(286PO) RECHARGEABLE HANDHELD VACUUM ENGLISH SIZE: 4.875” X 7.25” 10/21/2019
286
PO
SAVE THESE INSTRUCTIONS
Page 1 286-*PO-R0-2011
INTEX® OWNER'S MANUAL
RECHARGEABLE HANDHELD VACUUM
Model CL1704
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
• Assembly and disassembly by adults only.
• This is not a toy. Do not allow children to play with this product.
• Do not use if unit is damaged in any way. Replace damaged components promptly.
• This vacuum creates suction. Keep hair, loose clothing, fingers, and any body parts
away from openings and moving parts.
• Use only accessories and replacement parts specified in this manual.
• Never leave this product plugged into the main outlet for long term storage.
• Never leave this product in the water when it is OFF or has run out of battery power.
• Do not use this product for pool opening (start of the season). This product is design
for routine general maintenance of your pool or spa. Do not use for cleaning of longer
accumulated heavy dirt such as at the start of the pool season.
• This product is designed for underwater use: must be submerged to operate properly.
Do not use this product as an all-purpose vacuum cleaner.
• Do not use this product without the filter bag and/or vacuum body cover.
• Do not vacuum sharp objects, as this may damage the filter bag.
• Do not vacuum toxic substances, flammable or combustible liquids such as gasoline, or
operate in the presence of explosive or flammable fumes.
• Never insert or drop objects into any opening on the device. Keep all openings free of
leaves, debris, or anything that may reduce the water flow.
• Always turn off and unplug the device before cleaning, servicing, changing the filter bag
or any routine maintenance.
• Keep the charging USB cable away from sharp objects and hot surfaces.
• Do not charge the product with a damaged charging USB cable and/or a damaged plug
charger.
• Charge the product indoors in a clean and dry place. Do not expose to rain or extreme
temperature and do not handle with wet hands during charging. Never charge the
product while operating it.
• This product contains sealed nickel metal-hydride (Ni-MH) rechargeable batteries.
Do not dispose of product in regular trash, municipal waste stream or by fire as the
built-in rechargeable battery may leak or explode. Always dispose of the batteries in
accordance with your local law and regulations.
• This product is intended to be used only for the purposes described in the manual.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE
OR OTHER INJURY.
WARNING
(286PO) RECHARGEABLE HANDHELD VACUUM ENGLISH SIZE: 4.875” X 7.25” 10/21/2019
286
PO
SAVE THESE INSTRUCTIONS
Page 2
PARTS LIST
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
1
2
3
4
5
9
10
8
7
6
REF. NO.
DESCRIPTION QTY.
SPARE PART NO.
1
VACUUM BODY WITH NON-REPLACEABLE BATTERY
1 12271A
2 1 12278FILTER BAG WITH GASKET
3 1 12277VACUUM BODY COVER
4 1 12274LARGE VACUUM BRUSH HEAD
5 1 12275VACUUM NOZZLE
6 1 12276VACUUM NOZZLE BRUSH
7 1 12279MICRO-FILTER BAG
8 1 12269VACUUM CHARGING USB CABLE
9 1 10637TELESCOPING ALUMINUM POLE
10 1 12270POLE ADAPTOR
General:
• Plug charger not included. Only use a compatible standard female USB (smartphone or
tablet) plug charger with an output voltage of 5-5.2V DC, 1A.
• A full charge takes about 8-10 hours: provides about 40-50 minutes of operation.
• Make sure the charging receptacle on the product is dry before any recharging.
Charging the Battery:
1. Connect USB cable to plug charger USB receptacle and
plug the charger into the main electrical outlet.
2. Connect the small end of the USB cable (8) into the
vacuum body (1) charging receptacle. See fig 1.
The indicator light will turn on.
Installation:
1. Insert the filter bag with gasket (2) into the vacuum body
(1). See fig 2.1.
1
8
Fig 1
(286PO) RECHARGEABLE HANDHELD VACUUM ENGLISH SIZE: 4.875” X 7.25” 10/21/2019
286
PO
SAVE THESE INSTRUCTIONS
Page 3
For vacuuming fine-small particles, insert the micro-filter bag
(7) into the filter bag (2)
before inserting the filter bag (2) into the vacuum body (1). See fig 2.2.
2. Install the vacuum body cover
(3) onto the vacuum body (1). Turn the cover (3) clockwise
to securely lock it to the vacuum body. See fig 3.
3. Attach the desired cleaning head accessory to the vacuum body cover. See fig 4.
Note: The ridge on the vacuum body cover
(3) matches the groove on the end of the
vacuum brush head (4) or vacuum nozzle (5).
2
1
2
2
7
1
2
3
Fig 2.1 Fig 2.2 Fig 3
1
2
3
4
Fig 5
Fig 4
4. Attach the aluminum pole
(9) by squeezing the spring buttons and inserting into handle
of the vacuum body (1). Check the buttons “pop” into the holes. Adjust the length of the
shaft by unlocking, extending and locking each section accordingly. See fig 5.
Optional: The included pole adaptor (10) can be used with other sizes of extension
poles.
