Sida 1/52
U S E A N D
M A I N T E N A N C E
I N S T R U C T I O N S
N°REV REVISION DESCRIPTION REV. DATE REVISER
01 02/05/2014 R.R.REGULATORY UPDATE
02 27/08/2015 L.B.
CORRECTIONS AND LAYOUT UPDATE
03 10/09/2017 D.N.ADDED GAS R452A
Information regarding the warranty and assistance
Warranty validity: of the individual parts for 12 months from the date of invoicing, as stated in the price list in force.
Contacts:
Customer service +39.0438.5844
User assistance +39.0438.5844
Technical - spare parts after-sales +39.0438.2020
Fax +39.0438.2023
E-mail service@irinox.com
Web site www.irinoxprofessional.com
For every request relative to your blast chiller, always indicate:
The model•
The serial number •
stated on the label on the model
Dear Customer,
Thank you for having chosen IRINOX.
Please take the time to read this manual carefully to make the most of all the potential and benefits of your new MUL-
TIFRESH.
We would like to remind you that the perfect operation of the machine also depends on its correct use.
Keep this manual close to the MULTIFRESH so that it can be consulted easily by you and anyone else.
The graphic representations of the controls in the manual have been designed to make the machine easy and
intuitive to use.
Symbols key
suggestions and details for correct use of the blast chiller
standards for your safety
additional information in this manual
3
SAFETY INFORMATION
Below find the main general Safety
Standards:
Do not touch or operate the machine with damp or
wet feet and hands.
do not insert screwdrivers, kitchen tools or other
between the protections and the moving parts.
before carrying out cleaning operations or routine
maintenance, disconnect the machine from the
power supply mains, switching the master switch
off and removing the plug.
do not pull the power supply cable to disconnect the
machine from the power supply mains.
If the power supply cable is damaged, it must
be replaced by the manufacturer,
service centre or similarly qualified staff, in order to
avoid risks.
Non-mobile equipment, not equipped with disconnection
devices from the power supply having a contact separa-
tion of all poles that provide disconnection in category III
overvoltage conditions; must be equipped with a discon-
nection device incorporated in the fixed connection in
compliance with the connection regulations.
When loading the machine, the use of kitchen
gloves is recommended in order to prevent
burns on contact with the hot trays and trolleys.
Use gloves suitable for trays and cold trolleys.
During cleaning operations, of the condenser
in particular, always wear protective gloves,
safety glasses and mask for the respiratory protection.
The core probe must only be used for the pur-
pose for which it has been designed: detect
the temperature at the centre of the food stuffs to be
blast chilled and/or frozen.
It is prohibited to remove the protections and
safety devices in order toperform routine
maintenance.
Do not store explosive substances, such as
aerosol spray cans with inflammable propel-
lant inside the equipment.
Climatic Class:
4 (environment temperature 30°C with relative
humidity 55% non condensing) according to
I E C E N 6 0 3 3 5 - 1 , IEC E N 6 0 3 3 5 - 2 - 8 9 ,
ISO23953-2:2005 (E) Standards
Do not overload the machine beyond that estab-
lished by the manufacturer (Trays capacity and
Yield Tab.).
Do not block the ventilation openings of the unit
and of the structure in which it is positioned.
•
•
•
•
MODELS
MF25.1 25
MF45.1
MF70.1
Blast chilling (Kg)
Yields
Freezing (Kg)
25
The yields are declared in the following conditions:
- Trays filled with water at 90°C
- Environment temperature: 32°C
- No chamber pre-cooling
4545
7070
MF30.2 3030
MF70.2 7070
MF85.2 8585
(*) tray to rested on 530x650mm grill
MODELS
MF25.1
MF45.1
MF70.1
GN 1/1 h=20
CATERING CONFECTIONERY
8
18
27
MF30.2 16
MF70.2 36
MF85.2 54
GN 1/1 h=40
5
12
18
10
24
36
GN 1/1 h=65
4
9
13
8
18
26
GN 2/1 h=20
8
18
27
GN 2/1 h=40
5
12
18
GN 2/1 h=65
4
9
13
400x600 h=20
8
18
27
8*
18*
27*
400x600 h=40
5
12
18
5*
12*
18*
400x600 h=60
4
9
13
4*
9*
13*
• Do not use mechanical or similar devices to
speed up the thawing process other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use inside the unit any electrical device
unless it is of the type and/or model recom-
mended by the manufacturer.
• Do not use water jets to clean the unit.
• The unit can be used by children over 8 years
and by people with reduced physical, sensory
or mental capabilities, or lack of experience or
knowledge, provided under supervision or
after that the latter have received instructions
relating to the safe use of the unit and under-
standing of the dangers inherent in it. Children
must not play with the unit. Cleaning and
maintenance intended to be performed by the
user must not be performed by unsupervised
children.
