INNOVV C5

WiFi Full HD Remote Lens

Motorcycle Camera System

User Manual

Format MicroSD card to be FAT32

App download and Operation

Please follow instrucons below to download the INNOVV C5 mobile WiFi app for both Android & iOS.

Please follow instrucon below to format MicroSD card to be FAT32 before recording begins.

Please do not aempt to repair, modify, or alter this product and/or it’s accessories.

Follow one of below methods to format MicroSD card to be FAT32

Formang by App- App => Seng =>Formang => Yes ( Red power buon quick ﬂashes)

Formang by buons- 1. Press red power buon once to stop ﬂashing (Solid red), 2. Press WiFi buon (Flashing) for 8 seconds. Red buon power oﬀ and power on again (Solid red).

Formang on PC- if SD card is more than 32GB, download SD card formaer from hps://www.sdcard.org/downloads/formaer_4/

1 Downloading the App

2App Connection

APP Screen Shots

3Recording

a) Search and download INNOVV C5 on the Google Play Store for Android or the App

Store for Apple devices. Compable with iOS 8.3 or Android 5.1 above.

b) Scan QR code below to download INNOVV C5 App right to your device.

C) Storage must be allowed from App permissions for downloading videos/photos from

camera to your device.

F A d d D vor n roi e ice F App D vor le e ice

INOVV C5 App Logo

Select INNOVV_C5_*** from WiFi networks to connect

Sengs => Wireless & networks => INNOVV C5

Default password is 12345678

C k to enter into recording secon.lic

R d d ﬂ h g m y m d g, C k p d g, d C k d g.e ot is as in if ca era s ste is recor in lic to sto recor in an lic to start recor in

to a just ri tness d b gh . To view full screen video To exit full screen video.

ac u onb k b 

C k T v d g d ph .lic o re iew recor in s an otos

Recordings and photos can be toggled to play, review, download or delete.

Package included

Trouble Shooting

Key Indicator and Function

1x DVR,

1 x Lens with video cable,

1 x DC 12v to 5v converter,

1 x Bracket pack for lens,

1 x Bracket pack for DVR,

1 x SD Card Reader,

1 x User Manu,

Memory Card not included

Please refer to our troubleshoong

instrucons below for any problems or

errors that may arise. Please also contact

your INNOVV dealer for addional

informaon and guides.

Operation and LED Indicator

Operation

Live recording

Recording stop

Power Button (Red Color)

Flashes red (1 times / second)

Solid Red

Photograph

WiFi Connection stand-by

WiFi Connected

WiFi Terminated

No Micro SD Card

SD Card Formating

Firmware Upgrading

Quick flashes red (3 times / second)

Flashes red or solid red

Flashes red quickly (3 times / second)

Solid Red => Off => Solid Red

Flashes red (1 times / second) =>

(1 times / second)=> Red Off

WiFi Button (Green Color)

Flashes green (1 times / second)

Flashes green or solid green

Solid green

Flashes green flash slowly

Flashes green or solid green

Power Button

WiFi Button

USB Port

Trun ignition on, after 10 seconds power on delay, power button flashes red,

recording starts.

Power button is solid red and record stop

WiFi button flashes green after recording started. And WiFi is stand-by for connection.

A successful and continuous WiFi connection will be indicated by a solid green ligh.

Press WiFi button to drop the connection, WiFi flashes green again.

Works as factory service port only, not for powering

Hold down reset key to trigger a device reboot in case of error.

Reset Key

WiFi connected, can not

access App or App is

processing only

SD card in DVR,

no recording after

power supplied.

SD card in DVR,

no recording after

power supplied.

Can not download

videos/photos from

camera to device.

Live recording disapear

after device on screen

lock mode.

WiFi button solid green

Power button flashes

red or slid red

WiFi button flashes green

Power button solid red

WiFi button off

Power button off

1. WiFi has been disconnected

1. SD card was unreadable

2. SD card was broken or low speed

3. Loop Video was Off, SD card was fulfilled

5. Video calbe was bended or pinch point,

even broken

6. Wrong settings or System broken

1. Too low power supply from the power

source

2. Wires from 12v to 5v converter made

wrong connection to the power source

3. In line fuse from 12v to 5v converter

was blew.

4. DVR is overheat

INNOVV C5 app is not allowed to store

data to your device.

Screen locked and living recording can not

displayon the lock screen

Storage must be allowed from App permissions for

downloading videos/photos from camera to your device.

Settings => App Permissions => INNOVV C5 => Storage

Settings => App => INNOVV C5 => Storage

Display on the lock screen

Settings => App => INNOVV C5 => Notifications

4. Unstable connection between lens cable

and DVR

Turn WiFi network On and OFF, then reconnect.

Move Mobile device close to Camera system and

reconnect WiFi

Follow up the instruction to format SD card

Change SD card to be high speed (Class 10 or Above)

Change SD card or Format SD card

Disconnect Type c connector and re-connect.

Check video cable

Reset camera system, or Re-install firmware

Replace the inline fuse.

DVR cool down, press reset button.

Check power supply.

Correct wire connection.

Upgrade or change the mobile devices

2. The distance between Mobile device &

Camera system is too far, or the WiFi singal

was blocked

3. The mobile device is not compatible, WiFi

connection is weak

Fault Button Indicator Causes Operation

Trouble Shooting

INNOVV C5

WiFi Full HD Remote Lens

Motorcycle Camera System

Installation Guide

Product Over View

Installation Reference

Camera Bracket Installation

Do not push Lens!

1.DVR

2.WiFi Buon

3.Power Buon

5.Lens Cable

4.Lens

6.Power Cable

7.Lens Plug

8.Thumb Screw

9.Power Cable Connector

10.12V to 5V DC Converter

11.DVR Holder

12.External Mic

13.Internal Mic Hole

14.Mini USB Port

15. Reset Hole

16. SD card Slot

12V DC Converter Connection

Installation Instructions

Camera and DVR Connection

Locate a posion that will allow the best view.

Ensure the mount is secure and will not interfere with the operaon of the motorcycle. Consider the range of moon on the front forks of a motorcycle.

The camera may be mounted in several posions using the provided mounng accessories. Ensure you do not unscrew camera case or it may cause damage to lens inside.

Route the camera cable in a safe manor back to the DVR locaon. Ensure the cables are not subjected to a pinch point or in an area that will expose it to high temperature from the engine, and keep cable away

from all of the other cables (parcularly head light, tail light cables) to avoid EMI (Electro-Magnec Interference).

The C5 is designed to start/stop recording when the ignion is turned on/oﬀ.

The yellow wire from the supplied DC 12V to 5V converter is to connect the switched power source which has power only when the main ignion switch is on. Red wire is to connect the reliable and stable 12V

power source, like the posive terminal of baery. Black wire is to ground connecon.

Please keep a distance between DVR and Converter.

USB port beside of memory slot work as factory service port only, not for powering.

The C5 has an internal Mic to record audio. An external microphone (not included) can also be connected to the camera to record communicaons, etc.

Input Wires Connecon:

Red Wire: + (Posive Baery Terminal), Black Wire: - (Negave

Baery Terminal)

Yellow Wire: To 12V Switched Power Source, that is to trigger

power supply from power source to camera system when

ignion is on.

OUTPUT: DC 5V 2A (Max).

There is 10 second delay for ignion power on or power oﬀ.
