KEF.COM

Not all models / nishes are available in all markets. Contact your local dealer for specic range details.

KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.

Ci specifications sheet

Extreme Theatre

Tall Rectangle

Model Ci5160REF-THX Ci5160RL-THX Ci3160RL-THX

Series Reference Series R Series R Series

Nominal impedance 4Ω 4Ω 4Ω

Sensitivity (2.83V/1m) 90dB 90dB 90dB

Frequency response (±6dB)

open-backed 40Hz - 28kHz 40Hz - 28kHz 45Hz - 28kHz

Frequency range (-10dB) 35Hz - 45kHz 35Hz - 45kHz 35Hz - 45kHz

Nominal coverage (degrees) 150° 150° 150°

Max SPL (dB) 116dB 111dB 106dB

Crossover frequency 400Hz, 2.8kHz 300Hz, 2.4kHz 340Hz, 2.5kHz

Drive units

LF 4 x 160 mm (6.5 in.) 4 x 160 mm (6.5 in.) 2 x 160 mm (6.5 in.)

MF 125 mm (5.25 in.) Uni-Q 160 mm (6.5 in.) Uni-Q 160 mm (6.5 in.) Uni-Q

HF 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.)

Recommended amplier power 40 - 500 W 40 - 250 W 30 - 180 W

Recommended high-pass lter (Hz) 35Hz - 80Hz*40Hz - 80Hz*40Hz - 80Hz*

Product external dimensions

(H x W x D)

1070 x 230 x 105.7 mm

(42.13 x 9.06 x 4.16 in.)

1070 x 230 x 105.7 mm

(42.13 x 9.06 x 4.16 in.)

680 x 230 x 105.7 mm

(26.77 x 9.06 x 4.16 in.)

Cut-out dimensions

(H x W)

1052 x 209 mm

(41.42 x 8.23 in.)

1052 x 209 mm

(41.42 x 8.23 in.)

660 x 209 mm

(25.98 x 8.23 in.)

Net weight 22.0 kg (48.5 lbs.) 19 kg (41.89 lbs) 11.7 kg (25.79 lbs)

Mounting depth from surface 99 mm (3.9 in.) 99 mm (3.9 in.) 99 mm (3.9 in.)

Optional rough in frame RIF5160L RIF5160L RIF3160L

Ideal Rear Volume (L) 90L 90L 60L

Minimum Rear Volume (L) 40L 40L 30L

Certication THX ULTRA2 THX ULTRA2 THX ULTRA2

* Recommended high-pass lter for THX spec: 80Hz

Ci4100QL-THX

Q Series

4Ω

89dB

55Hz - 28kHz

40Hz - 30kHz

150°

104dB

2.2kHz

3 x 100 mm (4 in.)

100 mm (4 in.) Uni-Q

19 mm (0.75 in.)

10 - 150 W

55Hz

490 x 128 x 81 mm

(19.29 x 5.04 x 3.19 in.)

476 x 114 mm

(18.74 x 4.49 in.)

3 kg (6.61 lbs)

76 mm (3 in.)

RIF4100L

15L

THX SELECT2, IP64

KEF.COM

Not all models / nishes are available in all markets. Contact your local dealer for specic range details.

KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.

Ci specifications sheet

Model Ci200R R-TH X Ci20 0R S-TH X

Series R Series R Series

Nominal impedance 4Ω 4Ω

Sensitivity (2.83V/1m) 90dB 90dB

Frequency response (±6dB)

open-backed 33Hz - 28kHz 33Hz - 28kHz

Frequency range (-10dB) 28Hz - 45kHz 28Hz - 35kHz

Nominal coverage (degrees) 120° 120°

Max SPL (dB) 106dB 106dB

Crossover frequency 2.2kHz 2.2kHz

Drive units

200 mm (8 in.) Uni-Q

38 mm (1.5 in.)

Recommended amplier power

10 - 190 W

Recommended high-pass lter (Hz)

35Hz - 80Hz* 35Hz - 80Hz*

Product external

dimensions

(H x W x D) -

273 x 273 x 132.6 mm

(10.75 x 10.75 x 5.22 in.)

Diameter Ø 290 mm (11.42 in.)

Depth 132.6 mm (5.22 in.)

Cut-out dimensions

(H x W) -

240 x 240 mm

(9.45 x 9.45 in.)

Diameter Ø 238 mm (9.37 in.)

Net weight

3.6 kg (7.94 lbs.)

Mounting depth from surface 126.5 mm (4.98 in.)

127 mm (5 in.)

Optional rough in frame

RIF200R

RIF200S

Ideal Rear Volume (L) 20L 20L

Minimum Rear Volume (L) 10L 10L

Certication THX ULTRA2, IP64 THX ULTRA2, IP64

Extreme Theatre

Round / Square

* Recommended high-pass lter for THX spec: 80Hz

KEF.COM

Not all models / nishes are available in all markets. Contact your local dealer for specic range details.

KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.

Ci specifications sheet

Subwoofer

Model Ci3160RLb-THX

Ci200QSb-THX

Passive Mode

(Crossover “ON”)

Ci200QSb-THX

Active Mode

(KASA500)

Series R Series Q Series Q Series

Nominal impedance 4Ω 6Ω -

Sensitivity (2.83V/1m) 92dB 85dB -

Frequency response (±6dB)

open-backed 20Hz - 140Hz 40Hz - 100Hz 30Hz - 140Hz

Frequency range (-10dB) 25Hz - KASA setting 29Hz - 140Hz 25Hz - KASA setting

Max SPL (dB) 112dB 104dB 104dB

Crossover frequency - -100Hz

Drive units LF 3 x 160 mm (6.5 in.) 200 mm (8 in.) 200 mm (8 in.)

Required amplier KEF KASA500 - KEF KASA500

Recommended amplier power - 10 - 150 W -

Recommended high-pass lter (Hz) 25Hz - 80Hz* - KASA

Recommended low-pass lter (Hz) 50Hz - 120kHz 80Hz - 120Hz 50Hz - 120Hz

Product external dimensions

(H x W x D)

680 x 230 x 96 mm

(26.77 x 9.06 x 3.78 in.)

273 x 273 x 106 mm

(10.75 x 10.75 x 4.17 in.)

273 x 273 x 106 mm

(10.75 x 10.75 x 4.17 in.)

Cut-out dimensions

(H x W)

660 x 209 mm

(25.98 x 8.23 in.)

238 x 238 mm

(9.37 x 9.37 in.)

238 x 238 mm

(9.37 x 9.37 in.)

Net weight 10.9 kg (24.1 lbs) 3.3 kg (7.28 lbs) 3.3 kg (7.28 lbs)

Mounting depth from surface 88.5 mm (3.84 in.) 101.6 mm (4 in.) 101.6 mm (4 in.)

Optional rough in frame RIF3160L RIF200S RIF200S

Ideal Rear Volume (L) 80L 32L#32L#

Minimum Rear Volume (L) 40L 20L 20L

Certication THX ULTRA2, THX SELECT2 THX ULTRA2, THX SELECT2, IP64 THX ULTRA2, THX SELECT2, IP64

# For single speaker only. Double volume for pair speakers.

* Recommended high-pass lter for THX spec: 80Hz
