MAINTENANCE
The lenses have anti-reective coating and
are dirt resistant. However, they are not
scratch-proof. Use only cleaning agents
intended for optics. Larger impurities should
be removed rst with compressed air or with
a clean soft brush.
WARNINGS
The lens is equipped with a rubber seals to
protect the interior from dust and moisture.
It is not, however, completely waterproof.
Do not submerge it in water or store it for
extended periods of time in humid places.
To achieve better water-tightness, use
of the front protective lter is recommended.
Protect the lens from shock, being dropped
and excessive vibration, and do not leave
the lens in direct sunlight as a focused light
beam may cause a re.
Do not expose the lens to high temperatures.
Do not look through the lens at the sun
or in its general direction, as that may cause
permanent eye damage. TH Swiss AG
Switzerland
info@irixlens.com
irixlens.com
45mm T1.5
USER’S MANUAL
The lens and its accessories should be kept
away from children and animals, as they
contain small elements that constitute
a chocking hazard.
Unsupervised dismantling of the lens may
lead to permanent damage and loss of
warranty.
In the case of any faulty operation, it is
strongly recommended that you contact the
authorized Irix service point.
cine lens
[4]
[6]
[9]
]
]
Thank you for choosing our product. Your new
lens has been designed with both the eort
and experience of not only engineers, but also
of cinematographers. It has been created based
on the best available materials, technology
and solutions, thus making it the perfect tool
for both professionals and hobbyists.
The Irix Cine 45 mm T1.5 is a full frame cinema
lens with a standard focal length. Is is designed
for cameras with sensor diagonal size up to
43.3 mm.
[1]
[9]
[9]
[7]
[8]
[3]
[4]
[6]
[6]
[4]
[5]
[2]
[3] LENS HOOD
Using the lens hood improves contrast and pro-
tects the front lens against dirt and mechanical
damage.
The lens hood has an easy to use magnetic
mount with a positioning system. To save
space the lens hood can be attached
in an reversed position during transport.
WARNINGS
Do not hold the lens by the lens hood, as this
may cause the lens hood to detach and cause
the lens to fall.
[4] LENS SUPPORT FOOT
The support foot is a standard feature of the
Irix Cine 45mm T1.5 lens.
The lens is equipped with a detachable foot for
supporting the lens when using follow focus
system on rods. Depending on the follow focus
conguration, the foot can be attached
at the bottom or top position of the lens.
WARNINGS
The foot is not suitable for mounting a camera
with the lens directly on a tripod. Using it to at-
tach the lens to the tripod may lead to damage
both the lens and a camera.
[6] FOCUS RING
To focus on a given object, look at the image
in the viewnder or on the camera screen and
adjust it manually by rotating the focus ring.
You can also use the distance scale on the lens
body to estimate the distance to the chosen
object for the photograph. The focus ring can
be rotated by hand or by using the follow focus
system in the range of 0,4 m (15.75”) to innity.
[7] LENS MOUNT
Mounting the lens to the camera as described in
the camera’s user manual may dier with various
systems.
The marker (dot) on the lens body facilitates
mounting the lens onto the camera.
[8] REAR LENS CAP
The rear lens cap protects the lens during trans-
port and should be put in place whenever the lens
is not attached to the camera.
[9] APERTURE RING
The aperture ring allows for smooth adjust-
ment of the T number of the lens in the range
from T1.5 to T22. The ring can be rotated by
hand or by using the follow focus system.
[10] TECHNICAL SPECIFICATION
[5] ADAPTING RING
FOR FOLLOW FOCUS SYSTEM
The lens is equipped with a unique rotating
adaptive ring for follow focus systems.
It provides an easier t for your focus gear,
to the focus ring from any angle. The ring can
be rotated 360° with increments of 15 degrees.
[1] FRONT LENS CAP
The front lens cap protects the front lens and
should always be put in place whenever the lens
is not being used.
[2] FRONT FILTER THREAD
The design of the lens allows the use of 86mm
screw-in lters.
Screw the lter on clockwise as viewed from
the front lens. Before fully screwing on the
lter, make sure the lens does not come into
contact with the lter’s glass surface, as this
may cause damage to both components.
Image coverage full frame (43.3 mm)
Focal length 45 mm
Aperture range (T) T1.5 ~ T22
Number of iris blades 9 (rounded shape)
Minimum focusing distance 0,4 m (15.75”)
Focus ring rotation angle
gear pitch 0.8 M
number of teeth 117
distance scale
metric / imperial
Aperture ring rotation angle
gear pitch 0.8 M
number of teeth 110
full frame
S-35mm 1.39x
APS-C 1.53x
APS-C 1.62x
MFT 2.0x
Front filter thread 86 x 1.0 mm
Weather sealing Yes
Front diameter 95 mm
Canon EF – mount 112 x 97 mm
Sony E mount 138 x 97 mm
Arri PL mount 114 x 95 mm
MFT mount 138 x 97 mm
Canon EF – mount 1129g
Sony E mount 1190g
Arri PL mount 1135g
MFT mount 1186g
Included accessories
lens hood 1 pc
front lens cap
1 pc
rear lens cap
1 pc
support foot 1/4” 1 pc
1, 2 – a lens without accessories
180°
75°
Viewing angle
(horizontal)
43,6°
30,9
°
29,4°
27,7°
21,8°
Dimensions (L x D) 1
Weight2
