ventilation, we

recommend that you left an opening of at least

500 x 80 mm or an equivalent area in the lower

section of the housing.

An additional opening of 5 mm is required

between the oven top rim and the cooktop lower

rim: this opening must not be closed by strips or

housing crosspieces.

During oven installation, care must be taken to

ensure that the sides are not touching the front

edges of the housing or adjacent drawers and

doors (see picture).

INSTALLATION

No contacts

53932-gb.fm5 Page 13 Wednesday, April 4, 2001 3:38 PM

•Warning: Do not connect to the power

supply before you have finished

connecting the oven.

•Make sure the oven is installed and

connected to the electricity supply by a

qualified technician in accordance with

the manufacturer’s instructions and in

compliance with local regulations.

•The installer is responsible for the correct

electrical connection of the oven and the

observance of the relative safety

regulations.

•The oven must be connected to the

electricity supply by means of an all-pole

disconnect switch with minimum contact

gap of 3 mm.

•The oven must be earthed by law.

•Do not use multiple plug adapters or

extension leads.

•After the oven has been installed, the

electrical components must be

inaccessible.

•Make sure that the voltage shown on the

rating plate is the same as the power

supply voltage in your home. The rating

plate is on the front edge of the oven

cavity (visible with oven door open).

ELECTRICAL CONNECTION

53932-gb.fm5 Page 14 Wednesday, April 4, 2001 3:38 PM
