QUICK SETUP GUIDE
Color Changing
2.1 Computer
Speakers with
Bluetooth
NS5004BT
CONNECTING WITH BLUETOOTH
1 Make sure that your Bluetooth device is turned on and
within 33 feet (10 meters) of your speakers.
2 Turn on your speakers. The status LED blinks blue to
indicate that they are in pairing mode. If the status LED
is red, press the button once to switch to Input
Bluetooth mode.
3 Turn on your Bluetooth device, then turn on Bluetooth.
Set your device to pairing mode, then select Insignia
NS-5004BT. See the instructions that came with your
Bluetooth device for information about pairing.
4 If you are asked for a password, enter 0000. When
pairing is complete, the status LED lights solid blue.
STATUS LED
RECONNECTING WITH A PREVIOUS DEVICE
• Make sure that the last paired Bluetooth device is near
your speakers.
• When your speakers are on, they automatically search
for and try to connect to the last paired device.
FORCE PAIRING AND CONNECTING WITH A
NEW DEVICE
• If you have paired your speakers to a device and want
to pair with a dierent device, press and hold the Input
button for three seconds until the blue LED begins
blinking. Search your new device’s Bluetooth list for
Insignia NS-5004BT, then tap to pair and connect.
USING A WIRED CONNECTION
1 Connect an external sound source, such as an MP3
player, by plugging the included audio cable into the
AUX jack on the back of your control pod and the
sound source.
2 Press the Input button to enter AUX mode. The status
LED lights red.
Front
Control pod
CONNECTING THE SPEAKERS
1 Plug the satellite speakers into the To Speaker jack on
the back of the subwoofer.
2 Plug the power cable into a power outlet or surge
protector.
TURNING YOUR SPEAKERS ON AND OFF
• Slide the ON/OFF on the control pod to the left to turn
on your speakers or right to turn o your speakers.
When you rst turn on your speakers, they are in
Bluetooth pairing mode and the status LED blinks blue.
Before using your new product, please read these instructions to prevent any damage.
STATUS LED
Blinks blue
Solid blue
Solid red
DESCRIPTION
Speakers are in pairing mode
Speakers are paired
AUX mode
3.5 mm audio cable
PACKAGE CONTENTS
• Satellite speakers (2)
• Subwoofer
• Control pod
• 5 ft. (1.52 m) 3.5 mm to 3.5 mm audio cable
• Quick Setup Guide
FEATURES
• Eight color modes (blue, green, red, purple, yellow,
light blue, repeating six colors, and o) help set the
mood
• 25W RMS:
• 16W RMS subwoofer
• 9W RMS satellites (4.5W + 4.5W)
• Bluetooth connectivity wirelessly streams audio from
your Bluetooth-enabled devices
• 3.5 mm input jack lets you connect to external sound
sources
• Headphone jack provides an easy connection option
for private listening
Master
volume control
Status LED
Input button
AUX
input jack
Headphone jack
Light button
RIGHT LEFT
Back of speakers
Bass volume control Power cord
Power on/o
V2 ENGLISH 19-0173
SPECIFICATIONS
Dimensions (H×W×D): 7.3 × 14 × 7.3 in.
(185.4 × 355.6 × 185.4 mm)
Wattage: 25W total (16W sub, 4.5W for each satellite speaker)
Range: 32.8 ft (10 m)
Power cord length: 5.5 ft (1.67 m)
SAFETY INSTRUCTIONS
1 Read, follow, and save all instructions and documentation.
2 Do not use this apparatus near water.
3 Clean only with a dry cloth.
4 Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
5 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
6 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
7 Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
8 Only use attachments/accessories specied by the manufacturer.
9 Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
10 Unplug this apparatus during lightning storms or when unused for long periods of time.
11 Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in an way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
12 Keep the unit in a well-ventilated environment. Do not install this equipment in a
conned space such as a bookcase.
13 : To reduce the risk of re or electric shock, do not expose this device to WARNING
rain, moisture, dripping, or splashing, and no objects lled with liquids, such as
vases, shall be placed on it.
14 : The wall plug is the disconnecting device. The plug must remain readily WARNING
operable.
15 The apparatus is classied as a class II apparatus.
WARNING: To reduce the risk of re or electric shock, do not expose this appliance to
rain or moisture.
CAUTION: Use of controls or adjustments or performance of procedures other than
those specied may result in hazardous radiation or exposure.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be sucient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
LEGAL NOTICES
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Caution:
This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply within the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the reveiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC warning
Changes or modications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user’s authority to operate this equipment.
The equipment complies with FCC Radiation exposure limits set forth for uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
Canada ICES-003 statement
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China
LISTENING TO MUSIC
1 Turn on your speakers, then connect to your audio
device.
2 Press the Input select button to select a Bluetooth or
wired (AUX) connection. The status LED lights blue for
Bluetooth or red for AUX.
3 Begin playback on your device.
4 Turn the master volume control to adjust the volume.
5 Use the controls on your audio device to control
playback.
LIGHT COLOR PATTERN
• Press the LIGHT button repeatedly to select a color for
the LED lighting. The color options cycle as follows:
Blue -> Green -> Red -> Purple -> Yellow -> Light blue ->
Repeating six colors -> Lights o
• Press and hold the button for three seconds to LIGHT
dim the LED lighting by 50%.
• Press the button again for three seconds to return the
lighting to full brightness.
TROUBLESHOOTING
PROBLEM
Sound is distorted
Sound is coming
from one speaker
Can my speakers
connect to a TV,
monitor, soundbar,
DVD player?
Can my speakers be
connected to more
than one device
(3.5mm and
Bluetooth)?
Do my speakers work
with smart home
devices?
SOLUTION
• Adjust the master volume control to the ¼ or ½ level.
• Adjust volume settings on the output device (computer or
audio device).
• Make sure that all connections are correct and secure.
• If your speaker system is connected to a computer, adjust
your computer’s audio levels to balance the sound coming
from the speakers.
• Make sure that all connections are correct and secure.
Yes, if the device has a Bluetooth or an AUX connection.
Yes. Make sure that you select the correct source by pressing
the button.Input
Yes, your speakers work with any Bluetooth device.
PROBLEM
No power
No sound or low
volume
Cannot establish
Bluetooth
connection
My Bluetooth device
keeps unpairing
“Insignia NS-5004BT”
does not appear on
my Bluetooth device
SOLUTION
• Make sure that your speakers are plugged in.
• Make sure that your speakers are turned on.
• Make sure that your Bluetooth device is turned on, Bluetooth
is turned on, and is selected.Insignia NS-5004BT
• Turn up the volume on your speakers.
• Turn up the volume on your Bluetooth device.
• Make sure that your Bluetooth device is not muted.
• Make sure that your speakers are not paired to another
Bluetooth device.
• Make sure that your Bluetooth device is not paired to
another Bluetooth device.
• Shorten the distance between your speakers and your
Bluetooth device.
• Turn your devices o, then on. Re-pair your speakers and
your Bluetooth device.
• Make sure that your speakers are not paired to another
Bluetooth device.
• Make sure that your speakers and Bluetooth device are both
in pairing mode.
• Make sure that your Bluetooth device supports Bluetooth
v4.0 and below.
• Make sure that your Bluetooth device is not connected to
any other device.
• Make sure that you have selected on Insignia NS-5004BT
your Bluetooth device.
• If a passcode is needed, enter 0000.
• Shorten the distance between your speakers and your
Bluetooth device.
• If the battery on your Bluetooth device is low, recharge the
battery.
• Shorten the distance between your speakers and your
Bluetooth device.
• Put your speakers into pairing mode, then refresh your list
of Bluetooth devices. For more information, see the
documentation that came with your Bluetooth device.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

