Sida 1/2
1-5/8"
42mm
5-1/8"
130mm
3-3/16"
80mm
5-1/4"
133mm
6-1/4"
158mm
3-11/16"
93mm
4-3/16"
105mm
3"
76mm
1-15/16"
48mm
7/16"
11mm
R E F E R E N C E
6432cfp
Declaration of Conformity
We,Harman Consumer Group,Inc.
2,route de Tours
72500 Château du Loir
France
declare in own responsibility that the product described in this owner’s
manual is in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group,Inc.
Château du Loir,France 1/09
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.
Features, specifications and appearance are subject to change without notice.
Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman Consumer Group, Inc.,250 Crossways Park Drive,Woodbury, NY 11797 USA
www.infinitysystems.com
© 2009 Harman International Industries,Incorporated.All rights reserved.Tous droits réservés. • Part No. REF6432OM1/09
Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries,Incorporated, déposée aux États-Unis et/ou dans d’autres pays.
2x 1x
BL (T-m) 3.82 Vas (l) 2.48
DCR (ohms) 2.30 Fs (Hz) 88.1
Mms (g) 7.46 Qes 0.65
Sd (sq cm) 63.6 Qms 9.61
Cms (µm/N) 437 Qt 0.61
SPECIFICATIONS
Type: 4" x 6" 2-Way Custom-Fit Plate Power Handling, Peak: 135W
Impedance: 2 Ohms Frequency Response: 72Hz – 21kHz
Power Handling, RMS: 45W Sensitivity (2.83V, 1m): 91dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
Type: 4" x 6" 2-Way Custom-Fit Plate Power Handling, Peak: 135W
Impedance: 2 Ohms Frequency Response: 72Hz – 21kHz
Power Handling, RMS: 45W Sensitivity (2.83V, 1m): 91dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
Type: 4" x 6" 2-Way Custom-Fit Plate Power Handling, Peak: 135W
Impedance: 2 Ohms Frequency Response: 72Hz – 21kHz
Power Handling, RMS: 45W Sensitivity (2.83V, 1m): 91dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting
for this swi is the tch “0dB” position, which
provides an apparently “flat” response.
Tweeter output may be increased accord-
ing to the user’s ference, or to compen-pre
sate for off-axis placement (where the
speaker does not directly face the listen-
ing position), by setting the switch to the
“+3dB”position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting
for this switch is the “0dB”position, which
provides an apparently “flat” response.
Tw ter output may be increased accord-ee
ing to the user’s preference, or to compen-
sate for off-axis placement (where the
speaker does not directly face the listen-
ing position), by setting the switch to the
“+3dB”position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting
for this switch is the “0dB”position, which
pro ently“flat”response.vides an appar
Tweeter output may be increased accord-
ing to the user’s preference, or to compen-
sate for off-axis placement (where the
speaker does not directly face the listen-
ing position), by setting the switch to the
“+3dB”position.
