TUTTO&SEMPRE
endgame mixer
TUTTO&SEMPRE is a 4 stereo channels performance mixer with an active patchbay, individual VCAs and outputs, clickless mutes and
two high fidelity headphones drivers with switchable stereo inserts.
why
• To enjoy your mix with another person during a live session.
• To route signals while keeping everything in place.
• To give pristine balanced line level signals to your audio engineer.
• To send simultaneously individual outputs to your audio interface and to your PA.
with
• Stereo modules – modulate them with the individual VCAs per channel.
• Audio interfaces – thanks to the 8 individual post-attenuation outputs.
• Mixing headphones – optimized signal path with high performance op-amps.
• Stage mixers – feed them a low noise, balanced line level output.
how
While listening with a fri d you can send simultaneously individual outputs to en
your audio interface, a balanced line level signal to your PA and a stereo mix
directly into your recorder.
The module consists of two main blocks:
Mixing frame
I - 4 pairs of actively normalled inputs with input LED meters.
↑ - Patchbay out a cable here interrupts the signal flow. –
↓ - Patchbay insert to get back to the mix.
- Control voltage input for the VCAs. V
Audio graded logarithmic stereo potentiometers.
Paired clickless mute toggle.
- Individual output post attenuators. O
Output stage
The main level knob regulates the volume of the three outputs: and are balanced L R
line level signals while S is a combined stereo output designed to be fed into external
3.5mm interfaces.
A stand for auxiliary inputs: signals fed here will bypass the first mixing block.
The main mix continues to flow to the two headphones amplifiers. Each one of them
can easily power up to 600 ohms drivers with low noise and high-fidelity performance.
A stereo aux input can be fed into each one of the phones sections with a switch that
allows isolated preview listening and routing to the main mix – this makes the module
able to manage up to 7 stereo signals at the same time.
features
• Signal path optimized for the integration between modular systems and outboards.
• Versatile mixing frame with an active patchbay, stereo attenuators, paired VCAs and
clickless mutes.
• Two balanced mono and a stereo output with auxiliary input.
• Two independent headphones drivers with stereo preview input.
• “Whatever” power connector a.k.a. don’t mind the polarity.
specs
• dimensions width HP, depth 20 25mm.
• current draw +12V 250 , -12V 150 . ma ma
Demos and build documentation at jolin.tech/tuttoesempre