Produktspecifikationer

Varumärke: Insignia
Kategori: högtalare
Modell: NS-5004BT

Behöver du hjälp?

Om du behöver hjälp med Insignia NS-5004BT ställ en fråga nedan och andra användare kommer att svara dig


högtalare Insignia Manualer

Insignia

Insignia NS-5004BT Bruksanvisning

12 Mars 2025
Insignia

Insignia NS-CSPBTF1 Bruksanvisning

12 Mars 2025
Insignia

Insignia Voice NS-CSPGASP-G Bruksanvisning

18 September 2024
Insignia

Insignia Voice NS-CSPGASP-BC Bruksanvisning

18 September 2024
Insignia

Insignia Voice NS-CSPGASP-B Bruksanvisning

18 September 2024
Insignia

Insignia NS-PCS41 Bruksanvisning

18 September 2024

högtalare Manualer

Nyaste högtalare Manualer

Rockustics

Rockustics BlockRock Bruksanvisning

14 Mars 2025
Rockustics

Rockustics Coconutz Bruksanvisning

14 Mars 2025
Monster

Monster MT-401 Bruksanvisning

14 Mars 2025
Monster

Monster MT-F5 Bruksanvisning

14 Mars 2025
Monster

Monster MT-607 Bruksanvisning

14 Mars 2025
Elipson

Elipson Horus 10C Bruksanvisning

14 Mars 2025
Elipson

Elipson INF IW8 Bruksanvisning

14 Mars 2025
Elipson

Elipson INF IW6 Bruksanvisning

14 Mars 2025
Elipson

Elipson BS50 Tribute Bruksanvisning

14 Mars 2025
Elipson

Elipson Heritage XLS7 Bruksanvisning

14 Mars 2025
