Owner’s Manual
®
Theater Pac
2-Way Universal-Mounting
Satellite Loudspeakers
US
1
2◆US-1 Theater Pac – Owner’s Manual
2-W
AY
U
NIVERSAL
S
ATELLITE
S
YSTEM
...
A
BOUT
T
HIS
M
ANUAL
...
P
ARTS
L
IST
...
T
OOLS
A
ND
S
UPPLIES
(N
OT
E
NCLOSED
)...
INTRODUCTION
The Infinity US-1 is a compact, efficient 2-way universal satellite speaker system that is ideal
for reproducing home-theater sound for front or rear channels. With their versatile design, US-1
speakers can be placed virtually anywhere on shelves or stands, or mounted on a wall or ceiling,
using the integral 4-way mounting bracket. It has crossholes for mounting and also acts as a door
which hides the mounting terminals. The US-1 Theater Pac contains five US-1 satellite speakers.
To start enjoying your new US-1 Theater Pac, rst read and then perform all instructions
listed in this manual, as well as those found in the owner’s manuals of associated components in
your audio system. Save all instructions for future reference. These speakers are covered by
a limited ve-year warranty, so save the bill of sale to protect your purchase and aid in any
service-related questions.
UNPACKING THE PEAKERSS
Carefully unpack the speakers. If you suspect damage from transit, report it immediately to your
dealer and/or delivery service. Keep the shipping cartons and packing materials for future use.
Open the accessory pack and verify the following contents:
◆(5) US-1 Speakers
◆Owner’s Manual and Warranty Registration Card
◆Hex wrench, 5⁄32" (4mm)
You may also need the following tools and supplies:
◆High-quality speaker wire (also see Wiring the System on page 7)
◆Necessary wall-mounting hardware
◆Wire strippers
US-1 Theater Pac – Owner’s Manual ◆3
Figure 1. In this overhead view of a typi-
cal 6-piece home entertainment system,
US-1 speakers are used to reproduce
sound for the front, center and surround
channels. An Innity powered subwoofer
(optional) is shown providing extra
bass for eects and music.
F
RONT
C
HANNELS
...
C
ENTER
C
HANNEL
...
S
URROUND
C
HANNELS
...
P Y SLANNING OUR YSTEM
US-1 speakers can be used to reproduce sound for either front or surround channels. Before
deciding where to place your US-1 speakers, survey your room and study Figure 1 to determine
the best placement.
PLACEMENT
NOTE: US-1 speakers can be placed directly on a shelf or mounted on a wall, using the built-in
bracket (see Figures 2 through 5).
For front left and right channels, place one US-1 speaker on the left and another on the right,
along either side of the television monitor.
For the center channel, place one US-1 speaker directly on top of, or below, your
television, either vertically or horizontally.
Since the speakers are magnetically shielded, you can place them very close to the TV without
worrying about the magnetic eld distorting the TV picture.
For surround left and right channels, place one US-1 speaker on the left and another on the right,
to the side of, or behind the listening area.
TELEVISION
SOFA
US-1 SPEAKER
For Left Channel
INFINITY POWERED
SUBWOOFER
(optional)
US-1 SPEAKER
For Right Channel
US-1 SPEAKER
For Left Surround
US-1 SPEAKER
For Right Surround
US-1
SPEAKER
On Top of Television
For Center Channel
