BPU 128DE- -SS
8 bay Slim 2.5” SSD Hard Drive Cage-
User’s Manual
Specicaon:
Order Informaon:
Hot Swap
8x2.5” Slim SSD (7mm or less)
Cooling Fan
1x40mm
Standard Drive Bays
5.25” Drive: 1
Dimension (W x H x D)
5.75 x 1.65 x 6.3 inches
HDD Interface
SATA I/II/III, SAS I/II
Weight
2 lbs
Model Number:
Color:
UPC Code:
BPU 128DE- -SS
Black
846813039116
Introducon:
The 2.5" Disk Array BPU 128DE SS, the Disk Array to be set up in various - -
configuraons: as RAID 0, RAID 1, RAID 5 or JBOD, as individual drive, or
whatever the mix that best ts the applicaon. The Disk Array can start with as
little as one hard drive and then expands as needed. Hard Drive can also be
removed or added to the system without turning off your system power or
restarng your computer.
Features:
• Point to point, free from master/slave seng
• Supports SSD/HDD thickness 7mm or less
• Built in 40mm cooling fan-
• LEDs for power and HDD accessing
• Supports Plug & Play, h Swappable ot-
• High performance transfer rate up to 6.0 Gb/s
• Supports 8x 2.5” SAS I/II & SATA I/II/III HDD/SSD
• Mechanical lock design
• Metal body with stainless HDD carrier
Hardware Informaon: Front View
D-1: Power LED, green when lid.
D -2: HDD acvity LED, amber blinking when lid.
D 3: -Mechanical lock
BPU 128DE- -SS
BPU 128DE- -SS
BPU 128DE- -SS
iStarUSA – Powered by iStarUSA Group
727 Phillips Drive
City of Industry, CA 91748
Tel: (888) 989-1189
Email: sales@istarusa.com
Hardware Informaon: Rear View
D 4: -15-pin power connector
D -5: 7 pin data connector-
Hardware Informaon: HDD Tray
HDD Cage to 5.25” Bay Installaon:
1. Install BPU 128DE SS HDD cage to an available 5.25” bay from a system.- -
2. Secure the HDD cage on both sides with provided screws.
3. Connect two SATA power connectors to the HDD cage from the power supply.
4. Connect data cables to the HDD cage.
Accessories:
• Screws
2.5” SSD/HDD to tray Installaon:
1. Insert slim 2.5” SSD/HDD into the tray.
2. Use provided screws to fasten SSD/HDD to the tray from boom
3. Slide the HDD tray back to the HDD cage.
4. Repeat step 1 to 3 to nish the rest of HDD/SSD installation.
iStarUSAcare:
We will help you navigate our website to nd the informaon that
you need. Go to www.istarusa.com, and click on live chat bubble
above the Search Bar
Our technicians are standing by to take your questions. Visit
http://istarusa.com/support/ , and you will receive a technical
support cket to help track your requests from the beginning to the
end. Or you can contact us @ 989 1189888- -
FCC and CE Radiation Norm
FCC
This equipment has been tested and found to comply with limits for Class B digital device pursuant to Part 15 of Federal Communications
Commission (FCC) rules.
CE
This equipment has been tested and found to comply with the limits of the European Council Directive on the approximation of the law of the member
states relating to electromagnetic compatibility (89/336/EEC) according to EN 55022 Class B.
FCC and CE Compliance Statement
These limits are designed to provide reasonable protection against frequency interference in residential installation. This equipment generates uses
and can radiate radio frequency energy, and if not installed or used in accordance with the instructions may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in television reception, which can be determined by turning the
equipment off and on. The user is encouraged to try and correct the interference by one or more of the following measures: Reorient or relocate the
receiving antenna, Increase the separation between the equipment and the receiver, connect the equipment into an outlet on a circuit different from
that to which the receiver is connected to.
CAUTION!
The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible
for the compliance could void the user’s authority to operate the equipment.
BPU 128DE- -SS
BPU 128DE- -SS
BPU 128DE- -SS
BPU 128DE- -SS
