EN
Quick guide
THANK YOU FOR BUYING OUR PRODUCT. Before using the appliance carefully read the Safety Instruction.
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally lled
appliance. Position the antibacterial anti-odour lter in the fan as
demonstrated in the lter packaging (if available). If the audible signal
sounds, it means that the temperature alarm has intervened: press the
button to switch o the acoustic alarms.
CONTROL PANEL
1. LED Light
2. On/Stand-by
3. Freezer and refrigerator compartment
temperature button
2.
1.
3.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance o. In
Stand-by mode the light in the refrigerator compartment does not turn
on. Press the button again briey to reactivate the appliance.
Note: this does not disconnect the appliance from the power supply.
FREEZER AND REFRIGERATOR
COMPARTMENT TEMPERATURE
The three LED indicators indicate the refrigerator compartment
set temperature. It is possible to set a dierent temperature of the
appliance with the button.
Recommended setting: MEDIUM
The following adjustments are possible:
LEDs lit Set temperature
High (less cold)
Medium-high
Medium
Medium-low
Low (colder)
Fast cool
To avoid food waste, please refer to the recommended setting and storage
times found in the online user manual.
HOW TO STORE FRESH FOOD AND BEVERAGES
*
Legend
TEMPERATE ZONE
Suggested for storage of tropical fruit, cans, drink, eggs,
sauces, pickles, butter, jam
COOL ZONE
Suggested for storage of cheese, milk, daily food,
delicatessen, yoghurt
COOLEST AREA
Suggested for storage of cold cuts, desserts, meat and
sh
* Available only on certain models
* Available only on certain models
REFRIGERATOR COMPARTMENT
Light system (depending on model)
This product contains a light source of energy
eciency class G
This product contains 4 lateral light sources of
energy eciency class F
This product contains a light source of energy
eciency class G
This product contains 4 lateral light sources of
energy eciency class F and a top light source
of energy class G
This product contains a top light source of
energy eciency class G
FREEZER COMPARTMENT
Freezing fresh food
1. It is advisable to set the temperature colder or turn on the Fast Freeze/
Fast Cool* at least four hours before removing the food from the
freezer compartment, to prolong the preservation of the food during
the defrosting phase.
2. To defrost, unplug the appliance and remove the drawers. Leave
the door open to allow the frost to melt. To prevent the water from
escaping during the defrost, it is advised that you place an absorbent
cloth on the bottom of the freezer compartment and wring it out
regularly.
3. Clean the inside of the freezer compartment and dry it carefully.
4. Turn the appliance back on and put the food back inside. To remove
the frost on the STOP FROST* accessory, follow the CLEANING.
Ice cubes*
Fill 2/3 of the ice tray with water and put it back in the freezer
compartment. Do not, under any circumstances, use sharp or pointed
objects to remove the ice.
The quantity of fresh food that can be frozen in a specic time period is
indicated on the rating plate.
Load limits are determined by baskets, aps, drawers, shelves etc. Make
sure that these components can still close easily after loading.
GENERAL INFORMATION
The drawers, baskets and shelves should be kept in their current position
unless otherwise specied in this quick guide. The light system inside the
refrigerator compartment uses LED lights, allowing for better lighting than
with traditional light bulbs, as well as for very low energy consumption.
Doors and lids of the refrigeration appliance should be removed before
disposal in the landll, to avoid children or animals getting trapped inside.
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Visiting our website docs . whirlpool . eu and parts - selfservice . whirlpool . com
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product's identication plate.
The model information can be retrieved using the QR-Code indicated on the energy label. The label also includes
the model identier that can be used to consult the https://eprel.ec.europa.eu database portal.
* Available only on certain models
Note: If the chiller declaration is present in the rating plate (see image below), the declaration applies only to standard EN 62552:2013 valid until February 28th, 2021.
TROUBLESHOOTING
What to do if... Possible reasons Solutions
The control panel is
switched o, the appliance
does not work.
There may be an appliance power supply
problem.
Check that:
• there is not a power outage;
• the plug is properly inserted in the socket and any bipolar power
switch is in the correct position (this enables the power supply to
the appliance);
• the household electrical system protection devices are ecient;
• the power cable is not damaged.
The appliance could be in On/stand by
mode. Turn the appliance on by briey pressing the button (see On/Stand-
by function).
The inside light does not
work.
The light may need to be replace.
Malfunction of a technical component.
Disconnect the appliance from the power supply and contact the
Technical Assistance Service if you need a replacement.
The inside light ashes. Door alarm active.
It is activated when the refrigerator
compartment door remains open for a
prolonged period of time.
To stop the alarm, close the refrigerator door.
On reopening the door, check the light works.
The temperature inside the
compartments is not low
enough.
There could be various causes (see
“Solutions”).
Check that:
• the door closes properly;
• the appliance is not installed near a heat source;
• the set temperature is adequate;
• the circulation of air through the vents at the bottom of the
appliance is not obstructed (see installation section).
There is water on the
bottom of the refrigerator
compartment.
The defrost water drain is blocked. Clean the defrosting water drain (see section “Cleaning and
Maintenance").
Excessive amount of frost in
the freezer compartment.
The door to the freezer compartment is
not closed properly.
Check that there is nothing preventing the door from closing properly.
• Defrost the freezer compartment.
• Make sure the appliance has been correctly installed.
The front edge of the
appliance that the door
gaskets seal against is hot.
This is not a defect. It prevents
condensation from forming.
No solution is necessary.
One or more green symbols
are ashing continuously
and it is not possible to
change the temperature
set.
Malfunction alarm.
The alarm indicates a fault in a technical
component.
Contact Technical Assistance Service.
The temperature of the
refrigerator compartment is
too cold.
• The set temperature is too cold.
• A large amount of fresh food may
have been placed in the freezer
compartment.
• Try to set a less cold temperature.
• If fresh food has been placed in the freezer compartment, wait
until it has fully frozen.
• Turn o the fan (if present) following the procedure described in
the paragraph “FAN”.
