H0282300 Rev J
ENGLISH
WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment
installation and maintenance so that all of the instructions in this manual can be followed exactly. Before
installing this product, read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage, personal injury, or death.
Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTENTION INSTALLER - This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
Jandy® Pro Series
Sidemount Composite Sand Filters
JS
INSTALLATION AND
OPERATION MANUAL
Page 3
ENGLISH
Jandy® Pro Series, Sidemount Composite Sand Filters | Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER)
PUMP MODEL HORSEPOWER
FILTER MODEL SERIAL NUMBER
NOTES:
Section 1. Safety Information 4 ..........................
1.1 Important Safety Warning 4 ...................................
1.2 General Safety Instructions 4 ................................
Section 2. General Information 5 .......................
2.1 Introduction ......................................................... 5
2.2 Description ......................................................... 5
2.3 General Requirements 5 .......................................
2.4 SpecicationsandDimensions .......................... 6
Section 3.
Installation Instructions 6 ...................
3.1 Filter Location 6 .....................................................
3.2 Anchoring the Filter to the Equipment Pad 6 .........
3.3 Filter Preparation 7 ................................................
3.4 Filter Plumbing 7 ...................................................
3.5 Filling Filter with Sand 9 ........................................
3.6 Use of Zeobrite® as an Alternative to Sand 10 .....
3.7 Lid Installation ...................................................11
Section 4.
Start-Up and Operation .................. 11
Section 5. Filter Cleaning 12 ...............................
5.1 Filter Cleaning Instructions 12 ...............................
5.2 Optimal Filter Performance 13 ..............................
5.3 Chemical Cleaning Procedure 13 ..........................
Section 6. Maintenance 14 ..................................
6.1 General Maintenance 14 .......................................
6.2 Pressure Gauge 14 ...............................................
Section 7. Winterizing 14 ....................................
Section 8. Removing the Lid 15 .........................
Section 9. Troubleshooting 15 ...........................
Section 10. Parts List and Exploded View 17 .....
10.1 Jandy JS60-SM Sand Filter Parts List 17 ..............
10.2 Jandy JS100-SM Sand Filter Parts List 17 ............
10.3 Jandy JS60-SM Sand Filter
Exploded View 18 .................................................
10.4 Jandy JS100-SM Sand Filter
Exploded View 19 .................................................
Section 11. Head Loss Curves 20 ... .....................
11.1 Jandy JS Series Sand Filters Design
Head Loss Curves 20 ............................................
