Sida 1/2
Voltage
selector
Tips
Connector
FEATURES
• 7 interchangeable tips support devices that need round-pin
connectors
• Manual voltage knob (with 3 V, 4.5 V, 5 V, 6 V, 7.5 V, 9 V, 12 V, 13.5 V,
15 V, 19.5 V, or 24-volt DC output) adjusts to power a variety of
electronics
• Up to 3 A of current for use with high-output devices
• 5 ft. (1.5 m) cord gives you exible placement options
• Illuminated LEDs display your selected voltage
• Voltage knob design protects against accidental setting changes
• Over current protection with fault indicator LED
• 100-240 V input at 50/60 Hz for international use
• Works with positive-polarity devices that need 3-15 V DC (3 A max),
19.5 V DC (2 A max) or 24 V DC (2 A max) output
PACKAGE CONTENTS
• Universal AC adapter
• Adapter tips (7)
• Quick Setup Guide
QUICK SETUP GUIDE
High-Output Universal
AC Adapter
NS-AC3000
POSITIVE POLARITY ONLY
Before using your new product, please read these instructions to prevent any damage.
CHOOSING A TIP
Carefully test the tips by gently inserting them into the DC jack
on your device. Choose a tip that ts snugly, but do not force it
tot.
Note: If you have your old adapter, you can compare the connector on
the old adapter to the available tips.
SETTING UP YOUR ADAPTER
Using DC tips
You can nd your device’s input, polarity, and voltage on the
device itself, on its old adapter, or in its manual. Contact the
manufacturer if you cannot nd this information. Using
incorrect settings could damage your device.
1 Check the input of the device you are connecting to your
adapter. Do not use this adapter if your device requires more
than 3,000 mA (3.0A) of current.
2Check the voltage needed for your device, then select the
proper voltage on your adapter by turning the selector knob
to the desired setting. Do not use this adapter if your device's
voltage is not between 3 and 24 V DC.
3 Check the polarity of the device you are connecting to your
adapter.
• If your device has a positive polarity, connect the chosen tip
to the adapter’s connector.
• If your device has negative polarity, do NOT use this adapter
to power your device.
COMPATIBILITY
Your device is compatible with this adapter if:
• The correct tip is available
• Your device’s voltage is between 3 and 24 V DC
• Your device’s input does not require more than 3,000 mA (3 A) of
current (for DC tips) under 15 V output, and your device’s
input does not require more than 2,000 mA (2 A) of current
(for DC tips) between the 19.5 V-24 V output.
• Your device has a positive polarity
Not compatible with certain computers, monitors,
home theater systems, and other high-current
devices. Contact the manufacturer to obtain the
correct replacement power supply.
Included Tip Dimensions:
2.5 (OD) × 0.75 (ID) × 10.5
+
0.5 (L) Yellow
3.0 (OD) × 1.10 (ID) × 11.0
+
0.5 (L) Black
3.5 (OD) × 1.35 (ID) × 11.0
+
0.5 (L) Red
4.0 (OD) × 1.70 (ID) × 11.0
+
0.5 (L) Yellow
5.5 (OD) × 1.50 (ID) × 12.0
+
0.5 (L) Black
5.5 (OD) × 2.10 (ID) × 12.0
+
0.5 (L) Blue
5.5 (OD) × 2.50 (ID) × 12.0
+
0.5 (L) White
OD = outer dimension
ID = inner dimension / L = length
Front
Back
Fault LED
Voltage
LEDs
BE
CAREFUL!
USING YOUR ADAPTER
Warning: If your device does not work, immediately unplug the adapter,
then check the voltage and polarity settings. Do not attempt to power
multiple devices at the same time through the tip and USB connections.
• Connect the adapter to your device, using one of the available DC
tips, then connect it to a power outlet. Use or charge your device
as usual.
TROUBLESHOOTING
My device isn’t working.
• Immediately unplug the adapter.
• Check the polarity of your device. If your device has a negative
polarity, do NOT use this adapter.
• Make sure that your device requires less than the 3,000 mA
(3 A) at 3 V-15 V and less than the 2,000 mA (2 A) at
19.5 V-24 V.
• Make sure that the voltage selector is set to the correct voltage.
• Make sure that you have selected the correct tip.
My adapter is hot.
• It is normal for an adapter to feel warm during use. Make sure that
it is placed in a well-ventilated area.
• If your adapter feels abnormally hot, check your adapter’s settings
and make sure that it is compatible with your device.
SPECIFICATIONS
• : 5 ft. (1.5 m)Cable length
• Input: 100-240 V AC
• Output:
•
3 V, 4.5 V, 5 V, 6 V, 7.5 V, 9 V, 12 V, 13.5 V, or 15 V, DC 3,000 mA (3 A) max
• 19.5 V, or 24 V DC 2,000 mA (2 A) max
LEGAL NOTICES
FCC Statement
Caution: Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Canadian Notice
CAN ICES-003 (B) / NMB-003 (B)
V2 ENGLISH 21-0354
Check out these important safety
instructions to keep yourself and your
devices safe.
Warning: Identifying the correct voltage and polarity settings and
adjusting the product is the user’s responsibility.
• This adapter should only be used with a 100 - 240 Vac power
outlet. Follow all necessary safety precautions.
• Not recommended for use by children.
• Failure to adjust the adapter settings to match your connected
device’s requirements can result in damage to the device.
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and Canada)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2021 Best Buy. All rights reserved.
